  • Page 1 HEALTHBOX ® INSTALLATION & MAINTENANCE MANUAL...
  • Page 2 2.6 • Moving parts ..........................12 2.7 • Personal Protective Equipment (PPE) ..................13 2.8 • Privacy Statement ........................13 3 • General description of the Renson Healthbox Go unit ................. 14 3.1 • Operating principle ........................14 3.2 • Installation properties ........................15 3.3 •...
  • Page 3 Acoustics ..........................27 6.4 • Installing extraction valves ......................28 6.5 • Extraction of polluted air to outside ...................29 6.6 • Connecting pipes to Healthbox Go ....................29 6.7 • Connecting the Healthbox Go ....................30 6.7.1 • Healthbox Go PCB ......................30 6.7.2 • Connecting to mains voltage ..................31 6.7.3 •...
  • Page 4 Go - Installation & maintenance manual ® USER ................................40 8 • Using the Healthbox Go .......................... 41 8.1 • Using the Sense app ........................41 8.2 • Setting up WPS (Wi-Fi Protected Setup) ..................44 8.3 • XVK3 switch ..........................44 8.4 • Boost using the button on the unit ....................44 9 •...
  • Page 5 GENERAL...
  • Page 6 ® 1 • General The RENSON® Healthbox Go is a central extraction unit. Fresh air is brought in naturally via window louvres into the dry rooms. Polluted air is extracted mechanically by Healthbox Go from the humid rooms. This manual consists of 2 parts: •...
  • Page 7 Ventilation level = manual mode at 100%. Healthbox Go monitors air quality for CO2, moisture, and VOCs (odour) 24 hours a day. Here, the ventilation level is intelligently and fully automatically adjusted according to the chosen ventilation Demand management profile and according to the measured air quality.
  • Page 8 INSTALLER...
  • Page 9 2.1 • General regulations and safety regulations The unit in this packaging complies with the prescribed CE safety regulations and UK Conformity Assessment. Healthbox Go meets the legal requirements for electrical devices. Belgian General Regulations for Electrical Installations (AREI) The socket used to connect the unit to the mains voltage must comply with the provisions of the AREI.
  • Page 10 • If the power cable is damaged, it must be replaced by the manufacturer, its service representative or similarly qualified persons in order to avoid a hazard. • The Renson Healthbox Go is constructed in a way that makes it impossible to come into contact with moving or live components during normal usage and without performing specific actions.
  • Page 11 • It should not be possible to touch the ventilator with your hand. Therefore, Renson Healthbox Go must always have an air duct network connected before use. The minimum duct length is 0.5 m.
  • Page 12 • If no permanent cabling is provided and the power cable is damaged, it can only be replaced with a power cable from Renson. If this is not respected and different cabling is used, any warranty and/or liability for the poor functioning of the product will be void.
  • Page 13 • The air quality sensor data is used to display graphs (history) charts for the user. • As an installer, you are not automatically entitled to inspect the sensor data from a Renson Healthbox Go you have installed, see General Data Protection Regulation (GDPR).
  • Page 14 A door louvre can be fitted, or the bottom of the door could have a gap with a minimum airflow of 25 m3/h at 2 Pa. The Renson Healthbox Go is fitted with a sensor PCB with four sensors (RH + TEMP + VOC + CO ) that measure the interior air drawn in.
  • Page 15 Startup via the Sense app: With the Sense app, the smartphone can be used as a remote for the Healthbox Go settings. What’s more, the app offers insight into the unit’s proper functioning - it is an intuitive tool for customising the unit’s operation.
  • Page 16 ® Always provide the warranty number when you contact RENSON®, or when requesting service for your unit. Always report any complaints to the installer first. If necessary, the installer will contact the RENSON® service department. 3.6 • Warranty terms and conditions •...
  • Page 17 Healthbox Go - Installation & maintenance manual ® 4 • Material 4.1 • Disposing of the device Old electrical and electronic units often contain valuable materials. However, they also contain harmful substances that are necessary for the functioning and safety of the unit. Never dispose of the discarded unit with normal waste.
