  • Page 1 trusted dependable most name projector lamp sales. http://www.myprojectorlamps.com http://www.myprojectorlamps.ca http://www.myprojectorlamps.eu The following projector manual has not been modified or altered in any way.
  • Page 2 38-VIV202-01 MODEL User's Manual...
  • Page 3 TO THE OWNER Before operating this projector, read this manual thoroughly and operate the projector properly. This projector provides many convenient features and functions. Operating the projector properly enables you to manage those features and maintains it in better condition for a considerable time. Improper operation may result in not only shortening the product-life, but also malfunctions, fire hazard, or other accidents.
  • Page 4 SAFETY INSTRUCTIONS All the safety and operating instructions should be read before This projector should be operated only from the type of power the product is operated. source indicated on the marking label. If you are not sure of the type of power supplied, consult your authorized dealer or Read all of the instructions given here and retain them for later local power company.
  • Page 5 Model Number : 38-VIV202-01 Trade Name : Christie Responsible party : CHRISTIE DIGITAL SYSTEMS, Inc. Address : 10550 Camden Drive Cypress, CA 90630 USA Telephone No. : (714) 236-8610 AC POWER CORD REQUIREMENT The AC Power Cord supplied with this projector meets the requirement for use in the country you purchased it.
  • Page 6 TABLE OF CONTENTS FEATURES AND DESIGN COMPUTER MODE SELECTING INPUT SOURCE SELECTING COMPUTER SYSTEM PREPARATION PC ADJUSTMENT AUTO PC ADJUSTMENT NAME OF EACH PART OF PROJECTOR MANUAL PC ADJUSTMENT COMPATIBLE COMPUTER SPECIFICATIONS SETTING-UP PROJECTOR PICTURE IMAGE ADJUSTMENT CONNECTING AC POWER CORD IMAGE LEVEL SELECT POSITIONING PROJECTOR IMAGE LEVEL ADJUSTMENT...
  • Page 7 FEATURES AND DESIGN This Multimedia Projector is designed with most advanced technology for portability, durability, and ease of use. This projector utilizes built-in multimedia features, a palette of 16.77 million colors, and matrix liquid crystal display (LCD) technology. Compact Design Digital Zoom (for Computer) This projector is extremely compact in size and weight.
  • Page 8 PREPARATION NAME OF EACH PART OF PROJECTOR FRONT OF CABINET TOP CONTROLS AND INDICATORS PROJECTION LENS AIR INTAKE VENT INFRARED LENS COVER REMOTE RECEIVER SPEAKERS BACK OF CABINET INFRARED POWER CORD REMOTE RECEIVER EXHAUST VENT CONNECTOR HOT AIR EXHAUSTED ! Air blown from exhaust vent is hot.
  • Page 9 PREPARATION SETTING-UP PROJECTOR CONNECTING AC POWER CORD This projector uses nominal input voltages of 100-120 V or 200-240 V AC. This projector automatically selects the correct input voltage. It is designed to work with single-phase power systems having a grounded neutral conductor. To reduce risk of electrical shock, do not plug into any other type of power system.
  • Page 10 PREPARATION POSITIONING PROJECTOR This projector is designed to project on a flat ROOM LIGHT projection surface. The brightness in a room has a great influence The projector can be focused from 4.6’ (1.4m) ~ 47.3’ on picture quality. It is recommended to limit (14.4m).
  • Page 11 PREPARATION ADJUSTABLE FEET Picture tilt and projection angle can be adjusted by rotating the ADJUSTABLE FEET. Projection angle can be adjusted to 10.5 degrees. Lift the front of the projector and pull FEET LOCK LATCHES on both sides of the projector. Release FEET LOCK LATCHES to lock ADJUSTABLE FEET and rotate ADJUSTABLE FEET to fine tune position and tilt.
