Philips 27B2U6903 User Manual
Philips 27B2U6903 User Manual

Philips 27B2U6903 User Manual

Business monitor

Advertisement

Quick Links

Business
Monitor
6000 Series
EN
User manual
Customer care and warranty
Troubleshooting and FAQs
Register your product and get support at www.philips.com/welcome
27B2U6903
1
33
37

Advertisement

loading
Need help?

Need help?

Do you have a question about the 27B2U6903 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Philips 27B2U6903

  • Page 1 Business Monitor 6000 Series 27B2U6903 User manual Customer care and warranty Troubleshooting and FAQs Register your product and get support at www.philips.com/welcome...
  • Page 2 Table of Contents 1. Important �����������������������������������������1 11.1 Philips’ Flat Panel Displays Pixel Defect Policy ......... 33 1.1 Safety precautions and 11.2 Customer Care & Warranty ..36 maintenance ........1 1.2 Notational Descriptions ....3 1.3 Disposal of product and packing 12� Troubleshooting & FAQs ����������� 37 material ..........4...
  • Page 3 This electronic user’s guide is intended electronics. for anyone who uses the Philips monitor. Take time to read this user manual • Do not block the ventilation holes in before you use your monitor. It contains the cabinet.
  • Page 4 • Do not knock or drop the • Oil-based cleaning solutions may monitor during operation and/or damage the plastic parts and void the transportation. warranty. • The USB Type-C port could only be • Unplug the monitor if you are not connected to specify equipment with going to use it for an extensive period.
  • Page 5 1.2 Notational Descriptions also known as “after-imaging” or “ghost imaging”, on your screen. The following subsections describe the • “Burn-in”, “after-imaging”, or notational conventions used in this “ghost imaging” is a well-known document. phenomenon in LCD panel Notes, Cautions, and Warnings technology.
  • Page 6 From the planning, design, and production stages, Philips emphasizes the importance of making products that can easily be recycled. At Philips, end-of-life management primarily This marking on the product or its entails participation in national take- packaging illustrates that, under...
  • Page 7 Package contents Business Monitor 6000 Series 27B2U6903 Quick Start Register your product and get support at www.philips.com/welcome 2. Hold the stand with both hands. (1) Gently attach the base to the Power stand. (2) Use your fingers to tighten the...
  • Page 8 Power Switch installation is complete. AC power input RJ45 driver installation HDMI 1 input You can find the “LAN Drivers” from HDMI 2 input Philips website support page. DisplayPort input Please follow the steps for the Thunderbolt 4 input installation: Thunderbolt 4 output 1.
  • Page 9 Some selected Philips displays may not your system. Power or Charge your device when it 2. Double click driver to install, and enters “Sleep/Standby” mode (White follow Window’s instructions to power LED blinking). In that case, please proceed with installation.
  • Page 10 2.2 Operating the monitor Customize your own “USER” key This hot key allows you to setup your Description of the control buttons favorite function key. 1. Press button on the front bezel to enter OSD Menu Screen.    ...
  • Page 11 What is On-Screen Display (OSD)? LightSensor On-Screen Display (OSD) is a feature in all 1, 2, 3, 4 LowBlue Mode Philips LCD monitors. It allows an end user Input 1 HDMI 2.0 to adjust screen performance or select 2 HDMI 2.0 DisplayPort...
  • Page 12 The over-the-air (OTA) firmware update is through the SmartControl software 150mm and is easily downloadable through the Philips website. What does SmartControl do? It is an additional software that helps control the photo, audio, and the Warning other on-screen graphic settings of the •...
  • Page 13 2.3 MultiClient Integrated KVM 2. Enter the On-Screen Display (OSD) menu. Go to the KVM tab and select What is it? “Auto”, “Thunderbolt”, or “USB C” to switch the monitor view from With the Multiclient Integrated one device to another. To switch to Keyboard Video Mouse (KVM) switch another monitor view, simply repeat feature, it is possible to control two...
  • Page 14 it to the HDMI or DP port on the control two PCs via the On-Screen monitor for viewing video and Display (OSD) menu setting. audio content. PC2: You can use a USB-C/A cable in direction upstream and a HDMI cable or a DP cable and connect it to the HDMI or DP port on the monitor for viewing video and audio content.
