Table Of Contents - Delkin Devices 20 User Manual

Table of Contents

Introduction
Included Components
Driver Software Installation for Windows
Hardware Installation
Inserting a Card
Basic Operation
Removing a Card
Formatting a Card
USB 2.0 Compatibility
Operational Notes
Network - Windows Drive Letter Assignment
Windows Troublshooting
The eFilm Reader-20 will accept
CompactFlash Cards of Type I (3.3mm)
and Type II (5.0mm) including IBM
Microdrives, SmartMedia(3V), Secure
Digital/MultiMediaCards & Memory Stick.
It's 'hot swappable' - You can insert and
remove cards without the need to shut
down the computer.
4-pin floppy
drive power
connector
USB Type A
Type B USB
connector
Power LED
Card Access LED
1
1
1
2
3
4
4
5
5
5
6
7
USB Type B
Pin-1
(Red)
5-pin USB connector