  • Page 12 CONNECTING PROJECTOR TERMINALS OF PROJECTOR This projector has input and output terminals on its back for connecting computers and video equipment. Refer to figures on pages 11 to 13 and connect properly. COMPUTER INPUT TERMINALS (DIGITAL/ANALOG) COMPUTER AUDIO INPUT (1 and 2) JACKS Connect the computer (digital/analog) output to one of these terminals.
  • Page 13 CONNECTING PROJECTOR CONNECTING TO COMPUTER Cables used for connection ( = Cable or adapter is not supplied with this projector.) • VGA Cable (HDB 15 pin) • USB Cable • DVI-Digital Cable (for Single Link T.M.D.S.) • MAC Adapter (When connecting to Macintosh computer) •...
  • Page 14 CONNECTING PROJECTOR CONNECTING TO VIDEO EQUIPMENT Cables used for connection ( = Cable is not supplied with this projector.) • Video Cable (RCA x 1 or RCA x 3) • BNC Cable • S-VIDEO Cable • Audio Cable (RCA x 2) Video Source (example) Component video output equipment.
  • Page 15 BEFORE OPERATION OPERATION OF REMOTE CONTROL Left Side LASER POINTER INDICATOR POWER ON-OFF BUTTON Lights red while laser beam Used to turn projector on or is emitted from Laser Light off. (P19) ON-OFF Window. INPUT 1/2 BUTTON ZOOM FOCUS VOLUME Used to select input source either INPUT 1 or INPUT 2.
  • Page 16 BEFORE OPERATION Operating Range ON-OFF ZOOM BUTTON Point Remote Control Unit toward Used to adjust zoom. projector (Receiver Window) (P20) ZOOM FOCUS VOLUME VOLUME BUTTON whenever any button is pressed. Maximum operating range for Used to adjust volume. (P21) Remote Control Unit is about 16.4’ (5m) and 60°...
  • Page 17 BEFORE OPERATION TOP CONTROLS AND INDICATORS This projector has CONTROL BUTTONS (TOP CONTROLS) and INDICATORS on its top. LAMP REPLACE INDICATOR WARNING TEMP. INDICATOR READY INDICATOR LAMP INDICATOR Turns yellow when the Flashes when Lights green when the Becomes dim when the life of the projection internal projector...
  • Page 18 OPERATING ON-SCREEN MENU HOW TO OPERATE ON-SCREEN MENU You can control and adjust this projector through the ON-SCREEN WIRELESS REMOTE CONTROL MENU. Refer to the following pages to operate each adjustment POINT BUTTON on the ON-SCREEN MENU. Used to move the Pointer UP/ DOWN/ RIGHT/ LEFT.
  • Page 19 BEFORE OPERATION MENU BAR FOR PC SOURCE Press MENU BUTTON while connecting to PC input source. IMAGE SELECT MENU SCREEN MENU SETTING MENU Used to select Used to adjust size Used to change GUIDE WINDOW PC SYSTEM MENU image level among of image.
  • Page 20 BEFORE OPERATION TURNING ON / OFF PROJECTOR TURNING ON THE PROJECTOR Complete peripheral connections (with Computer, VCR, etc.) before turning on projector. (Refer to "CONNECTING TO PROJECTOR" on pages 11~13 for connecting that equipment.) Connect the projector's AC Power Cord into an AC outlet. LAMP Indicator lights RED, and READY Indicator lights GREEN.
  • Page 21 BASIC OPERATION ADJUSTING SCREEN ZOOM ADJUSTMENT Press ZOOM button on Top Control or ZOOM button on Remote Control Unit. Message “Zoom” is displayed. Press ZOOM button or POINT UP button to make image Zoom larger, and press ZOOM button or POINT DOWN button to make image smaller.
  • Page 22 BASIC OPERATION PICTURE FREEZE FUNCTION Press FREEZE button on Remote Control Unit to freeze the picture on-screen. To cancel FREEZE function, press FREEZE button again or press any other button except the POINT, SELECT, RIGHT CLICK, P-TIMER and LASER buttons. NO SHOW FUNCTION Press NO SHOW button on Remote Control Unit to black out the No show...
