- Page 1 Air Conditioners Indoor unit PLA-M·EA-A Series OPERATION MANUAL FOR USER English is original. English For safe and correct use, please read this operation manual thoroughly before operating the air-conditioner unit.
- Page 2 Contents 1. Safety Precautions ........1 5.
- Page 3 1. Safety Precautions Warning: • W hen installing or relocating, or servicing the air conditioner, use only • D o not use means to accelerate the defrosting process or to clean, the specified refrigerant written on outdoor unit to charge the refriger- other than those recommended by the manufacturer. • T he appliance shall be stored in a room without continuously operat- ant lines. Do not mix it with any other refrigerant and do not allow air to remain in the lines. ing ignition sources (for example: open flames, an operating gas appli- ance or an operating electric heater). I f air is mixed with the refrigerant, then it can be the cause of abnormal high pressure in the refrigerant line, and may result in an explosion • D o not pierce or burn.
- Page 4 2. Parts Names ■ Indoor Unit Filter PLA-M·EA Series Air outlet Fan steps 4 steps Vane Auto with swing Louver Not available Filter Long-life Filter cleaning indication 2,500 hr Vane Air intake Wireless remote controller model No. setting ■ Wired Remote Controller The functions of the function buttons change depending on the screen. Controller interface Refer to the button function guide that appears at the bottom of the LCD for the functions they serve on a given screen.
- Page 5 2. Parts Names Display The main display can be displayed in two different modes: “Full” and “Basic”. The factory setting is “Full”. To switch to the “Basic” mode, change the setting on the Main display setting. (Refer to operation manual included with remote controller.) <Full mode>...
- Page 6 2. Parts Names ■ Outdoor unit Power Ref. Pipes Indoor-Outdoor Connection wire Earth Service Panel Notes (Only for wireless remote controller): Battery installation/replacement When using the wireless remote controller, point it towards the receiver on the indoor unit. If the remote controller is operated within approximately 3 minutes after power is supplied to 1.
- Page 7 3. Operation ■ About the operation method, refer to the operation manual that comes with each remote controller. 3.1. Turning ON/OFF [ON] [OFF] Press the [ON/OFF] button. Press the [ON/OFF] button again. The ON/OFF lamp will light up in green, The ON/OFF lamp will come off, and and the operation will start. the operation will stop. When “LED lighting” is set to “No,” the ON/OFF lamp will not light up.
- Page 8 3. Operation 3.3. Temperature setting 3.5. Airflow direction setting <Cool, Dry, Heat, and Auto> 3.5.1 Navigating through the Main menu <Accessing the Main menu> Press the [MENU] button on the Main Main menu Main display. 28.5 Room Room The Main menu will appear. Cool Set temp. Auto Cool Set temp. Auto Operation Mode Temp. Mode Temp. Example display (Centigrade in 1-degree increments) Press the [F2] button to decrease the preset temperature, and press the [F3] button to increase.
- Page 9 3. Operation 3.5.2 Vane·Vent. (Lossnay) <3D i-see Sensor not supported> <Accessing the menu> Select “Operation” from the Main Main Main menu Swing menu (refer to 3.5.1), and press the [SELECT] button. Operation Vert Horiz Vent. 3D i-see Sensor setting Select “Vane·Louver·Vent. Operation This setting cannot be made when the 3D i-see Sensor function is not (Lossnay)”...
- Page 10 3. Operation ■ Notes: Manual vane angle (Vertical air direction) (Wired remote controller) During swing operation, the directional indication on the screen ● Select “Comfort” from the Operation does not change in sync with the directional vanes on the unit. Operation menu, and press the [SELECT] but- Vane·Louver·Vent. (Lossnay) Available directions depend on the type of unit connected. ● High power ton. In the following cases, the actual air direction will differ from the ● Comfort direction indicated on the remote controller display. 1. While the display is in “Standby” or “Defrost” states. Main menu: 2. I mmediately after starting heat mode (while the system is wait- Cursor ing for the mode change to take effect). 3. I n heat mode, when room temperature is higher than the tem- perature setting.
- Page 11 3. Operation The current vane setting will appear. Select “Manual vane angle” with the Manual vane angle Comfort [F1] or [F2] button, and press the Manual vane angle 3D i-See sensor Select the desired outlets from “1,” [SELECT] button. “2,” “3,” “4,” or “1, 2, 3, 4 (all outlets)” with the [F1] or [F2] button.