  • Page 15 4. Press ▲ or ▼ button to select [PIP] Why do I need it? or [PBP]. With the ultra-high-resolution Philips 5. Now you can move backward to set MultiView display, you can comfortably the [PIP / PBP Input], [PIP Size], [PIP experience a world of connectivity in Position], or [Swap].
  • Page 16 [PBP]: Picture by Picture • PIP Position: When PIP is activated, there are four sub-window positions Open up a sub-window to choose from. side-by-side of another (main) Top-Left Top-Right signal source. When the sub source is not detected: (main) (main) (main) Note The black strip located on the top...
  • Page 17 2.5 Remove the Base Assembly Note This monitor accepts a 100mm x 100mm for VESA Mounting VESA-Compliant mounting interface. Before you start disassembling VESA Mounting Screw M4. Always the display base, please follow the contact the manufacturer for wall- instructions below to avoid any possible mount installation.
  • Page 18 EasyRead, Office, Photo, Movie, in real-time. Whether you're working Game, Economy, LowBlue Mode, with text applications, displaying images, SmartUniformity and Off. or watching a video, Philips SmartImage delivers great monitor performance.  Why do I need it?  It is ideal to have a monitor that delivers ...
  • Page 19 Off: No optimization by SmartImage. photos and other images with outstanding clarity in vibrant colors Note - all without artifacts and faded Philips LowBlue mode, mode 2 colors. compliance with TUV eyesafe, you can have this mode by simply press •...
  • Page 20 3.3 LightSensor What is it? Light Sensor is a unique and intelligent way of optimizing picture quality by measuring and analyzing the incoming signal to automatically adjust picture quality settings. Light Sensor uses a sensor to adjust the picture brightness depending on the room light conditions.
  • Page 21 Thunderbolt or USB C-A cable, introduction your monitor screen probably show as the extend screen. To call out the main screen on your monitor, hold the Philips Thunderbolt docking monitors deliver universal port replication, Windows key and press P twice.
  • Page 22 • Reposition your screen to the appropriate measurment syndrome (CVS) according to your own height. 4. Choose a Philips monitor for viewing Philips monitor is designed to prevent that is easy on the eyes. eye strain caused by prolonged • Anti-glare screen: This feature computer use.
  • Page 23 which are not; and how to set the display to these modes. • Port used1.1.1.5: In case the port used for ‘low blue light’ mode differs from the port used for testing, the user manual shall describe which port shall be use.
  • Page 24 6. PowerSensor 2 User present in front User not present This monitor is equipped with the PowerSensor 2 feature that reduces energy consumption by detecting when users move closer and further away from the screen. Power consumption as illustrated above is for reference purpose only As both the PowerSensor and PowerSensor 2 aim to save energy, the main difference is in the OSD...
  • Page 25 Hot key    Sensor distance (for selected models  only)           This image shows the settings to change from the monitor's Landscape/Portrait mode OSD menu. Note • A manually selected PowerSensor mode will remain operational unless and until it is readjusted.
  • Page 26 7. Daisy-chain function Thunderbolt™ 4 supports Daisy Chain. If your laptop /Desktop/Display Monitor supports Thunderbolt™ 4, you can use Thunderbolt™ 4 for multi-screen connections (Daisy Chain). To daisy-chain monitors, first to check below: 1. Connect the Thunderbolt™ 4 cable to the Thunderbolt input port on the first monitor and to your PC.
  • Page 27 8. Adaptive Sync AMD Radeon R7 260X • AMD Radeon R7 260 • Processor A-Series Desktop and • Mobility APUs Adaptive Sync AMD A10-7890K • AMD A10-7870K • PC gaming has long had an imperfect AMD A10-7850K • experience because GPUs and monitors update at different rates.
  • Page 28 9. Technical Specifications Picture/Display Display Panel Type Backlight W-LED Panel Size 27" W (68.6 cm) Aspect Ratio 16:9 Pixel Pitch 0.1554 (H) mm x 0.1554 (V) mm Contrast ratio(typical) 1000:1 Native Resolution 3840 x 2160 @60Hz Maximum Resolution 3840 x 2160 @60Hz Viewing Angle 178°...
  • Page 29 Thunderbolt 4 (input) (upstream, DisplayPort Alt mode, Thunderbolt HDCP 2.2/ HDCP 1.4, PD 96W) Thunderbolt 4 (output) (downstream, PD 15W) USB-C1 x1 (upstream, DATA) USB Ports USB-C2 x1 (downstream, PD 15W) USB-A x4 (downstream with x1 fast charge B.C 1.2) Thunderbolt 4 (input): USB PD version 3.0, up to 96W (5V/3A, 7V/3A, 9V/3A, 10V/3A, 12V/3A, 15V/3A,...
