JVC HR-D210E Manual

HR-D210E/EG/EK
Same
As HRVSB2O
lee
VHS INDEX SEARCH SYSTEM
SPECIFICATIONS
Format : VHS PAL standard Audio
Recording system : Rotary, slant azimuth two-head Input : — 3.8 dBs (CENELEC standard},
helical scan system more than 10 k-ohms, unbalanced
Video signal system : PAL colour and CCIR monochrome Output level : —~ 3.8 dBs (CENELEC standard),
Tape width
Tape speed
Playing time
Temperature
Operating
Storage
Channel coverage
(E/EG)
(EK)
Aerial output
Power consumption
Power requirement
Video
Input
Output
Signal-to-noise ratio :
Horizontal resolution:
signals, 625 lines
- 12.65 mm
: 23.39 mm/sec
: 240 min. with E-240 video cassette
> 5°C to 40°C
: —20°C to 60°C
> VHF 47—89 MHz,
104—300 MHz,
302—470 MHz
UHF 470—862 MHz
UHF band IV/V Channels 21—69
: UHF channels 32—40 (adjustable)
: 26 watts
: 220 V~, 50/60 Hz (E/EG)
240 V~, 50/60 Hz (EK)
: 0.5 to 2.0 Vp-p, 75 ohms, unbalanced
: 1.0 Vp-p, 75 ohms, unbalanced
43 dB (Rohde & Schwarz noise meter)
250 lines
Output impedance
Signal-to-noise ratio:
Frequency range
Timer
Back up time
Reference
Dimensions
Weight
high impedance load
: Less than 1 k-ohm, unbalanced
More than 40 dB
: 70 Hz to 10,000 Hz
: 14-day/4-programme timer
: 10 sec
: AC Line
: 435 mm(W) x 95 mmiH) x
341 mm(D)
: 6.5 kg
Provided accessories. : Aerial cable,
Infrared remote control unit,
""R6" battery x 2
Design and specifications subject to change without notice.
COPYRIGHT © 1987 VICTOR COMPANY OF JAPAN, LTD.
No. 82003
April 1987
