INSTALLATION INSTRUCTIONS
CTS602 LIGHT
BY NILAN
Comfort 350L/R / Comfort 350L/R Polar
Version 1.31 - 28.08.2024
M24 Comfort 350L/R_GB

Advertisement

loading
Need help?

Need help?

Do you have a question about the Comfort 350L and is the answer not in the manual?

Questions and answers

Summary of Contents for nilan Comfort 350L

  • Page 1 INSTALLATION INSTRUCTIONS CTS602 LIGHT BY NILAN Comfort 350L/R / Comfort 350L/R Polar Version 1.31 - 28.08.2024 M24 Comfort 350L/R_GB...
  • Page 2 Table of contents General information Safety ............................................. 5 Power supply ........................................5 Introduction........................................... 5 Documentation........................................ 5 Unit type ..........................................6 Product description ......................................6 Dimensional drawing (L) ....................................7 Dimensional drawing Polar (L) ..................................7 Dimensional drawing (R) ....................................8 Dimensional drawing Polar (R) ..................................
  • Page 3 Electrical connection accessories ...................................18 CTS602 Connection Box ....................................18 Functional cable ......................................18 User selection 1 and 2 (cooker hood) ................................19 Modbus ...........................................20 Fire thermostat / external fire automation system ..........................20 EM-box (damper option) ....................................21 DTBU (damper option) ....................................22 Installation of expansion PCB on CTS602 Light circuit board ......................23 External electrical pre-heating element ..............................24 Electrical after-heating element ................................25 Water after-heating element ..................................26...
  • Page 5 The instructions can be downloaded from www.nilan.dk. If you have questions regarding installation and operation of the unit after having read the instructions, please contact your nearest Nilan dealer. A list of Nilan dealers is available on www.nilan.dk. ATTENTION The unit must be started up immediately after installation and connection to the duct system.
  • Page 6 Unit type Unit type Product description Product description Comfort 250L/R / 350L/R is an energy-effi cient ventilation unit with heat recovery for residential and small commercial buildings with a ventilation requirement of up to 250/372 m Comfort 250L/R / 350L/R is a compact unit that can be placed in the attic. The 4 nozzles of the unit are located on the same side, which provides some other options in relation to the installation.
  • Page 7 Dimensional drawing (L) Dimensional drawing (L) The illustration is of a left-facing version (L). Front Left side Connections: Outdoor air Supply air Extract air Discharge air Condensate drain NB! Spouts for inlet ring Bottom All listed measurements are in mm. Dimensional drawing Polar (L) Dimensional drawing Polar (L) The illustration is of a left-facing version (L).
  • Page 8 Dimensional drawing (R) Dimensional drawing (R) The illustration is of a right-facing version (R). Front Front Right side Højre side Connections: Outdoor air Supply air Extract air Discharge air Condensate drain NB! Spouts for inlet ring Bottom Bund All listed measurements are in mm. Dimensional drawing Polar (R) Dimensional drawing Polar (R) The illustration is of a right-facing version (R).
  • Page 9 Functional block diagram Functional block diagram Connections 1: Outdoor air 2: Supply air 3: Extract air 4: Discharge air 5: Condensate drain 6: Electrical or water after-heating element connections T1 /T8 Automation T2/T7: Supply air sensor T3: Extract air sensor T4: Discharge air- and deicing sensor T1/T8: Outdoor air sensor T9: Frost protection water after-heating ele-...
  • Page 10 If you want to adjust the fan speed level in accordance with the level of use of the dwelling/building (amount of people), you can retrofi t a CO sensor. Nilan’s CO sensors calibrate automatically. On the control panel, you select the CO level you want.
  • Page 11 Fire connection box The Comfort ventilation unit has a function in its control system that can control 1-2 fi re dampers. If you want to activate this function, Nilan can supply you with a Fire Connection Box, with the following connection options: •...
  • Page 12 You can control your ventilation unit with a smartphone app via a gateway connection. Connect the Nilan Gateway to a CTS400 or a CTS602 control system. This way, a cloud connection to the unit can be established. The Gateway is available in two different versions - with either a LAN or a WiFi...
  • Page 13 Set-up Installation Positioning of the ventilation unit Positioning of the ventilation unit ATTENTION When positioning the unit, you should always consider future service and maintenance. Therefore, we recommend that fl exible connections be fi tted between the ventilation unit and the duct system so that the unit can be easily removed.
  • Page 14 It is important that the unit is mounted on a surface level. Duct connections Duct connections An inlet ring needs to be fi tted (not supplied by Nilan). 1. Use size Ø160mm inlet ring. The Polar version is delivered 2. Press the inletrings fi rmly into the ventilation nozzles.
  • Page 15 Electrical installation Electrical connections Safety Safety ATTENTION All work must be carried out by qualifi ed persons and in compliance with existing legislation and regulations. ATTENTION It is important that the power is off, if you do work to the electrical components of the unit. It is important to check that wires are not damaged or squeezed during connection and use.
  • Page 16 Nilan offers a connection cable with RJ12 plug of 15 m. It is also possible to customize a cable up to 50 m in length. A standard LAN cable is used for this.
  • Page 17 Wall bracket Wall bracket Mount the HMI panel on the wall using the integrated wall bracket. The panel should be placed in a visible spot so it is possible to change settings and to monitor warnings or alarms regarding ope- ration of the unit.
  • Page 18 If you adapt an RJ45 cable yourself, be aware that wire 8 (Brown) can become live with 12V and must not be short circuited. In Nilan’s LAN cable the wires that are not used are not connected up to the RJ45 connector. With Nilan’s LAN cable there is therefore no risk of short circuits.
