- Page 1 EN User Manual | Refrigerator RTB411D1AW RTB411D2AW RTE811D1AW RTS811DXAW...
- Page 2 FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler – features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.
- Page 3 installation or usage. Always keep the instructions in a safe and accessible location for future reference. 1.1 Children and vulnerable people safety • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the...
- Page 4 – store raw meat and fish in suitable containers in the refrigerator, so that it is not in contact with or drip onto other food. • WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. •...
- Page 5 • Do not expose the appliance to the rain. • Do not install the appliance where there is The appliance contains flammable gas, direct sunlight. isobutane (R600a), a natural gas with a high • Do not install this appliance in areas that level of environmental compatibility.
- Page 6 • Concerning the lamp(s) inside this product consequences and might void the and spare part lamps sold separately: guarantee. These lamps are intended to withstand • The following spare parts will be available extreme physical conditions in household for 7 years after the model has been appliances, such as temperature, discontinued: thermostats, temperature vibration, humidity, or are intended to...
- Page 7 3.1 Dimensions Overall dimensions ¹ Overall space required in use ³ 1165 ¹ the height, width and depth of the appliance ³ the height, width and depth of the appliance without the handle including the handle, plus the space necessary for free circulation of the cooling air, plus the space necessary to allow door Space required in use ²...
- Page 8 correctly but energy consumption might increase slightly. If you have any doubts regarding where To ensure appliance's best functionality, you to install the appliance, please turn to the should not install the appliance in the place vendor, to our customer service or to the with direct sunlight.
- Page 9 10. Screw the bottom hinge on the other side of the appliance. 11. Install the rubber support on the side with no hinge. 12. Fit the door on the lower hinge making sure the hinge pin enters the door bottom hole.
- Page 10 3.5 Reversing the freezer 3. Remove the installation buckle and install compartment door it on the opposite side. WARNING! Before carrying out any operations, remove the plug from the power socket. 1. Close the freezer compartment door. Unscrew the screw of the installation button.
- Page 11 3.6 Installation of a door handle If there is a door handle provided in a bag separately, you can install it as follows: 1. Remove the screws from the holes on the side of the door. 2. Take the handle out of the bag. 3.
- Page 12 This function stops automatically after 52 hours. To freeze fresh food activate the Super You can deactivate the Super Freeze function Freeze function at least 24 hours before before its automatic end by pressing and placing the food to complete pre-freezing. holding the Control button for 3 seconds.
- Page 13 compartment or at room temperature, CAUTION! depending on the time available for this operation. In the event of accidental defrosting, for example due to a power failure, if the Small pieces may even be cooked still frozen, power has been off for longer than the directly from the freezer: in this case, cooking value shown on rating plate under "rising will take longer.
- Page 14 • Leave enough space around the food to package is swollen or wet, it might have allow air to circulate freely. not been stored in the optimal conditions • For adequate storage refer to food and defrosting may have already started. packaging label to see the shelf life of •...
- Page 15 • It is recommended to defrost the food • It is advisable not to keep the exotic fruits inside the fridge. like bananas, mangos, papayas etc. in the • Do not insert hot food inside the refrigerator. appliance. Make sure it has cooled down •...
- Page 16 7. Set the temperature regulator to obtain CAUTION! the maximum coldness and run the A temperature rise of the frozen food appliance for three hours using this packs during defrosting may shorten setting. their safe storage life. Only after this time put the food back into the Do not touch frozen goods with wet freezer compartment.
- Page 17 Problem Possible cause Solution The Super Freeze function is Refer to the "Super Freeze function" switched on. section. The compressor does not start im‐ The compressor starts after a period This is normal, no error has occur‐ mediately after pressing the "Super of time.
- Page 18 Problem Possible cause Solution Temperature cannot be set. The Super Freeze function is Switch off the Super Freeze function switched on. manually, or wait until the function deactivates automatically to set the temperature. Refer to the "Super Freeze function" section. The temperature in the appliance is The temperature is not set correctly.
- Page 19 9. NOISES SSSRRR! BRRR! CLICK! HISSS! BLUBB! 10. TECHNICAL DATA The technical information is situated in the It is also possible to find the same information rating plate on the internal side of the in EPREL using the link https://eprel.ec.europa.eu and the model appliance and on the energy label.
- Page 20 12. ENVIRONMENTAL CONCERNS appliances marked with the symbol with Recycle materials with the symbol . Put the the household waste. Return the product to packaging in relevant containers to recycle it. your local recycling facility or contact your Help protect the environment and human municipal office.
- Page 24 804182747-B-222023...
