X870 GAMING PLUS WIFI
Motherboard
User Guide

Advertisement

loading
Need help?

Need help?

Do you have a question about the X870 GAMING PLUS WIFI and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MSI X870 GAMING PLUS WIFI

Summary of Contents for MSI X870 GAMING PLUS WIFI

  • Page 1 X870 GAMING PLUS WIFI Motherboard User Guide...
  • Page 2 JRGB1: RGB LED connector ..................47 JARGB_V2_1~3: A-RAINBOW V2 (ARGB Gen2) LED connectors ......48 JAF_1: EZ Conn-Header V1 ..................50 Onboard LEDs........................52 EZ Debug LED ......................52 Installing OS, Drivers & MSI Center ................53 Installing Drivers with MSI Driver Utility Installer ..........54...
  • Page 3 UEFI BIOS ........................57 BIOS Setup ......................58 Entering BIOS Setup ....................59 Resetting BIOS ......................60 Updating BIOS ......................60 Block Diagram .......................62...
  • Page 4 Quick Start This Quick Start provides clear diagrams to help you install the motherboard. Video demonstrations are also available for some installations. Visit these videos by clicking the provided URL on your phone or tablet’ s web browser. Alternatively, you can scan the QR code to access the video directly.
  • Page 5 Safety Information The components included in this package are prone to damage from electrostatic ● discharge (ESD). Please adhere to the following instructions to ensure successful computer assembly. Ensure that all components are securely connected. Loose connections may cause ● the computer to not recognize a component or fail to start.
  • Page 6 Case stand-off notification To prevent damage to the motherboard, any unnecessary mounting stand-off between the motherboard circuits and the computer case is prohibited. The Case standoff keep out zone signs will be marked on the backside of motherboard (as shown below) to serve as a warning to user.
  • Page 7 Installing a Processor ⚽ https://msi.gm/SDBE5855 ●...
  • Page 8 ⚠ Important If you are installing the screw-type CPU heatsink, please follow the figure below to remove the retention module first and then install the heatsink.
  • Page 9 Installing DDR5 memory ⚽ https://msi.gm/S647FF99 ● DIMMA1 DIMMA2 DIMMA2 DIMMA2 DIMMB1 DIMMB2 DIMMB2...
  • Page 10 Connecting the Front Panel Header ⚽ https://msi.gm/S8EF7577 ● Power LED Power Switch JFP1 Reserved HDD LED Reset Switch JFP1 HDD LED - HDD LED HDD LED + POWER LED - POWER LED POWER LED +...
  • Page 11 Installing the Motherboard ⚽ https://msi.gm/S4BA9046 ● Torque: 3 kgf·cm* *3 kgf·cm = 0.3 N·m = 2.6 lbf·in...
  • Page 12 Connecting the Power Connectors ⚽ https://msi.gm/SD937E2C ● ATX_PWR1 CPU_PWR1~2 PCIE_PWR1...
  • Page 13 Installing SATA Drives ⚽ https://msi.gm/S9369131 ●...
  • Page 14 Installing a Graphics Card ⚽ https://msi.gm/SBC41FF1 ●...
  • Page 15 Connecting Peripheral Devices...
  • Page 16 Power On...
  • Page 17 Supports AMD Ryzen™ 9000/ 8000/ 7000 Series Desktop ● Processors* Processor socket AM5 ● * Please go to www.msi.com to get the newest support status as new processors are released. Chipset AMD X870 Chipset 4x DDR5 memory slots*, supporting up to 256GB** ●...
  • Page 18 Continued from previous column 3x M.2 slots (Key M) ● M2_1 slot (From CPU) ● Supports up to PCIe 5.0 x4 (For Ryzen™ 9000/ 7000 ● Series processors) Supports up to PCIe 4.0 x4 (For Ryzen™ 8000 Series ● processors) Supports 2260/ 2280 storage devices M.2 SSD Slots ●...
  • Page 19 Continued from previous column 1x USB 10Gbps Type-C® front panel port (From X870 ● chipset) 1x USB 5Gbps connector (From X870 chipset) Internal USB ● Connectors Supports additional 2 USB 5Gbps ports ● 2x USB 2.0 connectors (From X870 chipset) ●...
  • Page 20 1x 256 Mb flash ● UEFI AMI BIOS ● BIOS Features ACPI 6.5, SMBIOS 3.7 ● Multi-language ● Drivers ● MSI Center ● Acrobat ● Software Adobe Creative Cloud ● AIDA64 Extreme - MSI Edition ● CPU-Z MSI GAMING ● Norton 360 ●...
