Plantronics BACKBEAT 903 - QUICK START GUIDES Online User's Manual

NEED MORE HELP?
Project Specifications
24-hour support in USA:
1-866-363-BLUE (2583)
Project: GSG, ACCORDION, PSD, BB903, EN
Date: 06/15/10
Online user guide:
Component: Accordion User Guide
www.plantronics.com/documentation
1-year limited warranty details:
File Name: 83988-21_BackBeat903+_061510
www.plantronics.com/warranty
Art Master Number: 83988-21
Part Number: 83987-21
Scale: 1:1
© 2010 Plantronics, Inc. All Rights Reserved. Bluetooth
is a registered trademark of Bluetooth SIG, Inc. and any
Resolution: 300dpi
use by Plantronics is under license. All other trademarks
Links: N/A
are the property of their respective owners.
U.S. Patents Pending 83987-21 (06/10) AM83988-21
Fonts: Gesta Light, Regular, Medium, Bold
Software: CS3
Printing Method: Offset Lithography
Inks:
Process Black
PMS 294
PMS 151
Finishes: OVERALL MATTE VARNISH
Notes: FINAL
Designer: Malika Henderson
CALL BUTTON
Company: Oak Hill Corporation
• Take a call or end it (1 tap)
E-mail: malikaann@mac.com
• Redial (2 taps)
• Initiate phone's voice-dialing
Phone: 1.415.847.6083
(2-second press until tone is heard)
• Reconnect lost Bluetooth connection
(1 tap if the headset doesn't automatically reconnect)
• Cancel missed call LED (1 tap)
• Reject a call (2-second press)
• Transfer call to/from phone (during call, 2-second press)
• Enable/disable Online Indicator (while powered on, 2-second
press Call and Volume Up buttons)
MICRO USB CHARGING PORT
• Use with the AC wall charger:
1 hour before first use
3 hours (100% charge)
• Do not use headphones while charging
ADJUST THE FIT
For the best sound performance and a 1. Drape the stereo cable behind your neck.
secure, comfortable fit, be sure to adjust the
2. Guide one earpiece behind your ear and
headphones to rest gently in your ear and
secure the eartip inside your ear using the
drape around the back of your neck.
telescoping/swivel adjustments.
3. Repeat step 2 with the other earpiece and
continue to adjust the fit in either ear until
both eartips rest comfortably and
securely in your ears.
Z109
N10687
TAKE A GOOD LOOK
MUSIC BUTTON
• Play/Pause (1 tap)
LED
• Bass Boost (2-second press)
• Mute Music or Call (1 tap)
• Enable/disable OpenMic™ to pause music and
activate mic (1 tap)
+
-
POWER/PAIRING BUTTON
• On/Off (2-second press to turn on,
4 second press to turn off)
• Activate pairing mode after initial set up
(press until red/blue LED flashes)
• Check battery level (1 tap)
VOLUME/TRACKING BUTTONS
• Volume Up/Down (1 tap per level change)
• Track Forward/Back (2-second press per track change)
Understand the Lights You See: Check the Battery Level:
The LED will advise status of headphones. If you are on a call or listening to music and
hear 3 high tones then you have under 5
• Charging (solid red)
minutes talk time remaining.
• Fully charged (solid blue)
At other times, you can check the battery
• Low battery (2 red flashes every
level by tapping the Power button. The
15 minutes)
headphones will say how many hours of of
• On a call (blue flash every 2 seconds)
use remain. The LED also flashes red to
• Missed call (3 purple flashes. Repeats
show the charge level.
for 5 minutes or until cancelled.)
1 flash = more than 2/3 full
• Pairing mode (repeating red/blue flashes)
2 flashes = 1/3 - 2/3 full
3 flashes = less than 1/3 full
CONNECT TO YOUR PHONE
Bluetooth wireless technology provides 1. READY 2. SET 3. CONNECT 1. READY
a way for devices, like headphones and
Activate the Bluetooth feature on your
phones, to communicate with each other
device, then get it to add / search for /
without wires.
discover new Bluetooth devices.
PLT_BB903+
"Pairing" is the set-up process of introducing
your headphones to your phone. Before Phones have different menus to select from:
using your headphones for the first time,
iPhone: Settings > General > Bluetooth > On
you must pair them with your Bluetooth-
(starts the search for devices)
enabled phone.
BlackBerry® smartphone: Settings/options >
Pairing is a one-time process unless your
Bluetooth: On > Search for devices
phone loses the connection or you want to
pair to a new phone.
VIDEO TUTORIAL:
www.plantronics.com/pairing
TIPS
Stay Near Your Device:
Bluetooth has a working "range" of up to
30 feet between the device and headphones
before audio degrades and the connection
GET
is lost. For best audio reception, keep your
device on the left side of your body.
STARTED
Know How to Reconnect:
Your headphones try to reconnect a lost
connection. If they can't, then tap the Call
button once or manually reconnect via the
device' s Bluetooth menu. BackBeat ® 903
Bluetooth ® Headphones
2. SET 3. CONNECT
Select "PLT_BB903+" from the list of
First time, right out of the box:
Bluetooth devices shown on your device.
With headphones turned off, activate
If device asks for a passcode, enter four
Bluetooth pairing mode by pressing
zeros (0000). You may see
Power/Pairing button on. The LED flashes
red/blue to indicate pairing mode.
Some devices also ask to confirm
connection after pairing.
Pairing new phone/reconnecting original:
The headphone's LED will stop flashing
With headphones turned off, press
red/blue once successfully paired/connected.
Power/Pairing button until the LED flashes
red/blue.
You can now make a call using your device' s
keypad or voice-dialing feature.
+
**** on screen.