  • Page 30 1.54 BTU/ Sleep (Standby mode) 1.54 BTU/hr(typ.) 1.54 BTU/hr(typ.) hr(typ.) 1.37 BTU/ Off mode 1.37 BTU/hr(typ.) 1.37 BTU/hr(typ.) hr(typ.) Off mode(AC switch) 0 BTU/hr(typ.) 0 BTU/hr(typ.) 0 BTU/hr(typ.) On Mode(ECO mode) 20.9 W (typ.) PowerSensor 8.5 W (typ.) Power LED indicator On mode: White, Standby/Sleep mode: White (blinking) Power Supply Built-in, 100-240V AC, 50/60Hz...
  • Page 31 3. SmartUniformity and Delta E information are included in the sheets located in the box. 4. In order to update the monitor’s firmware to the latest version, Please download the SmartControl software from Philips website. It is necessary to be connected to a network when updating the firmware on SmartControl over-the-air (OTA).
  • Page 32 9.1 Resolution & Preset Modes to Thunderbolt 4 or DP port, please adjust resolution to the optimal state: 3840 x 2160 @60 Hz from your PC. H. freq Resolution V. freq (Hz) 2. The factory default setting HDMI (kHz) supports to the resolution 3840 x 31.47 720x400 70.09...
  • Page 33 Video Bandwidth Host Video Cable Resolution USB-C Gen1 Cable USB-C Thunderbolt 3 Cable (40G) 3840x2160@60Hz (Alt Mode DP1.2) Thunderbolt 4 Cable (40G) USB-C Gen1 Cable USB-C Thunderbolt 3 Cable (40G) 3840x2160@60Hz with HDR (Alt Mode DP1.4) Thunderbolt 4 Cable (40G) USB-C Gen1 Cable Thunderbolt Thunderbolt...
  • Page 34 10. Power Management If you have a VESA DPM compliance display card or software installed on your PC, the monitor can automatically reduce its power consumption when not in use. If an input from a keyboard, mouse, or other input device is detected, the monitor will 'wake up' automatically.
  • Page 35 Other Pixel Defect Policy combinations of lit and dark sub-pixels appear as single pixels of other colors. Philips strives to deliver the highest quality products. We use some of the Types of Pixel Defects industry's most advanced manufacturing...
  • Page 36 Note A red or bright blue dot must be period, a TFT Monitor panel in a Philips more than 50 percent brighter than flat panel monitor must have pixel neighboring dots, while a bright...
  • Page 37 BRIGHT DOT DEFECTS ACCEPTABLE LEVEL 1 lit subpixel 2 adjacent lit subpixels 3 adjacent lit subpixels (one white pixel) Distance between two bright dot defects* >15mm Total bright dot defects of all types BLACK DOT DEFECTS ACCEPTABLE LEVEL 1 dark subpixel 3 or fewer 2 adjacent dark subpixels 2 or fewer...
  • Page 38 Please contact our Philips Customer Service Representative or local contact center (by Consumer care number) for more details. Philips Customer Care Center number listed below.
  • Page 39 Disconnect the monitor from the be corrected by a user. If the problem mains power source immediately for persists after you have tried these safety solutions, contact a Philips customer • Contact Philips customer service service representative. representative immediately. Common Problems...
  • Page 40 Service contact information listed in the Important information manual What are the .inf and .icm files? and contact a Philips customer service How do I install the drivers (.inf representative. and .icm)? * Functionality is different according to Ans.: These are the driver files for...
  • Page 41 Can I connect my LCD monitor to not use other solvents such as any PC, workstation, or Mac? ethyl alcohol, ethanol, acetone, Ans.: Yes. All Philips LCD monitors are hexane, etc. fully compatible with standard PCs, Macs, and workstations. Can I change the color setting of...
  • Page 42 Ans.: Important information manual Always activate a moving screen can be downloaded on the saver program when you leave Philips website support page. your display unattended. Always activate a periodic screen Q15: Why cannot detect my monitor’s refresh application if your LCD...
  • Page 43 12.3 Multiview FAQs Can I enlarge the PIP sub- window? Ans.: Yes, there are 3 sizes to select: [Small], [Middle], [Large]. You can press to enter the OSD menu. Select your preferred [PIP Size] option from the [PIP / PBP] main menu.
  • Page 44 This product has been manufactured by and is sold under the responsibility of Top Victory Investments Ltd., and Top Victory Investments Ltd. is the warrantor in relation to this product. Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V. and are used under license.
