ZyXEL Communications VES-1616F-34 Specifications

VDSL Downstream/Upstream:
100/100 (VDSL1 Mode),
100/50 (VDSL1 Mode),
50/30 Mbps (VDSL2 Mode)
Two Build-in Dual-personality (RJ-
45 or SFP open slot) Interfaces for
Flexible Deployment
IP QoS support: VLAN, Multicasting,
and Priority queue
802.1x Service Authentication
Offer a Rich Set of Advanced
Features Such as IGMP Snooping,
MVR, MAC Filtering
SNMP Management Support
16-port DMT VDSL2 Switch
ves-1616f-34
ves-1616f-35
Carrier Grade: Beyond Triple Play
Benefits
DMT Modulation - Standard Compliance and Outstanding Performance
The ZyXEL VES-1616F-34/35 is a DMT (Discrete Multi-Tone)-based VDSL solution, which dynamically adapts
the bit rate to conditions on the local loop, offers excellent performance even over noisy lines. Network
administrators become free from manually testing lines and constantly adjusting equipment to noise
conditions. Both IEEE's 802.3ah Ethernet in the First Mile (EFM) Task Force and T1E1.4 Working Group
selected DMT as its worldwide VDSL line-coding standard.
Port Trunking Provides Higher Availability
The ZyXEL VES-1616F-34/35 supports IEEE 802.3ad with load distribution control and fail over recovery,
which distributes traffic to each trunk port based on the source and destination MAC addresses, balancing
the traffic load.
Traffic Prioritization Streamlines Multi-Services
Administrator can enable IGMP snooping to optimize service quality for IP multicasting applications. This
prevents unnecessary forwarding of multicast traffic to all subscribers, thus optimizing bandwidth
utilization for bandwidth-consuming applications such as broadcast video. In addition, the Multicast VLAN
registration (MVR) feature checks all the VLANs to see if they request the same video stream. Through this
exclusive mechanism, the video stream can be reduced significantly, and thus be very advantageous in
MoD environment.
Rate Limiting Allows Service Differentiation
Rate limiting on the subscriber ports allows for service in increments of 64Kbps, allowing service providers
to offer tiered service.
Excellent Configuration and Management Capability
The ZyXEL VES-1616F-34/35 includes rich management tools to streamline your management effort. The
Web-based management interface of the device offers an easy-to-use platform, independent management,
and configuration options. The VES-1616F-34/35 supports SNMP and MIBs, both of which can be managed
via standard-based management software. In addition to remote management capabilities, a console port
is available for local management.
