- Page 1 MOD : GTP-5/N2 Production code : 19104228 05/2024...
- Page 2 INSTALLATION, USAGE AND MAINTENANCE MANUAL EVJ805: BLAST CHILLER...
- Page 3 INSTALLATION, USAGE AND MAINTENANCE MANUAL: BLAST CHILLER CONTENTS INSTALLATION............................27 SITING ..............................27 CLEANING ............................27 WIRING ............................... 28 GENERAL MEASUREMENTS......................28 USE ................................30 – ENVIROMENTAL DATA ........................30 – CONSTRUCTION DATA ......................... 30 – UTILIZACIÓN ..........................30 –...
- Page 4 INSTALLATION, USAGE AND MAINTENANCE MANUAL Before starting the cooler up, we would like to thank you for the confidence you have placed in us on purchasing this machine, and recommend you read and follow the steps detailed in the instructions. This manual is designed to offer the information necessary for the installation, start-up, and maintenance of the Temperature Coolers.
- Page 5 Clean the inside of the chamber to prevent dirt from building up with neutral detergents that do not contain bleach and that are not abrasive. The areas surrounding the appliance should also be cleaned daily, always with soap and water and not with toxic or bleach-based detergents.
- Page 6 - 5 GN 1/1 - 10GN 1/1...
- Page 7 2.0 – ENVIROMENTAL DATA Room Temperature. The production data have been carried out in a technical laboratory with the following environmental according EN17032 Noise level Leq in the point with noise level at 1 metre and in operating conditions <70 dB(A) Lpc at 1 metre in operating conditions <130 dB(C) The measurements of the acoustic tests have been carried out according to ISO 230-5, in a rectangular shaped exposure room without sound-absorbent treatments.
- Page 8 During the cooling cycle: Do not open the door unit it has ended. Do not wrap the product or close the trays. Using trays with a height of over 40 mm is not recommended. The thickness of the product on the tray is compact from 2 to 2.5 cm. Using stainless steel or aluminium containers is recommended.
- Page 9 3.0 POWER FAILURE If there is a power interruption when there is no function, upon restoration of the power supply device reproposing the status to be before the interruption. If there is a power interruption when a feature is active, for restoring the same device will behave in the following manner: - With chilling or a freezing cycle running, the cycle is resumed by taking into consideration the duration of the lack of voltage;...
- Page 10 Short press: Start the selected function or gives access to the page of the selected menu Press and hold for 2 seconds: Stops the current cycle During a setting: allows you to make editable the value that you want to modify, while a subsequent pressing of the same confirms the value set Icons Icon...
- Page 11 Number of the current phase Chilling/freezing Cycle successfully completed Chilling/freezing Cycle does not successfully completed – SETTINGS OVERVIEW You access the list of settings by pressing from the Home screen LANGUAGES You can choose between English, French, German, Spanish, Portuguese, Simplified Chinese, Traditional Chinese.
- Page 12 PARAMETERS To view the parameters from the menu it is necessary to insert previously password -17 or-19 using the key to change the value of the parameters, select the desired parameter and with the key to make it editable; confirm finally with the key. The machine is set at the factory for optimal operation under specific conditions and it is not advisable to change the parameters.
- Page 13 Chilling hard temperature cycle and conservation Chilling and conservation Chilling hard time cycle and conservation - Freezing temperature cycle and conservation - Soft freezing temperature cycle and conservation - Freezing time cycle and conservation - Freezing soft cycle time cycle and conservation functions of the Chilling or Freezing accessed in a...
- Page 14 It is possible to finish the cycle at any time by pressing and holding the button for 2 seconds. PRE-COOLING This is a refrigeration cycle of infinite life that can precede all operating cycles. Access the menu special cycles from key and select pre-coolin.
- Page 15 Example of reducing cycle at a temperature (skewer), addition of hard phase, quick change of setpoint chamber for the phase and soft start cycle. Example of deep freezing cycle at a temperature (skewer), conversion to cycle time, quick change of the duration of the freezing cycle and start cycle.
- Page 16 The preservation phase is infinite and has only completed by pressing the key for 2 seconds. The defrost cycles are always enabled during a conservation. During the execution of a cycle by pressing the key, it is possible to access advanced page where you can change the setpoint of work for the current cycle and display all the internal states of the machine.
- Page 17 The flushing cycle begins with the removal step. When the temperature detected by the needle probe reaches the temperature at end of Chilling, the device will automatically switch to the maintenance. The temperature at the end of Chilling also represents the setpoint of the work during the maintenance.
- Page 18 RECIPES The recipes are programs pre-attached ready to use that propose a series of cycles that are optimized for the type of dish. Recipes can be changed before the start of the cycle, but may not be saved or overwritten. Access the menu special cycles from key and select recipes to view the list of Chilling programs/default freezing available.
- Page 19 Quickfreezing by needle probe Step 1 Set Chamber 0°C Set needle 3°C Step 2 Set Chamber -12°C Set needle -3°C Fase 3 Set Chamber -30°C Set needle -18°C Conservation Set Chamber -20°C – ALARMS The alarms will be displayed on the Home page if the effect is to interrupt or not to activate the cycle; if they are such as to allow the continuation of the current cycle will...
- Page 20 Probe Error chamber. Remedies: Check the value of parameter P0 Check the integrity of the probe Check the connection device-probe Check the temperature of the chamber. The main consequences: If the error occurs during the status "stand-by", will not be allowed to initiate any THE CHAMBER cycle of operation PROBE...
- Page 21 Temperature alarm maximum alarm (HACCP). Remedies: Check the temperature of the chamber HIGH The main consequences: TEMPERATURE The device will store the alarm The output of the alarm will be activated. Alarm Chilling at a temperature or freezing at a temperature not concluded within the maximum duration alarm (HACCP).
- Page 22 It is essential to disconnect the appliance if you are going to clean with water. Panels should not be moved to access electrical components except by technical staff authorised to carry out maintenance and repair operations The inside of the cooler should be cleaned with great care. 8.1 PRICK PROBE (optional) It is a frequently used component.
- Page 23 Condenser cleaning: When cleaning, be careful not to bend the condenser aluminium ribs, as on the contrary the air will not come through and will not condense, causing serious damage to the appliance and its repair guarantee will be made void. ...
