Related Manuals for Aiwa FR-C200
Summary of Contents for Aiwa FR-C200
- Page 1 All manuals and user guides at all-guides.com FR-C200 YZ(B) SERVICE MANUAL RADIO RECEIVER S/M Code No. 09-012-353-8N1...
- Page 2 All manuals and user guides at all-guides.com ACCESSORIES/PACKAGE LIST-1/1 REF. NO PART NO. KANRI DESCRIPTION 1 S0-303-401-000 IB,YZ(EDPHNCZ)C200 1 S0-303-400-000 IB,YZ(EGFSI)C200...
- Page 3 All manuals and user guides at all-guides.com SPECIFICATIONS • Design and specifications are subject to change without notice...
- Page 4 All manuals and user guides at all-guides.com ELECTRICAL MAIN PARTS LIST-1/1 REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION S1-010-013-500 COIL,AM W/ BAR 10-90MM S4-010-013-600 COIL,CHOKE 10UH S2-522-426-000 IC,KA22426D LED1 S7-010-012-000 LED,4-2MM(RED) S2-010-010-801 PVC,AM/FM S1-010-033-200 SPKR,57MM 8 OHM 1W DIODE S3-123-004-000 SW,SLD SKL-23D08-G4-NA...
- Page 5 All manuals and user guides at all-guides.com WIRING-1/1 MAIN C.B (PARTS SIDE) NOTE RXXX CXXX...
- Page 6 All manuals and user guides at all-guides.com SCHEMATIC DIAGRAM-1/1 MAIN C.B TC4,L2 TC1,L3 TC2,L4 T3,TC3 AM TRACKING FM TRACKING FM FREQUENCY AM FREQUENCY FM IF RANGE ADJ RANGE ADJ PVC (TC1-4) SKL-23D08 POWER BATT DC 4.5V SPRING AM/FM IF POWER IC SPEAKER 8 OHM BAND...
- Page 7 All manuals and user guides at all-guides.com IC BLOCK DIAGRAM-1/1 IC, KA22426D...
- Page 8 All manuals and user guides at all-guides.com ELECTRICAL ADJUSTMENT-1/1 MAIN C.B 2 5 3 TEST POINT < TUNER SECTION > 1. AM IF Adjustment 4. FM IF Adjustment Settings: • Test point IC1 23PIN Settings: • Test point IC1 23PIN •...
- Page 9 All manuals and user guides at all-guides.com MECHANICAL EXPLODED VIEW-1/1 RIBBON COIL, AM W/BAR...
- Page 10 All manuals and user guides at all-guides.com MECHANICAL PARTS LIST-1/1 REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION 1 S0-301-890-000 DOOR,BATT 16 S0-901-530-000 HOLDER POINTER 2 S2-010-012-600 ANT,ROD 17 S1-701-060-000 GEAR,POM 3 S0-100-200-000 HAND STRAP 18 S0-202-680-000 SPRING ROLL 4 S0-801-640-000 LENS,PMMA...
- Page 11 All manuals and user guides at all-guides.com COLOR NAME TABLE Basic color symbol Color Basic color symbol Color Basic color symbol Color Black Cream Orange Green Gray Blue Transparent Blue Gold Pink Silver Titan Silver Brown Violet White Transparent White Yellow Transparent Yellow Metallic Blue...
- Page 12 All manuals and user guides at all-guides.com 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110-8710, JAPAN TEL:03 (3827) 3111 H251701 Printed in Singapore...