  • Page 18 Contact the supplier immediately if damage is found when opening the packaging or if it appears that the delivery is incomplete. Each packaged kit (32753) contains the following components: 1 x Healthbox Go Quick start guide Power cable 2m 3 x Aeroo valve 3 x Adaptor Ø...
  • Page 19 Healthbox Go is a mechanical extraction unit compliant with a C+ ventilation system. The fan extracts polluted air. Fresh air is supplied to the home via Invisivent window louvres into the dry rooms. As the Healthbox Go is sensor-controlled, there is neither too much nor too little ventilation. This compact & flexible ventilation unit is suitable for residential applications with a nominal ventilation demand of up to 430m³/h.
  • Page 20 Healthbox Go - Installation & maintenance manual ® 5.3 • Technical specifications 5.3.1 • Technical specifications Type of ventilation Mechanical demand-driven extraction Ventilation flow rate Total flow rate of 430 m /h at maximum pressure of 200 Pa Connection voltage 230 Vac ±10% (50 Hz, 60 Hz) Fan unit power consumption - At max.
  • Page 21 5.3.6 • Additional features Automatic fault indication Via the SENSE app Automatic software updates Provided that the Healthbox Go is connected to the internet Can be downloaded free of charge from Play Store (Android) and App Store Sense app (Apple) –...
  • Page 22 Healthbox Go - Installation & maintenance manual ® 5.3.7 • Graphs Ventilation characteristics of fan unit 10 V 475 500 Debiet Q [m³/h] Power curves fan 10 V Debiet Q [m³/h]...
  • Page 23 Healthbox Go - Installation & maintenance manual ® 5.3.8 • Dimensions and weight 96,7 74,3 4 kg 96,7...
  • Page 24 Avoid obstacles that prevent access or removal of the unit. • The Healthbox Go must not be connected an extractor hood or dryer. • The unit’s extraction should always be to outside...
  • Page 25 • Pliers • Pencil, marker for marking 6.2 • Mounting the unit Healthbox Go can be fixed to a wall/ceiling/floor with 4 suitable screws for the respective surface using the integrated mounting holes. Ensure the surface is flat. Preferably ensure vibration-free installation to a solid wall/ceiling with a minimum mass of 100 kg/m². It is recommended to use vibration-damping material between the fan unit and the installation wall.
  • Page 26 6.3 • Installing air ducts • Secure the fixed air ducts so that the Healthbox Go is not weighed down by the weight of the air ducts. • Ensure the air duct network is airtight. The Renson Easyflex pipes meet the best air-tightness class, D.
  • Page 27 The table below provides an overview of the maximum recommended air flow rates through the Renson pipe components. Please note that this table does not address pressure drops. To limit the pressure drop across the channels, the length and especially the number of bends per channel must also be limited.
  • Page 28 Healthbox Go - Installation & maintenance manual ® 6.4 • Installing extraction valves Carefully select the location (In ceiling or wall) for the extraction louvre. The idea is to position the extraction louvre as far away as possible from the supply opening as possible, so that the room is fully flushed.
  • Page 29 Reducer 33098 is a practical solution for bridging the transition from Ø125mm to Ø150 mm. 6.6 • Connecting pipes to Healthbox Go The Healthbox Go kit with Aeroo valves includes 3 adaptor rings. These rings can also be bought separately (Art.nr. 33761).
  • Page 30 Healthbox Go - Installation & maintenance manual ® 6.7 • Connecting the Healthbox Go 6.7.1 • Healthbox Go PCB External outputs Mains voltage • Mains voltage: connect to the power socket or directly to the fuse box. +12 V Dig 2 OUT...
  • Page 31 The PCB shows where to connect the L, N, and PE wires. PLEASE NOTE If Healthbox Go is connected directly to the fuse box, the latter must be fitted with a device that can disconnect the Healthbox Go from the power supply network.
  • Page 32 120% of the nominal flow rate as set. Healthbox Go will always return to its standard demand-driven operation after a period of 12 hours. The Healthbox Go operates in standard demand-driven mode if no adjustment is made to the inlet.
