  • Page 1 User manual High Power ELC 5002 High Power ELC 5003 ELC 5112...
  • Page 2 Congratulations, you have just purchased a product with Intelbras quality and safety. The High Power ELC 5002/ELC 5003 and ELC 5112 electrifiers for electric fence are microprocessor-ba- sed, monitor the high voltage output, generating a trip by grounding or breaking the fence. They have a mixed zone (wired and/or wireless) for connecting aperture and/or infrared sensors.
  • Page 3 Care and safety » Read and follow all instructions in this user manual before installing and/or using this equipment. » The product was developed in accordance with the ABNT NBR IEC 60335-2-76 standard. » The equipment, cables or the electrified fence must not be installed in places where extreme condi- tions prevail, such as the presence of corrosives, explosive atmosphere (with the presence of gases), flammable liquids, etc.
  • Page 4 » It is recommended that children are supervised to ensure that they are not playing with the appliance. » LGPD - General Personal Data Protection Law: Intelbras does not access, transfer, capture or perform any other type of processing of personal data from this product.

  • Page 5: Table Of Contents

    Summary 1. Technical specifications 2. Characteristics 3. Products 3.1. Main components ..........9 4.
  • Page 6 4.25. Clear all programmed sensors ........26 4.26. Siren beep activation/deactivation .......26 4.27.

  • Page 7: Technical Specifications

    1. Technical specifications ELC 5002 ELC 5003 ELC 5112 Supply voltage 115 - 230 Vac (it is recommended to use a cable with gauge ≥1 mm) Nominal frequency 50 - 60 Hz Consumption in 115 - 230 Vac 4,5 W...

  • Page 8: Characteristics

    2. Characteristics The purpose of the ELC 5002/ELC 5003 and ELC 5112 electric fence centers is to energize the fence for the protection of commercial, residential and industrial areas and must be installed within the current technical standards, in order to generate overt protection, without generating risks fatal to anyone who touches the wiring that makes up the installation.

  • Page 9: Products

    » With the Power jumper in the middle position (disconnected) = 10,000 V pulsating (ELC 5112) or 18,000 V pulsating (ELC 5002 / ELC 5003), ±5%. » With the Power jumper in the high position = 12,000 V pulsating (ELC 5112) or 20,000 V pulsating (ELC 5002) or 21,000 V pulsating (ELC 5003), ±5%.

  • Page 10: Installation

    » Check the table below to select the minimum diameter of the wire to be used, according to the installed perimeter: 3.000 m 5.000 m 6.000 m 7.000 m High Power 0,6 mm 1,2 mm ELC 5002 / ELC 5112 High Power 0,6 mm 0,6 mm 0,9 mm 1,2 mm ELC 5003 »...
  • Page 11 » Intersections with overhead power lines should be avoided whenever possible. If such crossing cannot be avoided, it should be done below the power line and as close as possible so as to be perpendicular to the line. » If the high voltage conductors and electric security fence wires are installed close to overhead power lines, the separation distances must not be less than those indicated in the following table: Electric power line voltage (V) Separation distance (m)

  • Page 12: Siren

    » The installation of the equipment must only be carried out by a specialized technician. » Before performing maintenance or inspections on the system, all feeder circuits must be de-energized (mains and battery). » Do not install this equipment on structures that spread flames, due to the risk of shorting the wiring or the product.

  • Page 13: Monitoring On/Off Fence

    4.5. Monitoring on/off fence PGM2 is a dry contact that is activated when there is activation or deactivation of the fence system, that is, if it is connected in the central area, it will send a trip and restoration to the monitoring company. For connection, follow the procedure: »...

  • Page 14: Activation And Deactivation Via Pushbutton Or Key

    4.9. Activation and deactivation via pushbutton or key This product can be activated or deactivated through a retentive pushbutton or On/Off switch. Connect the pushbutton or the switch to the Z1 and PGM terminal of the fence, as shown in the image below: LED+ LED- PGM1...

  • Page 15: Ac Power Connection (Mains)

    Note: » Do not install the product on surfaces that favor the propagation of flames, in case of a short circuit in the wiring or equipment. » When possible, this equipment should be fixed in a place protected from the sun, rain and humidity, even with IPX4 protection level.

  • Page 16: Battery Connection (Bicolor Parallel Wire Cable)

    4.12. Battery connection (bicolor parallel wire cable) The J6 connector, as shown in the figure below, is used to connect the battery to the system. During normal operation, this output acts as a battery charger and, in the event of a power failure from the mains, it supplies energy to the system.
  • Page 17 » Position the battery at an angle for a better fit in the cabinet; » Lower the battery until it touches the bottom;...
  • Page 18 » Connect the battery cable to connector J6 on the board. Battery positive pole Black thread Battery negative pole Red thread 6. Close and screw the lid when finished. Attention: when the control unit is initially powered only by battery, check the procedure for the item Starting with battery.

