Installation manual
Note:
The control panels described in this manual have been designed and manufactured to the highest
standards of quality, reliability and performance adopted by INIM Electronics.
The components selected for this product will operate properly within their specifications when the
environmental conditions outside the product enclosure comply with Class 3k5 (EN 60721-3-3).
EN54:
The gas detection function is not provided for in the aforesaid standard and therefore cannot be
considered EN54-2 compliant.
Specification
Supply voltage
Maximum current draw 230V
AC mains input terminals
Nominal output voltage
Maximum output current
Motherboard absorption
LED board absorption
(where present)
Maximum battery-charge current
Battery specifications
Maximum internal resistance of batteries (R
Output voltage
Battery shutdown tension
Internal fuse of power supply module
Maximum output current ripple
Operating temperature
Isolation class
Enclosure protection class (EN 60529)
Dimensions
Weight (without batteries)
When you remove the four screws and metal-front plate, you will find:
General Description
I
max. a
I
max. b
stand-by
without supply voltage
LED test
stand-by
LED test
)
i max
Previdia Compact Models
PREVIDIA-CxxxS
(in small cabinet)
230V~ (-15% / +10%) 50/60Hz
0.5 A
AC Input
230V ~ 50/60 Hz
L N
27.6 V
1.5 A
1.5 A
1.5 A
150mA
130mA
170mA
5mA
115mA
0.6 A
2 x 12 V, 7 Ah
with UL94-V2 flame class casing or higher
2.7 Ohm
from 19 to 27.6V
19V
T 3.15A 250V
420 mV
from -5°C to 40°C
I
IP30
322 x 324 x 86 mm
3.3 Kg
PREVIDIA-CxxxL
(in large cabinet)
1.1 A
AC Input
230V ~ 50/60 Hz
N L
4 A
4 A
4 A
1.2 A
2 x 12 V, 17 Ah
1 Ohm
260 mV
497 x 380 x 97 mm
6.1 Kg
