DDREADER-20
Inserting a Card
All slots can be used simultaneously to transfer files from card to computer or card to
card. To avoid damaging the cards or the reader, do not use force when inserting cards.
Figure 4:
Inserting CompactFlash card
Figure 5:
Inserting SmartMedia card
Figure 6:
Inserting SD-MultiMediaCard
Figure 7:
Inserting Memory Stick
Delkin Devices User's Manual
USB 2.0 CF / SM / SD / MMC / MS Reader/Writer
•
To insert a CompactFlash Type I,
Type II or Microdrive, position the
card with the arrow side up and
toward the reader. Insert the card
gently but firmly into the slot labeled
CF / Microdrive.
•
To insert a SmartMedia card,
position the card with the gold
connector side up and the notched
end toward the reader. Insert the
card gently but firmly into the slot
labeled SM.
•
To insert a Secure Digital or
MultiMediaCard, position the card
with the gold connector side down
and the notched end toward the
reader. Insert the card gently but
firmly into the slot labeled SD/MMC.
•
To insert a Memroy Stick, position
the card with the gold connector
side down and the tapered end
toward the reader. Insert the card
gently but firmly into the slot labeled
MS.
Page 3
