Plantronics Backbeat FIT User Manual

Hide thumbs

Advertisement

Backbeat
FIT
®
User Guide

Advertisement

loading

  Also See for Plantronics Backbeat FIT

  Summary of Contents for Plantronics Backbeat FIT

  • Page 1 Backbeat ® User Guide...
  • Page 2: Table Of Contents

    Play or pause music Skip to next track Play previous track Volume Mute Use voice commands Answer or end a call Decline a call Pairing mode Charge Armband/storage Check battery level DeepSleep Mode Stay connected Backbeat FIT Updater app Specifications...
  • Page 3: Welcome

    Welcome Congratulations on purchasing your new Plantronics product. This guide contains instructions ® for setting up and using your Plantronics Backbeat FIT. Please refer to the safety instructions for important product safety information prior to installation or use of the product.
  • Page 4: What's In The Box

    What's in the box* Headphones Armband USB charge cable NOTE *Contents may vary by product.
  • Page 5: Pairing

    Get Paired The first time you power on your headphones, they begin the pairing process. Power on the headphones. The indicator light located on the right headphone, flashes red and blue to indicate the pairing process ® Activate Bluetooth on your phone and set it to search for new devices. Settings >...
  • Page 6: Headset Overview

    Headset overview Power button Headset indicator light Call button Charge port Volume button: Increases or decreases volume Audio button: Play or pause music, track forward or track back...
  • Page 7: Controls Overview

    Take control Power on or off Press the Power button until you hear “power on"/"power off." Play or pause music Tap the Audio button. Skip to next track Press the Audio button twice. Play previous track Press the Audio button until you hear the confirmation tone to restart the current track. Press the button twice (each press until the confirmation tone sounds) to go to the previous track.
  • Page 8: Charge

    Charge Your new headphones have enough power to pair and listen to audio for a while. The door covering the charging port is located on the right headphone. Open it with your fingernail. It takes up to 2 hours to fully charge the headphones. While charging, the indicator light is red and turns blue once charging is complete.
  • Page 9: Fit

    For the best sound performance and a secure comfortable fit, drape around the back of your head. Rotate the eartip between a plus and minus 20° range to achieve an optimal fit and sound experience.
  • Page 10: Armband/Storage

    Armband/storage Pouch to store headphones. Turn inside out to reverse into an armband to hold your phone during a workout. An extra pocket resides inside to hold smaller phones or music devices.
  • Page 11: Check Battery Level

    Check battery level To check the battery level tap the Power button while your headphones are powered on. Your headphones will announce battery status. "Battery full" = fully charged "Battery level high" = medium to fully charged "Battery level medium" = medium "Battery level low"...
  • Page 12: Deepsleep Mode

    DeepSleep Mode If you leave your headphones powered on but out of range of your paired phone for more than ® 10 minutes, your headset will conserve its battery power by entering into a DeepSleep mode. Once back in range with your phone, press the Power button to exit DeepSleep mode.
  • Page 13: Stay Connected

    Stay connected Bluetooth has a working “range” of up to 33 feet between the phone and the headphones before audio degrades and the connection is lost. Your headphones try to reconnect after a lost Bluetooth connection. If they can’t, tap any button once or manually reconnect via the phone’s Bluetooth device menu.
  • Page 14: Backbeat Fit Updater App

    Backbeat FIT Updater app Update the firmware for your Backbeat FIT over your Bluetooth connection using the Backbeat FIT Updater mobile application. The Updater app is available for both iOS and Android and can be downloaded from the Apple App Store or GooglePlay respectfully.
  • Page 15: Specifications

    Video Remote Control Profile (AVRCP) v1.4, Handsfree Profile (HFP) v1.6 and Headset Profile (HSP) v1.1 Operating and storage temperature 32°F – 104°F (0 – 40°C) Service and support www.plantronics.com/support NOTE * Performance is dependent upon battery and usage and may vary by device.
  • Page 16: Need More Help

    2132 LR Hoofddorp, Netherlands © 2014 Plantronics, Inc. All Rights Reserved. Bluetooth is a registered trademark of Bluetooth SIG, Inc. and any use by Plantronics is under license. All other trademarks are the property of their respective owners. Patents US 5,712,453; Patents pending...
