Summary of Contents for Care of Sweden CuroCell Cirrus
Page 1
CuroCell Cirrus ® Service manual 2017-04-06 Art. no service manual: 95-001053...
Page 2
3.3.1 Service repair - standard operating procedure T1 3.3.2 Service repair - standard operating procedure T2 3.3.3 Service repair - standard operating procedure T3 3.3.4 Service repair - standard operating procedure T4 4 Recommended tools Technical specifiction CuroCell Cirrus ® PUMP SPECIFICATION Model...
Page 4
2 Service instruction Instruction for all general service repairs WARNING! Unplug power cord from mains, ensure no electrical current is detected before starting to repair! Attention: Before commencing the repair please go through the following check list: Problem Solution Pump does not start Check that the power cord is connected to an approved electrical socket.
Page 5
2.1 All parts illustration 3. Front panel 4. Front panel PCB 5. Main PCB 6. Buzzer 7. Power switch 1. Timing motor and 8. Fuse control assembly 9. Power cord socket 2. Connector assembly 10. Compressor assembly Fig 2.1 1. Pressure sensor 6.
Page 7
2.2.1 Exploded view diagram Fig. 2.5 2.2.2 Bill of material Level Description Type Unit Quantity Top casing assembly; CuroCell Cirrus ® : includes top casing and controller PCB Assembly Top casing, CuroCell Cirrus ® Raw materials Controller PCB, AP02-2(A1) 230V...
Page 8
2.2.4 Service repair - standard operating procedure T1 T1 Confirm pressure range, pressure testing Connect the pump to the testing equipment according to fig 2.6. Make sure all air connections are secure. 2. Start the pump and wait for the pump to finish the start-up procedure and fill the test cells. 3.
Page 9
STEP 3: Press the comfort left/right selection button, and the power button together for 5 seconds, to enter in the calibration procedure (figure 2.8). STEP 4: When in the calibration procedure, the On/ Off LED will be lit, while the remaining LED lights should not be lit.
Page 10
2.3 Base case 2.3.1 Exploded view diagram Fig 2.12 2.3.2 Bill of material Level Part Name Part Description Quantity Chassis assembly CuroCell Cirrus ® , 230 V/50 Hz Case boss CuroCell Cirrus ® , ABS, 94V0 Power switch White frame, green bottom, with light, printed I/O, 4 PIN, for 115/230 V...
Page 11
2.3.3 Service check list General symptom encountered Standard operating procedure No Power Lead wires disconnected 2.3.4 Service repair - standard operating procedure T1 T1 Replacing blown fuse 1. Use a screwdriver and turn counter-clockwise to remove fuse from the holder. See Fig 2.13. Fig 2.13 Fig 2.14 2.
Page 13
3.2 Bill of material Level Part Name Part Description Quantity Top case assembly CuroCell Cirrus ® Case boss CuroCell Cirrus , 230 V/50 Hz ® Air outlet assembly Silicone tubing assembly CuroCell Cirrus ® compressor assembly (120V) Control Panel PCB...
Page 14
3.3.1 Service repair - standard operating procedure T1 T1 Fasten or replace with new timing motor or compressor 1. Assure the voltage supplied is correct. 2. Check the pump according to the steps in section 2.3.4, if problem encountered isn’t included perform the following check.
Page 15
4 Recommended tools NB Name Specification Pressure meter 0-150mmHg Flow meter 0-10LPM Wire cutter pliers Crimping pliers Philips screwdriver...