  • Page 19: Connection Of High Voltage Cables And Grounding

    4.13. Connection of high voltage cables and grounding The high voltage input and ground cables must be installed through the holes on the right side of the cabinet. After passing the cables, it is necessary to make the connection at their respective terminals, as shown in the figure below, it is necessary to have a high voltage cable with a dielectric strength of at least 15 kV.
  • Page 20 After installing the cables, fit the electrifier cover as follows: Cover fit orientation: » Position and snap the cover to the bottom of the case; » Position the lid on top and fit the lid to the bottom until the cabinet snaps into place;...

  • Page 21: Ground Connection

    » Make sure there are no gaps between the lid and the base. Place the cover fixing screws in the indicated location. 4.14. Ground connection Grounding is mandatory and very important for the sensation of shock to anyone who touches the fence wires, in addition to protection against lightning and overload of the electrical network and/or sensor wiring.

  • Page 22: Connection And Assembly Of The Electric Fence

    4.15. Connection and assembly of the electric fence Rods and insulators specially developed for the assembly of electric fences can be purchased easily in the market. The rods are in flat aluminum or in the shape of an angle, to facilitate assembly. Your material should absorb impact and have minimal wind flexibility.

  • Page 23: Mounting The Rods

    4.16. Mounting the rods Use quality threads with a section greater than 0.60 mm² as it has good durability, low electrical resistance per meter and resistance to the mechanical tension required by stretching, in order to avoid bellies and overhang that would cause breakage. 15 cm Aluminum rod Insulator of...

  • Page 24: Programming The Remote Control To Arm/Disarm The Fence

    4.18. Programming the remote control to arm/disarm the fence 1. Place the Power jumper (JP1) in the High position; 2. Press the C key. Remote and the Fence LED will light up; 3. Engage the remote, and the Enabled, Fence, and Zone LEDs will flash rapidly, indicating the code has been learned.

  • Page 25: Place The Power Jumper (Jp1) In The High Position

    4.24. XAC 4000 Smart Control remote control user manual Congratulations, you have just purchased a product with Intelbras quality and safety. The remote control XAC 4000 Smart Control, has 3 independent buttons (channels), modern design and powered by a single 3V Button type battery.

  • Page 26: Clear All Programmed Sensors

    4.25. Clear all programmed sensors 1. Set the Power jumper (JP1) to the Low position; 2. Press the Sector key and the Zone LED will light up. Press and hold the key for approximately 5 secon- ds until the Fence and Zone LEDs flash indicating that the sensors have been cleared. 4.26.

  • Page 27: To Enable Arming/Disarming The Fence

    4.30. To enable arming/disarming the fence 1. Place the Power jumper (JP1) in the High position; 2. Press and hold the Sector key for approximately 5 seconds and the On LED will be lit. After this time the Fence and Zone LEDs will flash for approximately 3 seconds and then go out. 4.31.

  • Page 28: Installation Completion

    6. General reset If the High Power ELC 5002/ELC 5003 and ELC 5112 fences are turned on and it is not possible to use the remote control, the only means available to turn off the fence is through a General System Reset. To perform the General Reset, follow the procedure: 1.

  • Page 29: Operation

    7. Operation 7.1. Activation/deactivation of the fence/alarm Press the previously programmed remote control key. The siren will beep and the fence will be activated. The drive does not have a time delay, therefore, all modules must be closed and the fence must be in good condition.

  • Page 30: Warranty Term

    Warranty term It is established that this warranty is granted upon the following conditions: Client’s name: Client’s signature: Invoice number: Date of purchase: Model: Serial number: Retailer: 1. All the parts, pieces and components of the product are guaranteed against possible manufacturing defects, which may arise, for the term of 1 (one) year - this being 90 (ninety) days of legal warranty and 9 (nine) months of contractual warranty –, counting from the date of purchase of the product by the Consumer, as appears in the product purchase bill of sale, which is an integral part of this...
  • Page 31 7. Intelbras is not responsible for the installation of this product, or for possible attempts at fraud and/ or sabotage in its products. Maintain the updates of the software and applications used up-to-date, if it is the case, as well as the network protection required for defense against hackers. The equipment is guaranteed against defects in its usual conditions of use, it being important to bear in mind that, as it is electronic equipment, it Is not free of fraud and scams which may interfere with its correct functioning.
  • Page 32 Support via e-mail: suporte@intelbras.com.br Customer Service: 0800 7042767 Where to buy? Who installs it? 0800 7245115 Produced by: Intelbras S/A – Indústria de Telecomunicação Eletrônica Brasileira Rodovia BR 459, km 124, 1325 – Distrito Industrial – Santa Rita do Sapucaí/MG – 37540-000 01.21 CNPJ 82.901.000/0016-03 –...