  • Page 21 Special Features MSI Center DIY Friendly MSI AI Engine PCI-E Steel Armor ● ● Mystic light EZ DEBUG LED ● ● Ambient Link EZ LED Control ● ● Frozr AI Cooling Audio ● LAN Manager Audio Boost ● ● User Scenario ●...
  • Page 22 Package Contents Please check the contents of your motherboard package. It should contain: Board 1x Motherboard ● Documentation 1x Quick installation guide ● 1x European Union Regulatory Notices ● Cables 2x SATA 6Gb/s cables ● 1x 1 to 2 EZ Conn-Cable (V1) ●...
  • Page 23 Back Panel Connectors Item Description Clear CMOS button - Power off your computer. Press and hold the Clear CMOS button for about 5-10 seconds to reset BIOS to default values. HDMI™ port USB 5Gbps Type-A port (From CPU) Flash BIOS port ●...
  • Page 24 LAN Port LED Status Table Link/ Activity LED Speed LED Link/ Activity LED Speed LED Status Description Status Speed No link 10 Mbps Yellow blinking slowly Linked Green 100 Mbps/ 1 Gbps/ 2.5 Gbps Yellow blinking rapidly Data activity Orange 5 Gbps Audio Jacks Connection Audio jacks to headphone and microphone diagram...
  • Page 25 Audio jacks to 4-channel speakers diagram AUDIO INPUT Rear Front Audio jacks to 5.1-channel speakers diagram AUDIO INPUT Rear Front Center/ Subwoofer Audio jacks to 7.1-channel speakers diagram AUDIO INPUT Rear Front Side Center/ Subwoofer Front Panel...
  • Page 26 Installing Antenna 1. Connect two antenna cables tight to the Wi-Fi antenna connectors as shown. 2. Place the antenna as high as possible for a better signal.
  • Page 27 Overview of Components SYS_FAN6 SYS_FAN5 JARGB_V2_3 ATX_PWR1 JTPM1 JUSBC1 M2_1 SYS_FAN2 PCI_E1 SATA▼_A1▲_A2 PCI_E2 SATA▼_A3▲_A4 PCI_E3 M2_2 M2_3 JUSB3 PCI_E4 JFP2 JFP1...
  • Page 28 CPU Socket The AM5 socket is a modern CPU socket designed for AMD processors. It is a key component in contemporary computing systems, providing the foundation for powerful and efficient CPUs. Installing the CPU to the AM5 socket The surface of the AM5 CPU has two notches and a golden triangle to assist in correctly lining up the CPU for motherboard placement.
  • Page 29 ● disconnect the power cord from the power outlet before installing or removing the CPU. Please retain the CPU protective cap after installing the processor. MSI will deal with ● Return Merchandise Authorization (RMA) requests if only the motherboard comes with the protective cap on the CPU socket.
  • Page 30 DDR5 DIMM Slots The DDR5 DIMM slot is a dedicated connector designed to accommodate DDR5 (Double Data Rate 5) memory modules. It represents the latest standard in computer memory, providing enhanced data transfer speeds and efficiency. DIMMA1 DIMMB1 DIMMA2 DIMMB2 Channel A Channel B Memory module installation recommendation...
  • Page 31 It is recommended to use a more efficient memory cooling system for full DIMMs ● installation or overclocking. The stability and compatibility of installed memory module depend on installed CPU ● and devices when overclocking. Please refer to www.msi.com for more information on compatible memory. ●...
  • Page 32 PCI_E4: PCIe 4.0 x4 (From Chipset) ⚠ Important If you install a large and heavy graphics card, you need to use a tool such as MSI ● Graphics Card Bolster to support its weight to prevent deformation of the slot.
  • Page 33 SATA SSDs. Watch the video to learn how to Install M.2 SSD with Screwless M.2 Shield Frozr heatsink. M2_1 ⚽ https://msi.gm/S7F5D000 ● M2_2 M2_3 ⚠ Important If your M.2 SSD equips its own heatsink, please note the following: Remove the M.2 plate or rubber cube in the M.2 slot before installing M.2 SSD.
  • Page 34 Installing M.2 module into M2_1 slot 1. Press and hold the end button of Screwless M.2 Shield Frozr heatsink. 2. Slightly lift up the end part of Screwless M.2 Shield Frozr heatsink and move it forward to uninstall the heatsink. 3.
