KCV-X101K MANUAL [10" Digital Color LCD Videophone] AHD CCTV Compatible GUI Full Touch Videophone - Compact and slim design - 10" Digital LCD Screen - Multifamily, Apartment application - Doorcamera/CCTV monitoring function - Connection up to 2 Door Cameras and...
Page 2
Cautions for safety For safe use, please stick to the following cautions. · Please do not dispose this manual after reading the instructions carefully. · Please read all instructions to set up rightly. · This Cautions for Safety may include items that are not contained in specifications of the product that consumer purchases. The important marks in the manual.
Page 3
· Do not disassemble this unit at will as this device is composed by precision parts. ·Install the unit by following the set-up instructions of Kocom. · Do not touch or insert any foreign substances, for example, sticker, magnetic, opener and the like.
Page 4
(2) Place with white wall reflecting direct ray of light (3) Place with direct ray of light ■ Installation 1) Monitor installation (KCV-X101K) 1) Remove wall hanger frame metal behind monitor. 2) Install wall hanger frame metal on 1 type box or wall with attached Vis.
Page 5
87(W) x 150(H) x 15(D)mm [ Dummy is combined : 240(W) x 368.5(H) x 37.5(D)mm ] Viewing angle Diagonal 100˚ Adjusting Angle ※ Door Camera Wiring : Polarzied 4 wire(VCC[12V] / GND / AUDIO / VIDEO) ※ Recommend adaptor : CT-140200 (14V) / UT60-140210-6-02(14V) ※ Kocom is not responsible of non verified power supply.
Page 6
Name and Functions of Each Part ■ Monitor part · Front · Back CAM1 CAM2 INTERPHONE DATA CCTV DOOR1 DOOR2 ③ ② ④ ⑤ ⑥ ⑦ ⑧ ① ① Power ON/OFF Switch ② Speaker ③ Microphone ④ Press long time : Menu Settings / Press short time : Guard ⑤...
Page 8
Product Wiring Diagram ■ 0.52M Door camera VCC(DC12V) - Orange GND - W/Orange, W/Green, W/Brown, Brown VOICE - Green VIDEO - Blue, W/Blue ① ④ D. CAM2 A. CAM1 ① 12V KC-R80E ① 12V ② GND BACK VIEW ② GND ③...
Page 9
Product Wiring Diagram ■ D1(0.41M) Door Camera VCC(DC12V) - Orange GND - W/Orange, W/Green, W/Brown, Brown VOICE - Green VIDEO - Blue, W/Blue ① ④ D. CAM2 A. CAM1 ① 12V KC-R80E ① 12V ② GND ② GND BACK VIEW ③...
Page 10
Last device. And the rest other monitors except the one chosen as "Last Device" must be set as "X". Non-Polarized KC-R80E CCTV DEVICE 1 DEVICE 2 DEVICE 3 DEVICE 4 KCV-X101K KCV-X101K KCV-X101K KCV-X101K CCTV CCTV Door Opener ADAPTOR KIP-32G KIP-32G...
Page 11
Product Wiring Diagram ■ Monitor's Door Opener Connection Ex-Monitor Indoor monitor 1. DC door lock connection . DOOR . DOOR ① 12V DC Door Lock ② GND ① 12V ③ DOOR NO ② GND ④ DOOR COM ③ DOOR NO External Power ⑤...
Page 12
Product Wiring Diagram ■ CAM1 - Outdoor Camera, CAM2 - 420System Connection (Ex-monitor Connection) Indoor monitor Ex-Indoor monitor CAM1 : Door camera CAMERA 1 CAMERA 1 ORANGE ORANGE ORANGE ①VCC(BLUE) ① CA1 VCC ①CA1 VCC W/Orange W/Orange W/Orange ② CA1 GND ②CA1 GND ②GND(YELLOW) W/Green...
Page 13
Product Wiring Diagram ■ CAM1 - CCTV, CAM2 - 420system Connection (Ex-indoor monitor Connection) Indoor monitor Ex-Indoor monitor CAM1 : CCTV ORANGE W/ORANGE W/BROWN BROWN W/GREEN GREEN ORANGE ORANGE CAMERA 1 CAMERA 1 W/BLUE W/ORANGE W/ORANGE ①CA1 VCC ①CA1 VCC BLUE W/BROWN W/BROWN...
