Summary of Contents for Mediclinics M99A-UL
- Page 1 HAND DRYERS / SECADOR DE MANOS / SÉCHE-MAINS M99A-UL / M99AC-UL / M99ACS-UL M88APLUS-UL INSTALLATION AND OPERATING MANUAL MANUAL DE INSTALACIÓN Y UTILIZACIÓN MANUEL D’INSTALLATION ET D’UTILISATION...
-
Page 2: Installation
ENGLISH INTRODUCTION Technical Features: • Surface Mounted. • Sensor Operated - Adjustable Detection Range: 2-6 inches (5-15 cm). • Voltage: 110 - 120 Volt at 60 Hz. NOTE: For dryer to function properly, a minimum of 15 inches (40 cm) should be spaced between the hand dryer sensor and any obstruction such as shelves, hand washing stations, or any type of reflective surface. -
Page 3: Sensor Range
These adjustments should be made by a qualified technician. High (8-10 inches) Low (4-6 inches) Default Setting: Figure 3 • Detection Range: Low. WIRING DIAGRAM BREAKDOWN LIST OF BASIC PARTS Mediclinics’ part Description Reference number number Fan Wheel RC92239T Motor RC92639-UL... -
Page 4: Method Of Use
METHOD OF USE To dry correctly is recommended rising well to remove all traces of soap. These models operate by hand detection. Place hands 4-6" (10 - 15 cm) from the air outlet and the dryer will start working. Once activated, immediately place hands in air flow and rub together until dry. - Page 5 MODEL MODELO MODÈLE M99A-UL M99AC-UL M99ACS-UL MM88APLUS- GENERAL: GENERAL: GÉNÉRAL : 110 – 120 VAC / 60Hz Input voltage: Alimentación: Alimentation : Consumption: Consumo: Consommation : 13.6 A Rated power: Potencia nominal: Puissance nominale : 2.25 Hp (1,680 W) 9.8 lb...
- Page 6 ANNEX MOUNTING INSTRUCTIONS. To mount onto wall, be sure there are no hidden electrical circuits or pipes in the mounting location. Place the mounting template (provided) on the wall to mark location of four mounting screw holes. Drill four holes (Fig.1) Ø8 (5/16”) diameter and 45mm (1 ¾”) depth.
