INSTRUCTION
MANUAL
2-Tier Square LED Cantilever
Umbrella with Fillable Base
SKY6467 + SKY6468 + SKY6469 + SKY6470 + SKY6471 + SKY6472
SKY6703 + SKY6704 + SKY6705 + SKY6706 + SKY7483 + SKY7486
SKY7487 + SKY7489 + SKY7490 + SKY7493 + SKY7494 + SKY7495
SKY7761 + SKY7762 + SKY7763 + SKY7764 + SKY7765 + SKY7766
SKY7767 + SKY7768
Ver. 5
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for BCP SKY6703
Summary of Contents for BCP SKY6703
- Page 1 Umbrella with Fillable Base SKY6467 + SKY6468 + SKY6469 + SKY6470 + SKY6471 + SKY6472 SKY6703 + SKY6704 + SKY6705 + SKY6706 + SKY7483 + SKY7486 SKY7487 + SKY7489 + SKY7490 + SKY7493 + SKY7494 + SKY7495 SKY7761 + SKY7762 + SKY7763 + SKY7764 + SKY7765 + SKY7766 SKY7767 + SKY7768 Ver.
- Page 2 Solar panel requires 6 to 7 hours of direct sunlight to fully charge. Do not use without umbrella base weights. Recommended Weight: >200 lbs. bestchoiceproducts.com...
- Page 3 NOTICE Please retain these instructions for future reference. • This product is intended for residential use only. • Umbrella base weights are not included. Do not use without umbrella base weights (recommended weight: >200 lbs.). • Place umbrella on a stable and level surface. •...
- Page 4 PARTS CROSSBAR I CROSSBAR II ROTATOR BASE 1 PC 1 PC 1 PC UMBRELLA FOOT PEDAL ROTATOR PLATE 1 PC 1 PC 1 PC SOLAR PANEL COVER SUPPORT CRANK HANDLE 1 PC 1 PC 1 PC BASE WEIGHT I BASE WEIGHT II UMBRELLA COVER 2 PCS 2 PCS...
- Page 5 BEFORE FIRST USE Hold the part F umbrella upside down and shake gently to separate the umbrella ribs. If necessary, carefully pull the ribs apart to free them. Insert and secure the part I crank handle into the crank mechanism on the part F umbrella. Slowly turn the crank to open the umbrella.
- Page 6 PRODUCT ASSEMBLY Press down on the pedal to rotate the base and expose the lower mounting holes. Overlay the rotator base with the crossbars. Attach the part C rotator base to the part A & B crossbars with four part 2 screws and four part 3 washers.
- Page 7 PRODUCT ASSEMBLY Fill the part J & K base weights with your choice CAPACITY PER WEIGHT: of sand or water. (DO NOT MIX sand with water) 220LBS WATER OR 308LBS SAND Place the base weights over the crossbar assembly, place the part K weights closest to the part C rotator base and the part J weights on the outside.
- Page 8 PRODUCT ASSEMBLY Insert the battery connector from the part F umbrella into the part G solar panel. Screw the solar panel onto the top of the pole. Remove the knob on the part C rotator base. Firmly place the part F umbrella onto the part C rotator base. Reinsert and tighten the knob to secure.
- Page 9 OPENING THE CANOPY Grip and squeeze the handle to engage the release. Move the arm up. Release the handle to lock the canopy in your desired position. Slowly turn the crank to open the canopy. ADJUSTING THE TILT Grip and squeeze the handle and move the arm up/down to adjust the tilt angle of the umbrella. Lock it in your desired position by releasing the handle.
- Page 10 TURNING ON THE LIGHTS • Press the power switch on the canopy to turn on LED lights. CLOSING THE CANOPY • Turn the crank counterclockwise to close the canopy.
- Page 11 STORAGE • Close the canopy when umbrella is not in use. • Grip the handle and move the arm all the way down, then secure the umbrella with the attached touch fastener. • Slide the part H cover support into the part L umbrella cover, then unzip the cover. •...
- Page 12 HELP CENTER Question about your product? We're here to help. Visit us at: help.bestchoiceproducts.com CHAT Chat Support Product Inquiry Orders FAQ Product Assembly Returns & Refunds PRODUCT WARRANTY INFORMATION All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long as the item is returned in its original product packaging and all accessories from its original shipment are included.
