Sealife SL053 Instruction Sheet

6"/15cm Wide Angle Dome Lens for SportDiver
1) Overview: Designed for the SeaLife SportDiver-series UW smartphone housings, the lens increases field-of-view by 40%,
allowing you to get closer to the subject while fitting everything into the image frame. The dome lens corrects barrel
distortion and produces sharp edges. Easily capture above-below water split shots. The lens may be attached/removed
while underwater. Includes neoprene lens cover and protective pouch Waterproof to 130ft / 40m.
2) What's in the box:
Wide Angle Lens Neoprene Dome Lens Cover
3) Attaching the lanyard
*IMPORTANT* Attach the lanyard correctly to prevent loss of the
lens in case it gets bumped during your dive.
a) Push in the two locking tabs to separate the lanyard.
b) Feed the end of the lanyard into one of the lanyard lens holes.
Then, feed the connector end of the lanyard through the loop.
c) Feed the end of the lanyard into the hole at the housing hinge.
Then, feed the connector end of the lanyard through the loop.
d) Push the two connector halves together until it locks securely.
6) Important:
a) Keep the neoprene lens cover attached to the lens when the lens is not in use to prevent scratches.
b) Never jump in the water holding the housing and lens. Have your housing handed to you after entering the water.
c) After entering the water, make sure there are no air bubbles trapped between the lens and camera.
d) After each dive, soak the lens in fresh water for about 20 minutes. Dry lens with clean microfiber cloth.
e) Do not allow water drops to dry on the lens – It may leave mineral stains.
f) Make sure the neoprene lens cover is free of sand/dirt/debris before attaching it to the lens.
g) The lens is positively buoyant by 13oz/377g. Attaching one SL934 weight (sold separately) reduces buoyancy by
7oz/193g. Use two weights to reduce buoyancy by 14oz/385g. The SL934 weight can be attached under the housing.
h) To clean the lens, brush or blow away and sand/dirt/debris from the lens surface. Use the included lens cleaning cloth
to gently clean fingerprints and smudges. For stubborn stains, moisten the lens cloth with plastic lens cleaner or fresh
water. Never use detergents, alcohol, acetone or other chemicals to clean the lens.
i) Store the lens with neoprene cover attached in a cool, dry location. Avoid prolonged exposure to direct sunlight.
j) Please refer to the SeaLife website online troubleshooting for technical updates and solutions to any known issues.
7) Guarantee: SeaLife warrants the original purchaser of this product, for a period of one (1) year from the date of purchase, that the
product is free from defects in workmanship and materials. In the event the original purchaser believes there is a defect in a product,
it is recommended that the purchaser first visit www.sealife-cameras.com for product updates and information on how to get warranty
repair service. Contact your local SeaLife dealer or local distributor where the product was purchased for return information.
SeaLife (Div. of Pioneer Research), 97 Foster Road, Moorestown, NJ 08057 USA
(Item SL053)
Lens retaining Lanyard Microfiber cloth
4) Attaching and releasing the lens
a) The lens has two tabs that securely lock the lens
around the SportDiver lens frame. Attach one end
of the lens by aligning it to the lens frame as shown
below. Then push down on the other end to lock
the lens to the lens frame. Lift the lens to ensure it
is securely locked to the housing lens frame.
b) To release the lens from the housing, push in
one of the two locking tabs shown below and lift
the lens up off the housing.
5) Align the sunshade
With the lens attached to the housing, rotate the
sunshade so the large sections are on the top and
bottom. This will prevent the lens from vignetting
Instruction Sheet
Travel & Storage Pouch
www.sealife-cameras.com
(Dec 2023)