  • Page 33 Healthbox Go - Installation & maintenance manual ® Recess for inserting the cable gland of the supplied power cable or a preflex pipe power supply). Cut-out for the connection wires of the external inlets and outlets. Opgelet!: Patchkabels NIET gekruist aansluiten 1.5 mm max.
  • Page 34 • Ensure that the main voltage is switched (back) on. Start-up check: the Healthbox Go operating system is booted up, the LEDs show a wave pattern for 10 seconds. This shows there is effective voltage on the unit. After this, all LEDs will turn off.
  • Page 35 Healthbox Go - Installation & maintenance manual ® Press the installer button, e.g. with a screwdriver, to scroll through the sequence of different menus. The colour of the LED mode indicates which menu you are in. After pressing 4 times, the LED will turn off again and you are out of the installer menu.
  • Page 36 Healthbox Go - Installation & maintenance manual ® 7.1.3 • Adjusting the standby flow rate using the buttons Click Press the installer button twice so that a blue light flashes on the installer LED. The unit is now in the menu where you can adjust the standby flow rate.
  • Page 37 When you plug in the Healthbox Go, the device will automatically create a local Wi-Fi network that remains active for 40 minutes. This will allow you to connect your smartphone to the Healthbox Go, even if there is no internet connection at the construction site.
  • Page 38 Healthbox Go - Installation & maintenance manual ® After you install the app, you can create an account. After setting several parameters, you can adjust the flow rate via the app. This way, the smartphone with Sense app can be used as a remote control for adjusting the valves.
  • Page 39 – If the flow rate is too high, reduce the total nominal flow rate of the Healthbox Go – If the flow rate is much too low, you can increase the flow rate of the Healthbox Go somewhat right away, if it is only a little too low, continue adjusting the valves.
  • Page 40 USER...
  • Page 41 Step 2: Link the Sense app to the Healthbox Go To open the local network of the Healthbox Go so that the Sense app can connect to the Healthbox Go: Press and hold the large control button for 5 seconds. The purple installation LED will start flashing, as well as the middle LED in the LED module.
  • Page 42 Open the Sense app and add the Healthbox Go as a device. Can then connect Healthbox Go to your home network. This will allow you to monitor the air quality when you are not at home. What’s more, software updates can be installed automatically.
  • Page 43 ® Step 3: Customise how the Healthbox Go behaves The Healthbox Go “Sense” app is not only useful for managing Healthbox Go settings, it can also be used to operate it. Several functions are available: Use silent settings to reduce the flow...
  • Page 44 8.4 • Boost using the button on the unit Pressing the large control button on the Healthbox Go unit will allow you to temporarily increase the air flow rate to the maximum flow rate as set. A different time period can be set, depending on need. The more the button is pressed, the more LEDs light up, the longer the boost will last.
  • Page 45 Healthbox Go - Installation & maintenance manual ® 9 • Device malfunction In the event of a malfunction, such as a faulty sensor or a non-functioning fan, the situation will be displayed clearly: Users can identify the specific cause of the issue by consulting the Sense app. It seems this is a technical issue that requires the attention of a qualified installer.
  • Page 46 • Clean the centrifugal fan housing with a wet cloth and then dry the centrifugal housing with a dry cloth. • Assemble everything in reverse order to the description above. • Finally, switch the mains voltage to the Healthbox Go back on. After this, the system will boot up on its own.
  • Page 47 Healthbox Go - Installation & maintenance manual ® 10.2 • Window vents •The inlet louvres in the windows should be cleaned annually using a brush or vacuum cleaner. 10.3 • Living space extraction louvres The extraction louvres in the ventilated rooms should be cleaned annually. 10.4 •...
  • Page 48 The actual product may vary due to modifications to the product. Renson reserves the right to make technical modifications to the products shown. ® The most recent brochures are available for download at www.renson.eu RENSON NV • Maalbeekstraat 10 • IZ 2 Vijverdam • B-8790 Waregem ®...
