APRILIA SCARABEO 500 - DEALER Instruction Sheet

DEALER INSTRUCTION SHEET
FITTING THE STORAGE BOX
• • • • • Lift the seat (1), after releasing it with the
appropriate key.
For fitting the storage box to the scooter,
follow the instructions given in the
instruction sheet p/no. E 107158.
In the USA version, there is no wiring
for stoplights on the storage box.
- 06/03 - USA
aprilia part #8104640
Release 04-07/03
SCARABEO 500
1
2
FITTING THE DEFLECTORS
For fitting the deflectors,
instructions given in the instruction sheet p/
no. E 107158.
For the sake of safety, before starting
the vehicle, carry out a thorough preliminary
check. See the PRELIMINARY CHECK LIST IN
THE VEHICLE OPERATION AND MAINTENANCE
HANDBOOK.
Pag. 8
INTRUCTION FOR REMOVING
follow the
MOTORCYCLE FROM CRATE
SAFETY MESSAGES
The following warning messages are used on all
the instruction sheets to draw your attention to the
situations described below.
Safety warning symbol. When you see
this symbol on the motorcycle or instruction
sheets, beware of potential injury hazards.
Failure to observe the instructions following
these symbols may affect your safety, the
safety of others and that of the motor cycle!
Risk of serious injury or death.
Possible risk of slight injury or damage to
motor cycle.
DANGER
Risk of serious injury or death.
CAUTION
Possible risk of slight injury or damage to
motor cycle.
IMPORTANT
The word "IMPORTANT"is written before any
important information on the instruction sheet.
DEALER INSTRUCTION SHEET
Scarabeo 500
Scarabeo 500
Before carrying out any maintenance
operation or inspection of the front wheel, if
possible hoist the vehicle onto a solid and
level surface with suitable equipment.
When disassembling and reassembling the
front wheel, take extra care not to damage
the brake lines, discs or pads.
Failure to carry out these checks may lead to
serious injury or damage to the vehicle.
Very little time is required, and the benefits
in terms of safety are enormous.
The components in this handbook are supplied
disassembled, and have to be fitted to the motor
cycle. These instruction sheets for dealers describe
the correct fitting procedures.
Read the instructions in the sheets to avoid
breakages or incorrect assembly.
Remove the rear street case from the packing case,
containing the mirrors, battery and components.
After removing the nailed-on supports and
crosspieces from the crate (used for transport
purposes), push the motor cycle off the bottom of
.
the crate and position it on the stand.
You can now proceed with the operations described
below.
Pag. 1
SCARABEO 500
