- Page 1 Momentum 345M2 www.philips.com/welcome User manual Customer care and warranty Troubleshooting & FAQs...
-
Page 2: Table Of Contents
6.1 Resolution & Preset Modes ..21 7. Power Management ....22 8. Customer care and warranty .. 23 8.1 Philips’ Flat Panel Monitors Pixel Defect Policy ..... 23 8.2 Customer Care & Warranty ..26 9. Troubleshooting & FAQs ..27 9.1 Troubleshooting ...... -
Page 3: Important
DC power cord for normal operation. • Please use approved power cord provided by Philips all the time. If 1.1 Safety precautions and your power cord is missing, please maintenance contact with your local service center. - Page 4 1. Important bezel, ensure that the monitor does the monitor by placing your hand or not tilt downward by more than -5 fingers on the LCD panel. degrees. If the -5 degree downward • Oil-based cleaning solutions may tilt angle maximum is exceeded, the damage the plastic parts and void monitor damage will not be covered the warranty.
-
Page 5: Notational Descriptions
1. Important activate a periodic screen refresh 1.2 Notational Descriptions application if your monitor will The following subsections describe display unchanging static content. notational conventions used in this Uninterrupted display of still or document. static images over an extended period may cause “Burn-in”, also Notes, Cautions and Warnings known as “after-imaging”... -
Page 6: Disposal Of Product And Packing Material
From the planning, design and production stages, Philips emphasizes the important of making products that can easily be recycled. At Philips, end-of-life management primarily This marking on the product or on entails participation in national take-... -
Page 7: Setting Up The Monitor
Top Victory Investments Ltd., and Top Victory Investments Ltd. is the warrantor in relation to this product. Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V. (2) Use your fingers to tighten the... - Page 8 2. Setting up the monitor 3. After attaching the base, erect the Connecting to your computer monitor with both hands on holding the monitor together with styrofoam firmly. Now you can pull out the styrofoam. When you pull out the styrofoam, do not squeeze the panel to avoid broken panel.
-
Page 9: Operating The Monitor
What is On-Screen Display (OSD)? Description of the control buttons On-Screen Display (OSD) is a feature in all Philips LCD monitors. It allows an end user to adjust screen performance or select functions of the monitors directly through an on-screen instruction window. - Page 10 2. Setting up the monitor Note Main menu Sub menu MPRT On, O Game Setting MPRT Level 0~20 • MPRT: To reduce motion blur, LED Crosshair On, O Low Input Lag On, O backlight will strobe synchronously SmartResponse O , Fast , Faster, Fastest On, O with screen refresh, which may SmartFrame...
- Page 11 2. Setting up the monitor Resolution notification Warning This monitor is designed for optimal • To avoid potential screen damage, performance at its native resolution, such as panel peeling, ensure that 3440 x 1440. When the monitor is the monitor does not tilt downward powered on at a different resolution, an by more than -5 degrees.
-
Page 12: Remove The Base Assembly For Vesa Mounting
2. Setting up the monitor 2.3 Remove the Base Assembly for VESA Mounting Before you start disassembling the Display base, please follow the 100mm instructions below to avoid any possible 100mm damage or injury. 1. Place the monitor face down on a smooth surface. -
Page 13: Multiview
MultiView in OSD menu Why do I need it? • PIP / PBP Mode: There are two With the ultra high resolution Philips modes for MultiView: [PIP] and MultiView display, you can experience [PBP]. a world of connectivity in a comfortable [PIP]: Picture in Picture way in the office or at home. - Page 14 2. Setting up the monitor Top-Left Top-Right When the sub source is not detected. (main) (main) (main) Note The black strip shows on the top and Bottom-Left Bottom-Right the bottom of the screen for the correct aspect ratio when in the PBP mode. If you expect to see full screen side by side, adjust your devices resolutions as (main)
-
Page 15: Image Optimization
Whether you're working There are multiple selections: FPS, with text applications, displaying images Racing, RTS, Gamer1, Gamer2, LowBlue or watching a video, Philips SmartImage Mode, EasyRead and Off. delivers great optimized monitor performance. ... - Page 16 Developed for wellbeing, • Personal: Customize available Philips LowBlue Mode setting uses a settings in picture menu. smart software technology to reduce • Off: No optimization by SmartImage harmful shortwave blue light.
