Android Panel

AP6 Series

Revision History

Revision

Description

1.0

Initial Release

RENU Electronics Pvt. Ltd

User Manual

reserves the right to change or discontinue specifications and features without prior notice.

Date

24/06/2024

Prepared by

Approved by

Need help?

Do you have a question about the AP6 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Renu Electronics AP6 Series

Page 1 Android Panel AP6 Series User Manual Revision History Revision Description Date Prepared by Approved by Initial Release 24/06/2024 ® RENU Electronics Pvt. Ltd reserves the right to change or discontinue specifications and features without prior notice.
Page 2 THERNET ....................15 ETWORK NFORMATION HECK AND SET UP USB H ............................15 ............................16 ONNECTION ..........................16 LUETOOTH ONNECTION ..............................16 UDIO ........................... 17 EMORY ....................... 17 YPICAL RCHITECTURE IAGRAM © RENU Electronics Pvt. Ltd. Page 2 of 26...
Page 3 SCREEN VISUALIZATION ........................19 ............................. 19 CREEN ..........................20 PPLICATIONS INDOW ..........................20 TATUS OTIFICATIONS ………………………………………………………………………………………………………21 UICK ETTINGS ………………………………………………………………………..………………………22 IOSK MODE EATURE FAQ (FREQUENTLY ASKED QUESTIONS) ..................... 25 NOTES ............................... 26 © RENU Electronics Pvt. Ltd. Page 3 of 26...
Page 4 This user manual gives detailed information regarding the hardware specifications, operating conditions, installation, mounting, wiring and and loading of Apps. All the information published in this manual is produced and governed by RENU Electronics Pvt. Ltd. and is protected by Indian Copyright Act.
Page 5 The following is standard with the Box 1. Android Panel with preinstalled Android 10 2. Foldable Antenna 10” 3. Quick Start Manual 4. Power Connector Antenna Extension cable will be included if preordered. © RENU Electronics Pvt. Ltd. Page 5 of 26...
Page 7 Android Panel Product Mounting Dimensions This section of the manual provides dimensional details of AP6070CN and AP6101CN android panels for mounting. All the dimensions shown below are measured in mm. AP6070CN © RENU Electronics Pvt. Ltd. Page 7 of 26...
Page 9 The storage temperature must be -30° to 80°C. Installing AP6 products AP6 series products are designed for panel mounting / wall mounting / VESA mounting. Before installing the products, the user should review the panel guidelines, panel cutout dimensions, product dimensions, and minimum clearances.
Page 10 Cable mount cutout For external antenna panel cutout diameter: 7.5mm ATTENTION: Mounting AP6 ATTENTION  Do not push the display when pushing the unit into the panel as it may damage the display. © RENU Electronics Pvt. Ltd. Page 10 of 26...
Page 11 Approx. 0.8kg Approx. 1.0kg Accessories Power Connector 3 Pin PCB Terminal block(5.08mm PBT) Environmental and Approvals -20° to 60°C Operating Temperature Storage Temperature -30 to 80°C Humidity 10 to 90% RH(Non-Condensing) © RENU Electronics Pvt. Ltd. Page 11 of 26...
Page 12 AN-1 Antenna extention cable 50 ohm, 2.4GHz, 3 metre wire. Display Specifications AP6 series products support high-quality Color TFT display range. Size: 7” or 10.1” XGA Color TFT with capacitive touch screen Resolution: 1024 x 600 pixels Brightness: 1000 nits Color : 16.7M...
Page 13 5~150Hz, 1g peak, (X, Y, Z) Protection IP65 RoHS Wi-Fi Antenna (Optional) General information: Application: Wireless Communication 2.4 GHz Frequency Range: 700 - 5000 MHz Dimensions: 150 x 30 x 20 mm Weight: 0.2 kg © RENU Electronics Pvt. Ltd. Page 13 of 26...
Page 14 Extension Cable (Optional): SMA Male/ Female, 3 Meters, 50 ohms STARTING THE ANDROID PANEL Connecting Power AP6 series requires a 24VDC isolated power supply. Follow the steps mentioned below to connect the power: 1. Secure the 24VDC power wires before connection. Make sure that no other terminal is connected on the Panel 2.
Page 15 [Note: When Ethernet and Wi-Fi both are connected, Ethernet connection will be on priority.] USB Host Port AP6 series products is equipped with two Type A USB 2.0 ports to connect various peripheral devices such as keyboards, mouse, USB storage devices, and other compatible accessories.
Page 16 4. Navigate to "Connected devices" and select "Bluetooth." Audio Jack AP6 series Android Panel is equipped with a 4-Pole audio jack adhering to the CTIA (Cellular Telecommunications Industry Association) standard that supports standard 3.5mm headphones, headsets, and external speakers with microphone. This feature allows for private listening, audio output to larger sound systems, and microphone input.
Page 17 Memory Card Slot AP6 series Android Panel is equipped with a memory card slot that supports microSD memory card upto 128GB. This allows for expanded storage, easy data transfer. The memory card slot is located on the down side of the panel.
Page 18 Android Panel Default Product Setting Network Setting Dynamic Default IP Brightness Full Scale Default Language English RTC Settings Current Date/Month/Year Current Time © RENU Electronics Pvt. Ltd. Page 18 of 26...
Page 19 2. Back : Return to the previous page. 3. Home : Return to the home screen. 4. Recent : Switch between recently used apps. 5. Volume + : Increase the system volume. © RENU Electronics Pvt. Ltd. Page 19 of 26...
Page 20 NOTE: Screen rotation to be change manually in “setting” option. 1. Click on – Setting > More settings > Display 2. Click on ‘Primary Rotation’ 3. Select required orientation : 0, 90, 180, 270 © RENU Electronics Pvt. Ltd. Page 20 of 26...
Page 21 Hide bar button – show/hide Check Network Information: 1. To check MAC address, IP address, Gateway, DNS 2. Click on – Setting > Network & Internet > Ethernet 3. Check information given ‘NETWORK INFO’ © RENU Electronics Pvt. Ltd. Page 21 of 26...
Page 22 3. Click ‘OK’ in confirmation popup window to uninstall the application. Android Kiosk Mode feature: 1. Connect internet to android device using Wi-Fi or Ethernet. 2. Open ‘Toolbox’ app in device © RENU Electronics Pvt. Ltd. Page 22 of 26...
Page 23 5. Click on ‘Boot APP’ and then click on add ‘+’ icon. 6. Click on ‘APP Name’ to select application that to be add for kiosk mode. 7. Enable ‘Show system App’ to show all installed apps © RENU Electronics Pvt. Ltd. Page 23 of 26...
Page 24 ’ symbol 14. Power cycle the device and app will run in kiosk mode. Exit Kiosk Mode feature: 1. For exit the Kiosk Reset the device. 2. Apply patch file in device. © RENU Electronics Pvt. Ltd. Page 24 of 26...
Page 25 Opera browser and download the .apk from the webpage onto a USB stick. Once the USB stick has the necessary .apk file insert it in the AP6CN device and copy it in the device and run it. © RENU Electronics Pvt. Ltd. Page 25 of 26...

This manual is also suitable for:

Ap6070cn Ap6101cn