  • Page 23 COMPUTER INPUT SELECTING INPUT SOURCE INPUT 1/2 button INPUT buttons DIRECT OPERATION INPUT 1 Select INPUT source by pressing INPUT 1/2 and INPUT 3 INPUT 1 buttons on Remote Control Unit. INPUT 2 INPUT 2 Select INPUT source by pressing INPUT button on Top INPUT 3 button Control.
  • Page 24 COMPUTER INPUT AUTOMATIC MULTI-SCAN SYSTEM This projector automatically tunes to most different types of computers based on VGA, SVGA, XGA or SXGA (refer to “COMPATIBLE COMPUTER SPECIFICATIONS” on page 26). When selecting Computer, this projector automatically tunes to incoming signal and projects proper image without any special setting. (Some computers need setting manually.) Note : Projector may display one of following messages.
  • Page 25 COMPUTER INPUT MANUAL PC ADJUSTMENT This projector can automatically tune to the display signals from most personal computers currently distributed. However, some computers employ special signal formats which are different from the standard ones and may not be tuned by the Multi-Scan system of this projector.
  • Page 26 COMPUTER INPUT Display area Selects area displayed with this projector. Select the resolution in the Display area dialog box. Press SELECT button at Display area icon and Display Display area H area dialog box appears. Adjustment of horizontal area displayed with this projector. Press Display area POINT LEFT/RIGHT button(s) to decrease/increase value and then press SELECT button.
  • Page 27 COMPUTER INPUT COMPATIBLE COMPUTER SPECIFICATIONS Basically this projector can accept a signal from all computers with V, H-Frequency mentioned below and less than 160 MHz of Dot Clock. ON-SCREEN H-Freq. V-Freq. ON-SCREEN H-Freq. V-Freq. RESOLUTION RESOLUTION DISPLAY (kHz) (Hz) DISPLAY (kHz) (Hz) VGA 1...
  • Page 28 COMPUTER INPUT PICTURE IMAGE ADJUSTMENT IMAGE LEVEL SELECT (DIRECT) Select image level among Standard, Real, Image 1, Image 2, Image 3 IMAGE button and Image 4 by pressing IMAGE button on Top Control or on Remote Standard Control Unit. Real Standard Normal picture level preset on this projector.
  • Page 29 COMPUTER INPUT IMAGE LEVEL ADJUSTMENT Press MENU button and ON-SCREEN MENU will appear. Press IMAGE ADJUST MENU POINT LEFT/RIGHT buttons to move the red frame pointer to IMAGE ADJUST Menu icon. Press POINT DOWN button to move the red frame pointer to the IMAGE ADJUST item that you want to adjust and then press SELECT button.
  • Page 30 COMPUTER INPUT PICTURE SCREEN ADJUSTMENT This projector has a picture screen resize function, which enables you to display the desirable image size. Press MENU button and ON-SCREEN MENU will appear. Press SCREEN MENU POINT LEFT/RIGHT button(s) to move the red frame pointer to SCREEN Menu icon.
  • Page 31 VIDEO INPUT SELECTING INPUT SOURCE WHEN SELECT INPUT 2 (5 BNC INPUT JACKS ) When connecting to those equipment, select a type of Video INPUT MENU source in SOURCE SELECT Menu. Press MENU button and ON-SCREEN MENU will appear. Press INPUT Menu icon POINT LEFT/RIGHT button to move the red frame pointer to Move the pointer (red arrow)
  • Page 32 VIDEO INPUT SELECTING VIDEO SYSTEM Press MENU button and ON-SCREEN MENU will appear. Press POINT LEFT/RIGHT buttons to move the red frame pointer to AV SYSTEM Menu icon. Press POINT DOWN button to move the red arrow pointer to system that you want to select and then press SELECT button. VIDEO JACK OR S-VIDEO JACK AV SYSTEM MENU (VIDEO OR S-VIDEO) Auto...
