- Page 1 Intelbras PSR180-12A-B – PSR180- 12A-F and PSR180-12D-B Power Supply User Manual...
- Page 2 180W. The PSR180-12A-F and PSR180-12A-B AC power supplies are similar in all respects except for the markings and the direction of airflow. The PSR180-12A-F power supply draws in air from the power supply panel, while the PSR180-12A-B and PSR180-12D-B power supplies expel air from the power supply panel.
- Page 3 Intelbras PSR180-12A-B - PSR180-12A-F and PSR180-12D-B Power Supply User Manual Technical specifications Item Specifications PSR180-12A-F/PSR180-12A-B：100 to 240V AC @ 50/60Hz Rated voltage range PSR180-12D-B：-48 to -60V DC PSR180-12A-F/PSR180-12A-B：90 to 264V AC @ 47/63Hz Max voltage range PSR180-12D-B：-36 to -72V DC...
- Page 4 Intelbras PSR180-12A-B - PSR180-12A-F and PSR180-12D-B Power Supply User Manual Safety precautions • Wear an ESD wrist strap and make sure the wrist strap makes good skin contact. • Before installing the power supply, make sure the operating voltage of the external power supply system is as required by the power supply, and the output voltage of the power supply is as required by the powered device.
- Page 5 Intelbras PSR180-12A-B - PSR180-12A-F and PSR180-12D-B Power Supply User Manual • Unpack the power supply and verify that the input mode of the power supply is as required. • Remove the filler panel, if any, from the target power supply slot.
- Page 6 Intelbras PSR180-12A-B - PSR180-12A-F and PSR180-12D-B Power Supply User Manual • Attach the hooks of the power cord retainer clip into the holes on the two sides of the AC-input power receptacle.Skip this step if the power cord retainer clip is installed on the power supply.
- Page 7 Intelbras PSR180-12A-B - PSR180-12A-F and PSR180-12D-B Power Supply User Manual...
