4 Installation
5. Place the top cover onto the protective
housing and secure them together using the
provided M4×10 bolts.
6. Attach the interlocks to the part of the cover
as shown.
a. Peel off the backing of one interlock.
b. Press the adhesive side firmly against the
indented part of the cover from inside,
being sure the trigger of the interlock
protrudes completely from the cover.
c. Repeat the process for the other interlock.
d. Arrange the cables using the provided
cable fixing clips.
Top Cover
M4×10 Bolts
M4×10 Bolts
Cable Fixing Clip
23
Interlock