  • Page 35 4. Insert your M.2 SSD into the M.2 slot at a 30-degree angle. 5. Rotate the EZ M.2 Clip to secure the M.2 SSD, or use the EZ M.2 Clip II, which automatically locks and secures the SSD. 30º 30º 30º...
  • Page 36 Installing M.2 module into M2_2/ M2_3 slot 1. Loosen the screws of M.2 Shield Frozr heatsink. 2. Lift the M.2 Shield Frozr heatsink up and remove it. 3. If you want to install the 2260 SSD in M2_3 slot or the 22110 SSD in M2_2 slot, replace the EZ M.2 Clip II to the 2260 or 22110 hole.
  • Page 37 4. Insert your M.2 SSD into the M.2 slot at a 30-degree angle. 5. Use the EZ M.2 Clip II, which automatically locks and secures the SSD. 30º 30º 6. Remove the protective films from the thermal pads under the M.2 Shield Frozr heatsink.
  • Page 38 SATA_A1~A4: SATA 6Gb/s Connectors These connectors are SATA 6Gb/s interface ports. Each connector can connect to one SATA device. SATA_A2 SATA_A1 SATA_A4 SATA_A3 ⚠ Important Please do not fold the SATA cable at a 90-degree angle. Data loss may result during ●...
  • Page 39 JFP1, JFP2: Front Panel Connectors The JFP1 connector controls the power on, power reset, and the LEDs on your PC case/ chassis. Power Switch/ Reset Switch headers allow you to connect power button/ reset button. Power LED header connects to LED light on the PC case, and HDD LED header indicates the activity of the hard disk.
  • Page 40 JDASH1 : Tuning Controller connector This connector is used to connect an optional Tuning Controller module. Signal Name Signal Name No Pin MCU_SMB_SCL_M MCU_SMB_SDA_M VCC5 Ground...
  • Page 41 CPU_PWR1~2, ATX_PWR1, PCIE_PWR1: Power Connectors These power connectors allow you to connect an ATX power supply. CPU_PWR1~2 Signal Name Signal Name Ground Ground Ground Ground +12V +12V +12V +12V ATX_PWR1 Signal Name Signal Name CPU_PWR1~2 +3.3V +3.3V Ground Ground Ground PWR OK 5VSB +12V...
  • Page 42 JCI1: Chassis Intrusion Connector This connector allows you to connect the chassis intrusion switch cable. Normal Trigger the chassis (default) intrusion event Using chassis intrusion detector 1. Connect the JCI1 connector to the chassis intrusion switch/ sensor on the chassis. 2.
  • Page 43 JUSBC1: USB 10Gbps Type-C® Front Panel Connectors This USB connector allows you to connect to the USB Type-C® port on the front panel and supports data transfer speeds of up to 10Gbps. It features a user-friendly design that ensures proper orientation when connecting the cable. USB Type-C Cable JUSBC1 USB Type-C port of...
  • Page 44 Important Note that the VCC and Ground pins must be connected correctly to avoid possible ● damage. In order to recharge your iPad, iPhone and iPod through USB ports, please install MSI ● Center utility. JTPM1: TPM Module Connector This connector is designed for a Trusted Platform Module (TPM) to enable secure storage of sensitive data and perform cryptographic operations that ensure the integrity of your system.
  • Page 45 CPU_FAN1, PUMP_SYS1, SYS_FAN1~6: Fan Connectors Fan connectors can be divided into two categories: PWM Mode and DC Mode. PWM Mode fan connectors provide a constant 12V output and adjust fan speed with a speed control signal. DC Mode fan connectors control fan speed by changing voltage. Please refer to the following specification table for the fan connector mode of your motherboard.
  • Page 46 JBAT1: Clear CMOS (Reset BIOS) Jumper There is CMOS memory onboard that is external powered from a battery located on the motherboard to save system configuration data. If you want to clear the system configuration, set the jumpers to clear the CMOS memory. Keep Data Clear CMOS/ (default)
  • Page 47 (12V/G/R/B) with the maximum power rating of 3A (12V). Always turn off the power supply and unplug the power cord from the power outlet ● before installing or removing the RGB LED strip. Please use MSI’ s software to control the extended LED strip. ●...
  • Page 48 JARGB_V2_1~3: A-RAINBOW V2 (ARGB Gen2) LED connectors The JARGB_V2 connectors allow you to connect the ARGB Gen2 and the ARGB-based LED strips. The JARGB_V2 connector supports up to 180 individually addressable RGB LEDs with maximum power rating of 3A (5V). Signal Name Signal Name Data...
