LCD Monitor
345B1C
WARNING
This disassembly information is designed for experienced repair technicians only and is not designed for use by the general public.
It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
Products powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to service or
repair the product or products dealt with in this disassembly information by anyone else could result in serious injury or death.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Philips 345B1C
Summary of Contents for Philips 345B1C
- Page 1 LCD Monitor 345B1C WARNING This disassembly information is designed for experienced repair technicians only and is not designed for use by the general public. It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
- Page 2 Content Index General Safety Instructions ............................1 1. General Guidelines ..............................1 2. Important Notice ..............................1 3. How to Read this Instruction ..........................3 Exploded view diagram with list of items ........................5 Disassembly SOP ..............................6...
- Page 3 General Safety Instructions 1. General Guidelines When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated or damaged by the short circuit. After servicing, see to it that all the protective devices such as insulation barriers, insulation papers shields are properly installed.
- Page 4 2-6 Safety Check after Repairment Confirm that the screws, parts and wiring which were removed in order to service are put in the original positions, or whether there are the positions which are deteriorated around the serviced places serviced or not.
- Page 5 2. After removing an electrical assembly equipped with ES devices, place the assembly on a conductive surface such as aluminum foil, to prevent electrostatic charge buildup or exposure of the assembly. 3. Use only a grounded-tip soldering iron to solder or unsolder ES devices. 4.
- Page 6 Warning: A “warning” is used when there is danger of personal injury. Reference: A “reference” guides the reader to other places in this binder or in this manual, where he/ she will find additional information on a specific topic.
- Page 7 Exploded view diagram with list of items...
- Page 8 1. Suggest Tools Here are some tools that can be used for the LCD monitor’s service and repair. Philips-head Screwdriver Use a Philips-head screwdriver to fasten/remove the K- or B-typed screws P/N：N/A Gloves To protect LCD Panel and your hand...
- Page 9 2. Disassembly Procedures 1. While keeping the release button pressed, tilt the base and slide it out. 2. Remove the screws.
- Page 10 3. Use disassembly tool to open all the latches along the edge of the rear cover. 4. Take off the tape and connector then remove the rear cover.
- Page 11 5. Remove the tapes and disconnect connectors. 6. Remove screws. 7. Remove the tape and disconnect the connector.
- Page 12 8. Remove Mylar. 9. Remove screws to get main board and power board.
- Page 13 10. Remove screws to get middle frame and panel.
