Logicube WriteProtect USB User Manual page 11

3.0 Quick Start Guide
To use the WriteProtect-USB, connect the following (in any order):
Connect the AC adapter to a power source, then to the WriteProtect-USB
•
Connect a network cable to the WriteProtect-USB (optional, see
•
Operation)
Connect one end of the USB 3.0 Type-A connector to the open USB Host port on the left side of
•
the WriteProtect-USB
Connect the other end of the USB 3.0 Type-A connector to an open USB port on your
•
workstation
Connect a USB drive to the open USB port on the right side of the WriteProtect-USB
•
3.1 Connected Drives
Depending on the Operating System on the computer, drives connected to the WriteProtect may or may
not be automatically mounted. Windows may automatically assign a drive letter to partitions that it can
recognize.
Logicube WriteProtect-USB User's Manual
3: Quick Start
Section 4.0 for Remote
5
