- Page 1 INSTRUCTION MANUAL 10ft Solar LED Cantilever Umbrella SKY6228 + SKY6229 + SKY6230 + SKY6231 + SKY6233 + SKY6234 Ver. 2...
- Page 2 As shoppers, we’re always trying to find the perfect balance between quality & value. At BCP, we believe we’ve achieved that. Our diverse catalog of everyday essentials is tailored especially to our customers & guaranteed to hit that sweet spot of high quality & low price.
- Page 3 Do not use without umbrella base weights. Recommended Weight: >100 lbs. bestchoiceproducts.com...
-
Page 4: Tools Required
NOTICE Please retain these instructions for future reference. • Firmly secure all bolts, screws and knobs before use. • Reconfirm that all bolts, screws, and knobs are secure every 90 days. • Fasten screws loosely during initial assembly. Do not firmly tighten the screws until the item is completely assembled. - Page 5 PARTS UPPER CROSSBAR LOWER CROSSBAR SUPPORT SHAFT 1 PC 1 PC 1 PC FOOT PEDAL/ GEAR COVER SHAFT BUSHING ROTATING BASE 1 PC 1 PC 1 PC UMBRELLA SOLAR PANEL CRANK 1 PC 1 PC 1 PC COVER POLE UMBRELLA COVER 1 PC 1 PC...
-
Page 6: Before First Use
BEFORE FIRST USE 1. Hold the umbrella upside down and shake gently to separate the umbrella ribs. If necessary, carefully pull the ribs apart to free them. 2. Slowly turn the crank to open the umbrella. Make sure that the ribs are not stuck together. PRODUCT ASSEMBLY Place the part A upper crossbar on the Attach the part D rotating base to the part... - Page 7 PRODUCT ASSEMBLY Slide the part F shaft bushing down the part C support shaft. Set aside the base assembly. Insert the connector from the part G umbrella into the part H solar panel. Screw the solar panel clockwise onto the part G umbrella until secure.
- Page 8 PRODUCT ASSEMBLY Connect the part G umbrella to the part C support shaft and secure with the part 3 knob.
- Page 9 PRODUCT ASSEMBLY Make sure the self-adhering storage strap on the umbrella is secured, then squeeze the adjustment handle and move it upward to your desired position. Attach the part I crank. Release the self-adhering strap and slowly turn the crank clockwise to open the canopy...
- Page 10 PRODUCT ASSEMBLY Locate the on/o switch inside the umbrella to enjoy the LED lights.
- Page 11 OPERATING INSTRUCTIONS Opening Canopy 1. Compress the handle and move the arm up. 2. Release the handle to lock it in your desired position. 3. Slowly turn the crank clockwise to open the canopy. Adjusting Tilt 1. Compress the handle and move the arm up/down to adjust the tilt angle of the umbrella. 2.
-
Page 12: Usage Tips
OPERATING INSTRUCTIONS Closing Canopy 1. Turn the crank counterclockwise to close the canopy. 2. Compress the handle and pull the arm downward. USAGE TIPS • Umbrella base weights are not included. Do not use this umbrella without umbrella base weights. •... - Page 13 LIGHTS • The light switch is located under the canopy (see step 8). • LED Lights last 6 to 7 hours on a single charge.
- Page 14 LIGHTS • Solar panel requires 6 to 7 hours of sunlight to fully charge. • Make sure the lights are o during charging process. • If the lights are not working, allow the solar panel to charge and try again.
- Page 15 STORAGE 1. Close the canopy. Compress the handle and move the arm all the way down. 2. Fasten the strap around the canopy. 3. Assemble the part I cover pole. Slide the pole into the part J cover. 4. Place cover and pull the string to close the zipper. Remove the cover pole. 5.
-
Page 16: Help Center
HELP CENTER Question about your product? We're here to help. Visit us at: help.bestchoiceproducts.com CHAT Chat Support Product Inquiry Orders FAQ Product Assembly Returns & Refunds PRODUCT WARRANTY INFORMATION All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long as the item is returned in its original product packaging and all accessories from its original shipment are included.
