INIM Electronics PREVIDIA COMPACT Series Installation Manual page 7

Installation manual
INIM Electronics s.r.l.
Via Dei Lavoratori 10 - Fraz. Centobuchi
63076, Monteprandone (AP) - Italy
0051-CPR-1498
EN 54-2:1997 + A1:2006
EN 54-4:1997 + A1:2002 + A2:2006
EN 54-21:2006
EN 12094-1:2003
PREVIDIA-C200LG, PREVIDIA-C200LR, PREVIDIA-C200LZG,
PREVIDIA-C200LZR, PREVIDIA-C200LZEG, PREVIDIA-C200LZER
Control and indicating equipment with power supply equipment, alarm
transmission and fault warning routing equipment and electrical automatic
control and delay device integrated for fire detection and fire alarm systems
installed in buildings and for gas extinguishing systems installed in
buildings and part of a complete system.
INIM Electronics s.r.l.
Via Dei Lavoratori 10 - Fraz. Centobuchi
63076, Monteprandone (AP) - Italy
0051-CPR-1499
EN 54-2:1997 + A1:2006
EN 54-4:1997 + A1:2002 + A2:2006
EN 54-21:2006
EN 12094-1:2003
PREVIDIA-C050SG, PREVIDIA-C050SR, PREVIDIA-C050SZG,
PREVIDIA-C050SZR, PREVIDIA-C050SZEG, PREVIDIA-C050SZER,
PREVIDIA-C100SG, PREVIDIA-C100SR, PREVIDIA-C100SZG,
PREVIDIA-C100SZR, PREVIDIA-C100SZEG, PREVIDIA-C100SZER,
PREVIDIA-C200SG, PREVIDIA-C200SR, PREVIDIA-C200SZG,
PREVIDIA-C200SZR, PREVIDIA-C200SZEG, PREVIDIA-C200SZER
Control and indicating equipment with power supply equipment, alarm
transmission and fault warning routing equipment and electrical automatic
control and delay device integrated for fire detection and fire alarm systems
installed in buildings and for gas extinguishing systems installed in
buildings and part of a complete system.
1.5.2 Directive 2014/53/EU
Hereby, INIM Electronics S.r.l. declares that these Previdia Compact are in compliance with the essential requirements
and other relevant provisions of Directive 2014/53/EU.
Following paragraph explains how to download the complete Declaration of Conformity.
This product may be used in all EU Countries.
1.5.3 Documents for the users
Declarations of Performance, Declarations of Conformity and Certificates concerning to INIM Electronics S.r.l. products
may be downloaded free of charge from the web address www.inim.biz, getting access to Extended Access and then
selecting "Certifications" or requested to the e-mail address info@inim.biz or requested by ordinary mail to the address
shown in paragrafo 1.5.1.
Manuals may be downloaded free of charge from the web address www.inim.biz, getting access to Extended Access and
then selecting "Manuals".
General information
0051
18
0051
18
Performance in the event of fire
Power supply performance
Response delay (response time in the event of fire)
Transmission performance
Operating reliability
Thermal resistance
Vibration resistance
Durability of
operating reliability:
Humidity resistance
Electrical stability
Options provided in accordance with EN54-2
7.8 Output to fire alarm devices
7.9 Output to fire alarm routing equipment
7.10 Output to fire protection equipment
7.11 Delay on outputs
7.12 Co-incidence detection (Type A, B and C)
7.13 Alarm counter
8.3 Point fault signal
8.9 Output to remote fault or warning signalling devices
9.5 Addressable points out-of-service
10.0 Test condition
Options provided in accordance with EN12094-1
4.17 Delay of extinguishing signal
4.18 Signal representing the flow of extinguishing agent
4.19 Monitoring of the status of components
4.20 Emergency hold device (*)
4.21 Control of flooding time
4.23 Manual only mode
4.24 Triggering signals to equipment within the system
4.26 Triggering of equipment outside the system
4.27 Emergency abort device (*)
4.30 Activation of alarm devices with diverse signals
(*) one only between 4.20 and 4.27
Additional information according to EN 54-2
About information required at point 12.2.1, see data contained in this
manual.
Additional information according to EN 54-4
For the information required by point 7.1, see data contained in this
manual.
Additional information according to EN 54-21
For the information required by point 7.2.1, see data contained in this
manual.
Additional information according to EN 12094-1
Environmental class: A
Degree of protection: IP30
Flooding zones: 1
Zones for CO2, inert gas or halogenated hydrocarbons.
Response delay activation condition: max 3s
Response delay triggering of outputs: max 1s
PASS
PASS
PASS
PASS
PASS
PASS
PASS
PASS
PASS
Performan
ce
PASS
PASS
PASS
PASS
PASS
PASS
PASS
PASS
PASS
PASS
Performan
ce
PASS
PASS
PASS
PASS
PASS
PASS
PASS
PASS
PASS
PASS