  • Page 19 There you can then have a switch that is activated and the ventilation is increased e.g. for an hour before it then goes back into operation. Connection via Nilan Functional cable Green/white Green...
  • Page 20 The CTS602Light control system has open Modbus RS485 communication that allows you to communicate with and control the ventilation unit via external control systems. Please consult the software instructions and the Modbus protocol for further information on settings and registers. Connection via Nilan Functional cable Green/white Green...
  • Page 21 EM-Box (damper option) EM-box (damper option) Dimensional drawing: If it is desired to run the cooker hood over the ventilation system, it may in some cases be diffi cult to get enough air for the cooker hood. With an EM box installed and when the cooker hood is in operation, you can regulate the extraction so that less air is extracted out of the other rooms, e.g.
  • Page 22 DTBU (damper option) DTBU (damper option) If it is desired to run the cooker hood over the ventilation system, it may in some cases be diffi cult to get enough air for the cooker hood. To solve that challenge, an EM-box solution can be used. However, if there is not enough space in the installation for an EM box, you can alternatively connect a DTBU damper in the duct system, which has the same function, except that it does not have a built-in dirt fi lter.
  • Page 23 5. Connect the wires up in accordance with the wiring diagram. ATTENTION The expansion PCB and the connections must be installed by a certifi ed electrician. The expansion PCB is an accessory for the CTS602 circuit board. Nilan does not supply external components.
  • Page 24 External electrical pre-heating element External electrical pre-heating element It is possible to purchase an external electrical pre-heating element for frost protection of the ventilation unit. The electrical pre-heating element is mounted in the outdoor air duct before the unit with the necessary temperature sensor. If it is desired to see the actual outdoor air temperature on the control panel, the temperature sensor T1 / T8 must be led out into the duct before the pre-heating element.
  • Page 25 Electrical after-heating element Electrical after-heating element If you want to control the supply air temperature, you will need an after-heating element. You can purchase an electrical after-heating element for installation in the supply air duct. It comes with the required sensor, an expansion PCB and connection to the ventilation unit.
  • Page 26 Water after-heating element Water after-heating element If you want to control the supply air temperature, you will need an after-heating element. You can purchase a water after-heating element for installation in the supply air duct. It comes with the required sensor, an expansion PCB and connection to the ventilation unit.
  • Page 27 sensor sensor If the extent to which a dwelling/building is used varies considerably, you will benefi t from installing a CO -sensor to control the air exchange. The CO -sensor measures the CO -level in the extract air. It then regulates the fan speed level accordingly. ATTENTION In order to be able to connect up a CO -sensor, the ventilation unit must have an expansion PCB.
  • Page 28 USEFUL INFORMATION As an accessory, Nilan can supply a water trap with ball. When the water trap dries out, the ball closes it off and ensures that air cannot be drawn into the ventilation unit. When condensate water is formed again, it will lift the ball, and the water will be able to drain away without problems.
  • Page 29 Plumbing connections accessories Connecting a water trap with ball Connecting a water trap with ball It is important to connect up the water trap in compliance with the measurements below. If the water trap is placed outside the climate screen, it should be protected against frost. Water trap and accessories: 1.
  • Page 30 B3 Actuator and regulation valve Danfoss AME 140/24V 0-10V signal, 2-way valve VZ2 Kv 0.4 (Nilan supply), the Kvs value must be checked against the power supply. Differential pressure: 0.1 - 0.6 bar. With a fl ow temperature of 60 °C and at maximum Return fl...
  • Page 31 It is important to check that wires are not damaged or squeezed during connection and use. Usage Usage Nilan’s fi re automation system is used to monitor, test and check the fi re protection components of the ventilation system: • Fire and smoke damper, and fi re thermostat Important functions: •...
  • Page 32 Connection of fire damper Connection of fi re damper As an optional extra you can purchase Nilan’s Fire Connection Box for connection of fi re dampers. The fi re automation system is integrated into the control system. Belimo fi re damper...
  • Page 33 Note that the two extra wires from dampers (S3 and S5) are not used. Connect the supply voltage from Neutral and relay 5 in a parallel circuit. Mount junctions in an external junction box (not supplied by Nilan). Connect up S1-S6 to Nilan’s Fire Connection Box as shown under “Connecting fi re dampers”. Fire damper 1 Fire damper 2...
  • Page 34 Start-up and annual testing Start-up and annual testing It is necessary to carry out a complete test of functions after installation of the fi re protection automation system. If everything has been installed in accordance with the guidelines and regulations, and the test reveals no errors, the display will show “OK”. If the test fails, the display will show “ERROR”.
  • Page 35 Schedule for functional testing Schedule for functional testing ATTENTION DS 428 requires written documentation of the annual test of the Fire automatic system. Date: Comments: Tested by:...
  • Page 36 Nilan can supply Soundfl ex tubes that you can use as fl exible connections between the ventilation unit and the duct system. They will also reduce sounds from the system considerably.
  • Page 37 Supply air Supply air Install supply air valves in living areas. Place them strategically so they cause minimum discomfort. It is, for instance, not recom- mended that you install supply air valves in areas where people are inactive, as the supply air may be experienced as draughty. Living areas may be, for example: •...
  • Page 38 Balancing Important information Important information ATTENTION To ensure the ventilation system operates optimally, it is important that it is balanced correctly. We recommend that experts do this. It is important to measure the total supply air and the total extract air. The system must have a minimum vacuum, which means it draw out more air than it blows in.
  • Page 40 Nilan A/S Nilanvej 2 8722 Hedensted Danmark Tlf. +45 76 75 25 00 nilan@nilan.dk www.nilan.dk...