- Page 12 3. Operation ■ 3.6. 3D i-see Sensor setting Confirmation procedure (wired remote controller) Note: 1 First, confirm by setting “Ref. Manual vane angle This function cannot be set depending on the outdoor unit to be address” to 0 and “Unit No.” to 1. Ref. address Unit No. • Move the cursor to “Ref. address” connected.
- Page 13 3. Operation 3.6.2 Air distribution 3.6.3 Energy saving option 1 Move the cursor to “Ref. address” 1 Select the desired menu with the Air distribution Energy saving option or “Unit No.” with the [F1] button [F1] or [F2] button. Ref. address No occupancy energy save Unit No.
- Page 14 3. Operation Notes: 3.6.4 Seasonal airflow function Any person at the following places cannot be detected. 1 Select the setting with the [F4] Seasonal airflow ● Along the wall on which the air conditioner is installed button. Seasonal airflow ● Directly under the air conditioner OFF → Cooling only → Heating ● Where any obstacle, such as furniture, is between the person and Cooling/Heating only → Cooling/Heating → OFF… the air conditioner A person may not be detected in the following situations. Select: After changing the setting, press ● Room temperature is high.
- Page 15 6. Care and Cleaning ■ Filter information will appear on the Main display When the is displayed on the in the Full mode when it is time to Main display in the Full mode, the clean the filters. system is centrally controlled and Room Room the filter sign cannot be reset.
- Page 16 7. Trouble Shooting Having trouble? Here is the solution. (Unit is operating normally.) Air conditioner does not heat or cool well. ■ Clean the filter. (Airflow is reduced when the filter is dirty or clogged.) ■ Check the temperature adjustment and adjust the set temperature. ■...
- Page 17 7. Trouble Shooting Having trouble? Here is the solution. (Unit is operating normally.) ■ The indoor operation sound level is affected by the acoustics of the Noise is louder than specifications. particular room as shown in the following table and will be higher than the noise specification, which was measured in anechoic room.
- Page 18 8. Specifications ■ PLA-M·EA Series Model M100 M125 M140 Power source <V / Hz> ~/N 230/50, 230/60 ∙ Voltage/Frequency Rated Input <kW> 0.04/0.04 0.07/0.07 0.10/0.10 0.10/0.10 ∙ Cooling/Heating indoor only Rated Current <A> 0.27/0.25 0.46/0.44 0.66/0.64 0.66/0.64 ∙ Cooling/Heating indoor only Heater <kW>...
- Page 22 Software Information This product includes open source software (“OSS”) distributed under the terms of open source licenses. Apache License Version 2.0, January 2004 http://www.apache.org/licenses/ TERMS AND CONDITIONS FOR USE, REPRODUCTION, AND DISTRIBUTION 1. Definitions. “License” shall mean the terms and conditions for use, reproduction, and distribution as defined by Sections 1 through 9 of this document. “Licensor” shall mean the copyright owner or entity authorized by the copyright owner that is granting the License. “Legal Entity”...
- Page 23 APPENDIX: How to apply the Apache License to your work. To apply the Apache License to your work, attach the following boilerplate notice, with the fields enclosed by brackets “{}” replaced with your own identifying information. (Don’t include the brackets!) The text should be enclosed in the appropriate comment syntax for the file format. We also recommend that a file or class name and description of purpose be included on the same “printed page” as the copyright notice for easier identification within third-party archives. Copyright {yyyy} {name of copyright owner} Licensed under the Apache License, Version 2.0 (the “License”); you may not use this file except in compliance with the License. You may obtain a copy of the License at http://www.apache.org/licenses/LICENSE-2.0 Unless required by applicable law or agreed to in writing, software distributed under the License is distributed on an “AS IS” BASIS, WITHOUT WARRANTIES OR CONDI- TIONS OF ANY KIND, either express or implied.
- Page 24 This product is designed and intended for use in the residential, commercial and light-industrial environment. Please be sure to put the contact address/telephone number on this manual before handing it to the customer. HEAD OFFICE: TOKYO BUILDING, 2-7-3, MARUNOUCHI, CHIYODA-KU, TOKYO 100-8310, JAPAN VG79N451H01 Printed in Thailand...
