APRILIA SR 50 - DEALER INSTRUCTION SHEET 2001 Instruction Sheet

aprilia
DEALER INSTRUCTION SHEET
7
1
2
3
ASSEMBLING INDICATORS
Inside the pack, the indicators are hanging as shown
in the diagram; cut the fascia (1).
Fit the left indicator light into its housing
And secure with the screw TCEI M 5x15 (2) and the
flanged self-locking nut M 5 (3).
Repeat for the right-hand indicator.
aprilia part #8202293 - 04/01 - USA
SR 50 DITECH
1
4
2
ASSEMBLING SPRAY GUARDS
To fit the spray guards (1) fit the washer (2) and
secure with the screw TBEI M 5x20 (3) and the self-
locking nut M 5 (4).
Position the license plate light (5) and secure with
two self-blocking nuts M 5 (6). Fit the bulb (7) into
the housing.
6
7
Pag. 4
aprilia
3
2
1
NSTRUCTIONS FOR REMOVING
MOTORCYCLE FROM CRATE
SAFETY MESSAGES
The following warning messages are used on all the
instruction sheets to draw your attention to the situations
described below.
Safety warning symbol. When you see this
5 symbol on the motorcycle or instruction sheets,
beware of potential injury hazards.
Failure to observe the instructions following these
symbols may affect your safety, the safety of
others and that of the motor cycle!
Risk of serious injury or death.
Possible risk of slight injury or damage
to motor cycle.
DANGER
Risk of serious injury or death.
CAUTION
Possible risk of slight injury or damage to motor
cycle.
IMPORTANT
The word "IMPORTANT"is written before any important
information on the instruction sheet.
DEALER INSTRUCTION SHEET
SR 50 Ditech
SR 50 Ditech
For the sake of safety, before starting the
vehicle, carry out a thorough preliminary check.
See the PRELIMINARY CHECK LIST IN THE
VEHICLE OPERATION AND MAINTENANCE
HANDBOOK.
Failure to carry out these checks may lead to
serious injury or damage to the vehicle.
Very little time is required, and the benefits in terms
of safety are enormous.
The components in this handbook are supplied
disassembled, and have to be fitted to the motor cycle.
These instruction sheets for dealers describe the
correct fitting procedures.
Read the instructions in the sheets to avoid
breakages or incorrect assembly.
Remove loose bodywork components from the crate.
After removing the nailed-on supports and crosspieces
from the crate (used for transport purposes), push the
motor cycle off the bottom of the crate and position it
on the stand.
You can now proceed with the operations described
below.
NB: The instructions for the battery, wing mirrors
and spray guards are inside the helmet
compartment under the saddle.
Pag. 1
SR 50 DITECH