  • Page 33 VIDEO INPUT PICTURE IMAGE ADJUSTMENT IMAGE LEVEL SELECT (DIRECT) Select image level among Standard, Cinema, Image 1, Image 2, IMAGE button Image 3 and Image 4 by pressing IMAGE button on Top Control or on Standard Remote Control Unit. Cinema Standard Normal picture level preset on this projector.
  • Page 34 VIDEO INPUT IMAGE LEVEL ADJUSTMENT Press MENU button and ON-SCREEN MENU will appear. Press IMAGE ADJUST MENU POINT LEFT/RIGHT button(s) to move the red frame pointer to IMAGE ADJUST Menu icon. Press POINT DOWN button to move the red frame pointer to the IMAGE ADJUST item you want to adjust and then press SELECT button.
  • Page 35 VIDEO INPUT Store To store adjustment data, move the red frame pointer to Store icon and press SELECT button. Image Level Menu will appear. Move the red frame pointer to Image Level 1 to 4 and then press SELECT button. Image Level Menu Other icons operate as follows.
  • Page 36 SETTING SETTING MENU Press MENU button and ON-SCREEN MENU will appear. Press SETTING MENU POINT LEFT/RIGHT button(s) to move the red-frame pointer to SETTING icon. Press POINT DOWN button to move the red-frame pointer to the Set the red frame SETTING Menu icon item you want to set and then press SELECT button.
  • Page 37 SETTING Power management This function turns Projection Lamp off when this projector detects signal interruption and is not used for a certain period in order to reduce power consumption and maintain Lamp-life. (This projector is shipped with this function ON.) Time left until Lamp off.
  • Page 38 SETTING/APPENDIX This Projector is equipped with an USB port for interactive operation between the projector and a computer. Set the mode following the steps below. Press the SELECT button at this Wireless Mouse mode icon to display previous items. Select " "...
  • Page 39 APPENDIX MAINTENANCE WARNING TEMP. INDICATOR WARNING TEMP. Indicator flashes red when the internal temperature of the projector exceeds the normal temperature. This Indicator stops flashing when the temperature of the projector returns to normal. When WARNING TEMP. Indicator continues to flash, check items listed below. Ventilation Slots of the projector may be blocked.
  • Page 40 APPENDIX LAMP REPLACEMENT When the life of the Projection Lamp of this projector draws to an end, LAMP REPLACEMENT indicator lights yellow. When a projected image becomes dark or the color of an image becomes unnatural, replacement of Projection Lamp is required. CAUTION CAUTION For continued safety, replace with a lamp...
  • Page 41 APPENDIX TROUBLESHOOTING Before calling your dealer or service center for assistance, check matters below once again. 1. Make sure you have connected the projector to your computer or video equipment as described in section "CONNECTING PROJECTOR" on pages 11 ~ 13. 2.
  • Page 42 You can often correct operating problems yourself. If the projector fails to work properly, see the "TROU- BLESHOOTING" section on pages 40 and 41. If after following all operating instructions, you find that service is necessary, contact the Christie Service Station or store where you purchased the unit.
  • Page 43 APPENDIX TECHNICAL SPECIFICATIONS Projector Type Multi-media Projector Dimensions (W x H x D) 12.6" x 6.6" x 16.8" (319 mm x 168 mm x 429.5 mm) Net Weight 17.4 lbs (7.9 kg) LCD Panel System 1.3" TFT Active Matrix type, 3 panels Panel Resolution 1024 x 768 dots Number of Pixels...
  • Page 44 APPENDIX CONFIGURATIONS OF TERMINALS COMPUTER INPUT-1 TERMINAL (ANALOG) Terminal : HDB15-PIN Connect the display output terminal of the computer to this terminal with the VGA Cable (supplied). When connecting the Macintosh computer, the MAC Adapter (supplied) is required. Pin Configuration Red Input +5V Power Green Input...
  • Page 45 Printed in Japan Part No. 10-A 610 299 6975 (1AA6P1P3325-- MB8K)

This manual is also suitable for:

38-viv202-01