  • Page 49 Always turn off the power supply and unplug the power cord from the power outlet ● before installing or removing the addressable RGB LED strip. Please use MSI’ s software to control the extended LED strip. ●...
  • Page 50 JAF_1: EZ Conn-Header V1 This header is designed to connect MPG EZ120 ARGB fans, simplifying cable routing. It also allows you to connect the ARGB Gen1 and Gen2 LED strips and system fans. Signal Name Signal Name Ground DATA Sense Ground Speed Control Signal No Pin...
  • Page 51 1 to 2 EZ Conn-Cable (V1) ARGB/ ARGB Gen2 LED Fan JAF_1 header ⚠ Important The Fan-JAF1 Cable is included in the packaging of MPG EZ120 ARGB. ● For more information on how to install MPG EZ120 ARGB, please refer to ● https://msi.gm/S5035E56.
  • Page 52 Onboard LEDs EZ Debug LED These LEDs indicate the debug status of the motherboard. LED Color Status CPU is not detected or fail Yellow DRAM is not detected or fail White GPU is not detected or fail Green Booting device is not detected or fail...
  • Page 53 Installing OS, Drivers & MSI Center Please download and update the latest utilities and drivers at www.msi.com Installing Windows 11 1. Power on the computer. 2. Insert the Windows 11 installation disc/ USB into your computer. 3. Press the Restart button on the computer case.
  • Page 54 2. Select Start > Settings > Windows Update, and then select Check for updates. 3. MSI Driver Utility Installer will pop up automatically. 4. Select the I have read and agree to the MSI Terms of Use check box, and then click Next.
  • Page 55 5. Check the Select All checkbox in the lower-left corner and click Install to install MSI Center and drivers. The installation progress will be shown at the bottom. 6. Once the progress has completed, click Finish.
  • Page 56 MSI Center is an application that helps you easily optimize game settings and smoothly use content creation softwares. It also allows you to control and synchronize LED light effects on PCs and other MSI products. With MSI Center, you can customize ideal modes, monitor system performance, and adjust fan speed.
  • Page 57 UEFI has many new functions and advantages that traditional BIOS cannot achieve, and it will completely replace BIOS in the future. The MSI UEFI BIOS uses UEFI as the default boot mode to take full advantage of the new chipset’ s capabilities.
  • Page 58 ● have. BIOS User Guide If you’ d like to know more instructions on setting up the BIOS, please refer to https://msi.gm/S53FE767 or scan the QR code to access. ⚠ Important The appearance of the BIOS user guide may differ based on your motherboard model.
  • Page 59 Entering BIOS Setup Press Delete key, when the Press DEL key to enter Setup Menu, F11 to enter Boot Menu message appears on the screen during the boot process. Function key +/ -: Increase / decrease the value Enter: Select the item ESC: Exit Tab:...
  • Page 60 ● Please follow the steps below to update BIOS: 1. Download the latest BIOS file from the MSI website that matches your motherboard model, and save it to the USB flash drive. 2. If your motherboard has a Multi-BIOS switch, switch to the target BIOS ROM.
  • Page 61 1. Download the latest BIOS file from the MSI website that matches your motherboard model. 2. Rename the BIOS file to MSI.ROM, and save it to the root directory of a USB flash device. 3. Connect the power supply to CPU_PWR1 and ATX_PWR1. (You don’ t need to install the CPU and memory.)
  • Page 62 Block Diagram X870 GAMING PLUS WIFI DDR5 DIMM A1/A2 PCIe 5.0x16 PCI_E1 DIMM B1/B2 USB 40Gbps GEN5 x4 M.2_1 (Rear Type-C) (PCIe Only) ASM4242 HDMI USB 10Gbps (4K@60Hz) (Rear Type-A) USB 5Gbps USB2.0 (Rear Type-A) (Rear Type-A) GL850 PCIE x4...
  • Page 63 This device may not cause harmful interference. ● This device must accept any interference received, including interference that may ● cause undesired operation. MSI Computer Corp. 901 Canada Court, City of Industry, CA 91748, USA (626)913-0828 www.msi.com...
  • Page 64 ● Compliance with these directives is assessed using applicable European Harmonized Standards. The point of contact for regulatory matters is MSI-Europe: Eindhoven 5706 5692 ER Son, the Netherlands. For any support regarding the EU General Product Safety Regulation (GPSR), please contact MSI Computer Europe В.V.
