Smoke alarm II
quick instructions
Product description
The product is a optical smoke alarm certified
according to EN14604. It can be relied upon to warn
you if a fire develops in your house or home. If smoke is
detected, a visual and acoustic alarm is triggered.
Follow the instructions and information in these quick
instructions to ensure correct operation.
Description of the symbols
Warning!
Note about hazards
Note:
Additional
important information
Note about the installation video
Safety instructions
▶ R ead this user manual completely before install
ing or commissioning the device and pay particular
attention to the hazard information.
▶ D o not charge used batteries, and do not attempt to
reactivate them using heat or other means. Do not
short-circuit batteries. Do not expose batteries to
strong sunlight. Do not throw batteries into fire!
There is a risk of explosion!
There is a risk of explosion!
▶ M ake sure the polarity is correct when inserting
the batteries! Only use batteries of the same type.
Drained batteries must be removed from the device
immediately. Remove batteries from the device if it
is not used for a longer period of time.
Increased risk of leakage!
Increased risk of leakage!
▶ O nly use the batteries which are recommended in
the technical data.
▶ T he device is not a toy! Do not allow children to play
with it. Never leave the packaging material lying
around unattended. Plastic film and small parts may
pose a danger to children.
▶ S tore small cells and batteries which could be swal
lowed out of the reach of children. Swallowing can
result in burns, perforation of the soft tissue and
death. Severe burns can occur within 2 hours after
swallowing. In the event that a cell or battery is swal
lowed, seek medical assistance immediately.
▶ T his device may be used by children from 8 years of
age and by persons with reduced physical, sensory
or mental capacities, or a lack of experience and
knowledge provided these persons are supervised
or have been instructed in the safe use of the device,
and understand the corresponding risks.
▶ W hen remotely or automatically controlling a device,
it is not always possible to guarantee that commands
are actually executed or that the correct device sta
8-750-002-215
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Bosch Smoke alarm II
Summary of Contents for Bosch Smoke alarm II
- Page 1 Safety instructions ▶ R ead this user manual completely before install ing or commissioning the device and pay particular Smoke alarm II attention to the hazard information. quick instructions ▶ D o not charge used batteries, and do not attempt to reactivate them using heat or other means. Do not Product description short-circuit batteries. Do not expose batteries to The product is a optical smoke alarm certified strong sunlight. Do not throw batteries into fire!
- Page 2 ▶ O nly use the device together with original compo failure to observe the safety instructions. In these nents and recommended products from Bosch part cases, any guarantee claim becomes void! We ners. accept no liability for consequential damage.
- Page 3 You can also use the explanatory videos and additional information on our website and in the app as an additional aid for mounting, installing, starting up and restoring the factory settings on your Bosch Smart Home smoke alarm: www.bosch-smarthome.com/rom/smoke-alarm-2 Product overview Item Name Operating button Status LED Sirens Smoke alarm Ceiling bracket „Click“...
- Page 4 The smoke alarm has re After checking, initiate emergency ceived a signal from the measures. If there is no hazard, ac Alarm Bosch Smart Home controller knowledge the alarm on the detector to say that smoke has been which triggered it. detected in the system...
- Page 5 If you wish to make use of the option of integrating the room, as well as in every hallway which serves alarm into the Bosch Smart Home system, ensure that as an escape route. For optimal protection, we you have a Bosch Smart Home controller and the Bosch recommend installing additional smoke alarms in Smart Home app and have successfully configured the living areas, in the attic and in the basement.
- Page 6 > 1 m > 20° > 20° > 1 m 0.5 m > 20° Observe the minimum distances and correct Observe the subdivision of ceilings into panels orientation during mounting on the ceiling. Also or through beams and joists. If the height of the observe the angle of sloping walls in the room or subdivision is > 0.2 m, then one smoke alarm must attic.
- Page 7 Screw the smoke alarm clockwise into the ceiling controller which have been activated through alarm bracket until you feel it click into place. forwarding can be muted centrally from the Bosch Smart Home app. A test alarm may be triggered by accidentally If the switching off of an alarm is initiated via...
- Page 8 The device does not require maintenance. Leave any Smoke Alarm No. of devices interconnected: 10 repairs to a specialist. Clean the device with a soft, clean, dry and lintfree cloth. When cleaning, do not use Robert Bosch Smart Home GmbH hereby declare that any cleaning agents containing solvents. the radio equipment type Bosch Smart Home BSD-2 A visual inspection and function test must be corresponds with the directive 2014/53/EU. carried out monthly on the smoke alarm.
- Page 9 Ambient temperature 0 °C … + 40 °C Max. humidity 95 % (non-condensing) Housing dimensions (D × H) 110 × 37 mm Weight (without battery) 133 g Radio frequency band 2.4–2.4835 GHz Radio protocol ZigBee 3.0 Max. transmitting power 10 mW Radio range in the open < 100 m Software class Receiver category Battery 1 × 3 V CR17450 (Pairdeer, FDK) Battery lifespan < 5 years Volume at a distance of 3 m ≥ 85 dB(A) Technical modifications reserved Open source software This Bosch Smart Home product uses open-source software. License information for the components used can be found in the attached documents.
- Page 10 Spare parts Order number Name 8-750-002-152 Ceiling bracket Service information Robert Bosch Smart Home GmbH Schockenriedstraße 17 70565 Stuttgart-Vaihingen Germany service@boschsmarthome.com @ www.boschsmarthome.com/service 8-750-002-215 V010 03/2023...
