Leviton GreenMAX DRDD7 Instruction Sheet

WARNINGS:
• TO AVOID FIRE, SHOCK, OR DEATH; TURN OFF POWER AT CIRCUIT BREAKER OR FUSE
AND TEST THAT POWER IS OFF BEFORE WIRING!
• To be installed and/or used in accordance with appropriate electrical codes and regulations.
• If you are unsure about any part of these instructions, consult an electrician.
• To avoid electrical overload, total connected lamp load shall not exceed output rating.
• This equipment permits more than one power supply output source.
• Do not mount near gas or electric heaters.
Product Description
The GreenMAX DRC Multi-channel relay provides multiple channels of switching with optional
TM
0-10V control for both dimming and switching of loads. This device communicates on the LumaCAN
network and offers full integration with the DRC system.
Before Installation
• Relay & modules should be installed in a suitable DIN rail enclosure.
• All mains wiring should be done in accordance with local authority wiring regulations.
• Appropriate isolation shall be maintained between Line and Low Voltage cabling.
• For more information on network wiring, see the Leviton GreenMAX DRC Installation Guide
and training videos at www.Leviton.com.
• Confirm load type and amount is within product capabilities as not all load types are supported.
Wiring Diagrams
• All Neutral terminals are internally connected.
• DRDD7-D2U may be configured as 1 or 2 channel device. Factory default configuration is 1
channel setup for 2-pole load.
• DRDD7-D2U inputs may be same or different phases, however, neutral must be identical.
• On power loss, 0-10V loads go to full output.
DRDD7-A4U, Four Channel, Switching Only
120-347VAC
Hot (Black)
50/60 Hz
Neutral (White)
input
20A Max
Channel 1 shown
(channels 2-4 typical)
LOAD LOAD
N L
N CH1 N CH2 N
Daisy chain
between devices
DRDD7-D2U 2 Channel Operation Load
Hot (Black)
120-277VAC
Neutral (White)
20A input
Neutral (White)
Hot (Black)
LOAD 1
CH1 L1 N N
Daisy chain
between devices
GreenMAX
Cat. Nos. DRDD7, DRDDS, and DINRK
Light Light
CH1 CH2 CH3 CH4
0-10VDC
CH3 N CH4
CONTROL,
100mA MAX
SINKING
TEST
POWER NETWORK 1 2 3 4
RESET
CLASS 2
LumaCAN
LumaCAN
network connection
Light
Light
0-10V connections
are optional
LOAD 2 CH1 CH2
0-10VDC CONTROL,
N N L2 CH2 100mA MAX SINKING
TEST
POWER NETWORK 1 2
RESET
CLASS 2
LumaCAN
LumaCAN
network connection
DRC Multi-Channel Relay
TM
CAUTIONS:
• Use this device with copper or copper clad wire only.
• For indoor applications only.
• Test all network cables for proper pin-out configuration prior to interconnecting devices and systems.
• If you are unsure about any part of these instructions, consult an electrician.
• SAVE THESE INSTRUCTIONS.
INSTALLATION INSTRUCTIONS
Catalog Nos.
Input Voltage
Input Current
Standby
Load Ratings
LED,CFL, Electronic Ballast @ 120V
LED,CFL, Electronic Ballast @ 277V
LED,CFL, Electronic Ballast @ 347V
Resistive, Tungsten @ 120V
Resistive, Tungsten @ 208-277V
General Use@ 208-347V
Receptacle control (5-20R) @ 120V
Receptacle control (6-20R) @ 250V
Motor @ 120V
Motor @ 240-277V
Motor @ 347V
Dry Contract
IP Rating
Terminal Torque Rating, Line Voltage
Terminal Torque Rating, Low Voltage
Network Connections
Topology
Operating Temperature
Humidity
Storage Temperature
UL Impulse Voltage Category
UL Pollution Degree Category
Control Type
Purpose of Control
Dimensions
DRDD7-A4U, Four Channel, Switching and 0-10V operation
120-347VAC
50/60 Hz
input
20A Max
DRDD7-D2U 1 Channel Operation, 2 Pole Load
120-277VAC
50/60 Hz
input
20A max
Specifications
DRDD7-A4U
120-347VAC,
50/60 Hz
20A
35mA
5A
5A
5A
5A
5A
5A
N/A
N/A
1/3 HP
1/3 HP
1/3 HP
N/A
10
5lb-in
5lb-in
• LumaCAN via (2) RJ45 connections
• Termination provideded via termination plug
• Use of feed-through RJ-45's plugs are not supported. Their use
will void product warranty.
• Daisy Chain, 1600' Max between repeaters.
• Home-Run topology and network length up to 10,000' can be
achieved when using LumaCAN network repeaters (Leviton #
NPRPT)
• Maximum 110 nodes between repeaters
• Maximum 250 nodes on a LumaCAN network
32 -149 °F (0 - 65°C) ambient at the module itself, cabinet external
will be lower rating.
20-90% non-condensing
14 -185 °F (-10 - 85°C)
6000V <347V>
4000V <277V>
2
Type 1 Action, Electronic Disconnection
Energy Management Equipment
5.9 in. Wide (151mm) x
3.4 in. Tall (86mm) x 2 in. (51mm)
Neutral (White)
0-10 +
Light
0-10 -
Hot (Black)
Channel 1 shown Channel 1 shown
(channels 2-4 typical) (channels 2-4 typical)
LOAD LOAD CH1 CH2
N L
N CH1 N CH2 N CH3 N CH4
POWER NETWORK 1
RESET
Daisy chain
between devices
Light
Neutral if needed.
Hot (Black)
Hot (Black)
Neutral (White)
LOAD 1 LOAD 2
0-10VDC CONTROL,
CH1 L1 N N N N L2 CH2
100mA MAX SINKING
TEST
POWER NETWORK 1
RESET
Daisy chain
between devices
PK-A3467-10-00-0A
ENGLISH
DRDDS-A4L DRDD7-D2U
120-347VAC 120-277VAC,
50/60hz, or, 50/60Hz
0-48VDC 1 Pole or 2 Pole
20mA from
(2) 20A
LumaCAN network
20mA 15mA
5A 16A
5A 16A
5A N/A
5A 20A
5A 20A
5A 20A
N/A 20A
N/A 20A
1/3 HP 1.0 HP
1/3 HP 2.0 HP
1/3 HP N/A
1A DC N/A
CH3 CH4
0-10VDC
CONTROL,
100mA MAX
SINKING
TEST
2 3 4
CLASS 2
LumaCAN
LumaCAN
network connection
CH1 CH2
2
CLASS 2
LumaCAN
LumaCAN
network connection