Page 14
Refer to the page 20 for setting and the rest DEVICE 4 DEVICE 4 DEVICE 4 DEVICE 4 other monitors except the one chosen as KCV-X101K KCV-X101K KCV-X101K KCV-X101K "Last device" must be set as "X" - Camera and Device...
Page 15
Product Wiring Diagram ■ CCTV Camera connection (CAMERA 1,2 Port) (How to Connect when using coaxial cable) CCTV CAMERA MONITOR CA1 or CA2 CCTV GND ① CA1 or 2 VCC ② CA1 or 2 GND ③ CA1 or 2 AUDIO CCTV VIDEO IN-OUT WIRING (X) Coaxial Cable...
Page 16
KCV-X101K How to Operate ※ Cautions Before Using the Device Please follow following steps before using the device. 1. DEVICE ID - When extending additional monitors, each ID must be set. ID collision may cause malfunction. - In case of ID Collision, "ID collision" may be shown at the top of its screen.
Page 17
Power ON - Before turning the devices on, all connection (door cameras, extension monitors, etc) must be fully made. - As you turn on the power switch placed at the top of its device, and you will find booting progress and the home screen afterward in order.
Page 18
Home Screen Setting - Home screen is the start screen where all functions of the product can be run. - Press menu icon in Home screen to run desired functions. Home screen UI ① Icon for Setting Screen : ⑦ Icon for Preventing Disturbances : Button to function all of the calling melody Menu setting in silence...
Page 19
Calling From Outdoor Camera When calling from the outdoor camera, you can see the image of visitors, make a call, and open the door. ▶ ▶ Press the call button When calling to the monitor, you will see When pressing OFF button while talking with to make a call.
Page 20
Monitoring Outdoor Camera ▶ ▶ When pressing the outdoor camera While the image of outdoor camera Press off button then calling gets monitoring button, the image from #1 is on, press "CAM2" then you see finished. the outdoor CAM 1 will be shown. the other image.
Page 21
Extension Calling & Receiving Function In case of extended monitors or interphones, you can perform extension calling. To perform extension calling, you MUST set each device's numbering at the "Setting" From ID #1 to #4 is available to register, you MUST register in order. ▶...
Page 22
Calling From The Lobby ▶ When calling from the lobby, calling melody will be Pressing door opening button during talk status, then rung. Then, the image at the lobby will be displayed. the lobby's door gets opened and calling will be off. Press door opening button and lobby's door gets Press off button and the talk will be off.
Page 23
Lobby Monitoring KLP-C420 firmware more than 03.00 ver, KVS-A8P/A4P firmware more than 03.00 ver are available ▶ Press lobby button from the home screen, then lobby When pressing door open button during monitoring can be monitored. status, the lobby door's gets opened and calling gets off right away.
Page 24
QR Code ▶ Press Help button from the home screen, Take a QR code and check the manual. Manual QR code appears. Following Points are Normal Operating Condition, NOT a Quality Failure ① When connected monitor is in talk status, KIP-32G the sub interphone gets connected when you pick up the handset. (It means the sub interphone can hear and join into the communication) ②...
Page 25
Setting Menu Screen Home screen > By pressing setting button, it will move to setting menu screen. ① General ② Sound Device ID : Setting monitor's ID. Sound item : Cam1, Cam2, Lobby, Guard, Device, Interphone Time Setting : System time setting. Calling volume : 1~9 Date Setting : System date setting.
Page 26
Your usage of this mode could lead to shortened life time of product. There might be possible afterimage on display due to continuously actived display. We, Kocom, is not resoponsible for possible problem due to this mode and usage. Auto capture : When you select "ON", automatic screen capture...
Page 28
2) If this product breaks down during proper use as a result of product defect, KOCOM will repair it within one year from date of purchase free of charge. 3) The following cases will be subject to charge, even during warranty period: a.
