heightec RescuePack Reach WK31 Quick Start Manual

WK31 - RescuePack Reach - RescueHauler
TM
This equipment should only be used by Competent Persons, who have been trained in the use of this specifi c kit.
These Prompt Sheets are to be read in conjunction with user instructions for each item of the kit.
Lowering
1. Select an unquestionably sound anchorage structure,
above casualty.
2. Pass anchor strop (A) around anchorage and connect
karabiner to screwlink.
3. Fit open hook to end of pole. With control device in "go"
position detent, extend rope and pole to casualty (B).
Attach hook to harness and pull to release, ensuring
hook gate closes fully.
4. Lock handle and hauling catch (D).
5. Pull rope to casualty tight by pulling tail end through
device (C).
6. Check all connections, then cut casualty's fall arrest
lanyard, with shears.
7. Remove the 'lock-off ' and gently lower casualty by
holding tail rope and squeezing device handle into
'sweet spot' (E).
The heightec Group Ltd, Lake District Business Park, Mint Bridge Road, Kendal, Cumbria, LA9 6NH, UK
REF: UI WK31 Issued: 17/06/2024
Prompt Sheet
c
A B
E
D
Revised: 18/06/2024 Approved: SBE
WK31 - RescuePack TM Reach - RescueHauler
This equipment should only be used by competent persons, who have been trained in the use of this specifi c kit.
These user instructions are to be read in conjunction with user instructions for each item of the kit.
Raising
1. Select an unquestionably sound anchorage structure,
above casualty.
2. Pass anchor strop (A) around anchorage and connect
karabiner to screwlink.
3. Fit open hook to end of pole. With control device in "go"
position detent, extend rope and pole to casualty (B).
Attach hook to harness and pull to release, ensuring
hook gate closes fully.
4. Lock handle and hauling catch (D).
5. Pull rope to casualty tight by pulling tail end through
device (C).
6. Attach Hurricane to casualty rope as shown (E). DO
NOT PUT DEVICE OVER EDGE
7. To raise casualty, pull tail rope (F).
8. When hauling-device reaches control-device, slide
hauling-device back down rope.
9. Repeat steps 6 & 7 to incrementally raise casualty as
required.
The heightec Group Ltd, Lake District Business Park, Mint Bridge Road, Kendal, Cumbria, LA9 6NH, UK
REF: UI WK31 Issued: 18/06/2024
Prompt Sheet
c
A B
E
D
Revised: 17/06/2024 Approved: SBE