-
Page 17: Smartcontrast
3. Image Optimization 3.2 SmartContrast What is it? Unique technology that dynamically analyzes displayed content and automatically optimizes a display's contrast ratio for maximum visual clarity and viewing enjoyment, stepping up backlighting for clearer, crisper and brighter images or dimming backlighting for clear display of images on dark backgrounds. -
Page 18: Adaptive Sync
4. Adaptive Sync • AMD Radeon R9 285 4. Adaptive Sync • AMD Radeon R7 260X • AMD Radeon R7 260 ■ Processor A-Series Desktop and Adaptive Sync Mobility APUs • AMD A10-7890K PC gaming has long been an imperfect •... -
Page 19: Hdr
5. HDR 5. HDR HDR Settings in Windows10 system. Steps 1. Right click on the desktop, enter to Display settings. STEP 5 2. Select the display/monitor. 3. Adjust resolution to 3440 x 1440. 4. Turn the “HDR and WCG” to on mode. -
Page 20: Technical Specifications
6. Technical Specifications 6. Technical Specifications Picture/Display Monitor Panel Type Backlight W-LED system Panel Size 34" W (86.36 cm) Aspect Ratio 21:9 Pixel Pitch 0.2325(W) x 0.2325(H) Contrast Ratio (typ.) 1000:1 Recommended 3440x1440@60Hz Resolution Viewing Angle 178° (H) / 178° (V) @ C/R > 10 (Typ.) Picture Enhancement SmartImage Game / SmartImage HDR Display Colors... - Page 21 6. Technical Specifications Power AC Input AC Input AC Input Consumption Voltage at Voltage at Voltage at 100VAC , 50Hz 115VAC , 50Hz 230VAC, 50Hz Normal Operation 55.8 W (typ.) 55.5 W (typ.) 56.2 W (typ.) Sleep (Standby mode) 0.5 W 0.5 W 0.5 W Off mode...
- Page 22 Finish Texture Note 1.This data is subject to change without notice. Go to www.philips.com/support to download the latest version of leaflet. 2.The maximum resolution through HDMI is 3440 x 1440@100Hz, if you want to run refresh rate at 120Hz through HDMI, you may select the resolution from the advanced setting in your graphic card.
-
Page 23: Resolution & Preset Modes
1440, but please always ensure H. freq (kHz) Resolution V. freq (Hz) that your graphic card is capable of 31.47 720x400 70.09 achieving the maximum resolution and refresh rate of this Philips 31.47 640x480 59.94 display. 35.00 640x480 66.67 37.86 640x480 72.81... -
Page 24: Power Management
7. Power Management 7. Power Management If you have VESA DPM compliance display card or software installed in your PC, the monitor can automatically reduce its power consumption when not in use. If an input from a keyboard, mouse or other input device is detected, the monitor will 'wake up' automatically. -
Page 25: Customer Care And Warranty
Pixel Defect Policy single black pixel. Other combinations of lit and dark sub pixels appear as Philips strives to deliver the highest single pixels of other colors. quality products. We use some of the industry's most advanced manufacturing... - Page 26 Black Dot Defects the warranty period, a TFT Monitor Black dot defects appear as pixels or panel in a Philips flat panel monitor sub pixels that are always dark or 'off'. must have pixel or sub pixel defects That is, a dark dot is a sub-pixel that...
- Page 27 8. Customer care and warranty BRIGHT DOT DEFECTS ACCEPTABLE LEVEL 1 lit subpixel 2 adjacent lit subpixels 3 adjacent lit subpixels (one white pixel) Distance between two bright dot defects* >15 mm Total bright dot defects of all types BLACK DOT DEFECTS ACCEPTABLE LEVEL 1 dark subpixel 5 or fewer...
-
Page 28: Customer Care & Warranty
Please contact our Philips Customer Service Representative or local contact center (by Consumer care number) for more details. Philips Customer Care Center number listed below. -
Page 29: Troubleshooting & Faqs
• Disconnect the monitor from mains This page deals with problems that can power source immediately for safety be corrected by a user. If the problem • Contact with Philips customer still persists after you have tried these service representative immediately. solutions, contact Philips customer service representative. -
Page 30: General Faqs
• Open 'Advanced Properties' and set Service contact information listed in the Refresh Rate to 60 Hz, then click Important information manual and contact Philips customer service • Restart your computer and repeat representative. step 2 and 3 to verify that your PC is set at 3440 x 1440 . - Page 31 Can I connect my monitor to any not use other solvents such as PC, workstation or Mac? ethyl alcohol, ethanol, acetone, Ans.: Yes. All Philips monitors are fully hexane, etc. compatible with standard PCs, Macs and workstations. You may Can I change the color setting of...
- Page 32 In most cases, the in EDFU? "burned in" or "after-imaging" Ans.: Important Information manual or "ghost imaging" will disappear can be download on the Philips gradually over a period of website support page. time after the power has been switched off.
- Page 33 This product has been manufactured by and is sold under the responsibility of Top Victory Investments Ltd., and Top Victory Investments Ltd. is the warrantor in relation to this product. Philips and the Philips Shield Emblem are regis- tered trademarks of Koninklijke Philips N.V. and are used under license.
