Operating Instructions

Air Purifier

IDEAL AP60 PRO

IDEAL AP80 PRO

AP60 80 PRO DE-NL 08-2022 9700284 20230130zm

Need help?

Do you have a question about the IDEAL AP60 PRO and is the answer not in the manual?

Questions and answers

Summary of Contents for KRUG+PRIESTER IDEAL AP60 PRO

Page 1 Operating Instructions Air Purifier IDEAL AP60 PRO IDEAL AP80 PRO AP60 80 PRO DE-NL 08-2022 9700284 20230130zm...
Page 2 Intended use Important safety instructions Product features Included in the box Unpacking and setting up Overview and description of parts Control panel Fan speeds Timer function Quiet function Air quality indicator Filter replacement indicator Daylight sensor IR receiver Air quality sensor Remote control (when using for the first time) Remote control (replacing the battery) Remote control (function)
Page 3 Important safety instructions Introduction Thank you for choosing a device from IDEAL. Intended use • The device is used exclusively for cleaning the ambient air indoors. • Please read these operating instructions before starting to use the device and please follow the safety instructions. The operating instructions must be kept available with the device at all times.
Page 4 Important safety instructions Important safety instructions • Children being supervised not to play with the appliance. • Do not block the air intake and outlet. • Keep this air purifier away from direct sunlight, naked flames or heat. • Only use the air purifier in closed interiors and within the specified technical parameters.
Page 5 Air Purifier Filter cartridge Remote control (including filter cartridge) • With self-adhesive magnetic film • With 3V lithium battery Air Purifier Operating Instructions IDEAL AP60 PRO IDEAL AP80 PRO Power cable Printed operating instructions AP60 80 PRO DE-NL 08-2022 9700284 20230130zm...
Page 6 Unpacking and setting up Installation guidelines for optimum performance: • The air intake ducts on the top can be used as handles (see adjacent diagram). • Place the device at least 10 cm away from the wall. • Keep the device away from areas subjected to draft (wind). •...
Page 7 Unpacking and setting up Hold the filter cartridge with both hands using the recessed grips provided and turn it anti-clockwise (9.). Take out the filter cartridge (10.) and remove the protective film (11.). Insert the filter cartridge with the three tabs in the notches provided and lock in position by turning clockwise (12.).
Page 8 Overview and description of parts Air outlet grill Control panel Air intake ducts Filter cartridge Front panel Power cable AP60 80 PRO DE-NL 08-2022 9700284 20230130zm...
Page 9 Control panel On/off button Air quality indicator Quiet button Fan speed button Timer button Fan speed indicator Timer indicator Filter replacement Daylight sensor Air quality sensor Quiet indicator indicator IR receiver Note: The air quality sensor (L) is recalibrated the first time you switch it on (A) and after being disconnected from the mains power supply.
Page 10 Control panel On/off button Air quality indicator Quiet button Fan speed button Timer button Fan speed indicator Timer indicator Filter replacement Daylight sensor Air quality sensor Quiet indicator indicator IR receiver Fan speeds • Press the on/off button (A) to switch the air purifier on or off. •...
Page 11 Control panel On/off button Air quality indicator Quiet button Fan speed button Timer button Fan speed indicator Timer indicator Filter replacement Daylight sensor Air quality sensor Quiet indicator indicator IR receiver Quiet function The Quiet button (D) is provided for particularly low-noise, unobtrusive operation (e.g. bedrooms). Press the Quiet button (D) to switch the fan speed (G) to its lowest capacity and switch off all indicators.
Page 12 Remote control Battery usage • Always use 3V lithium batteries CR2025 for the remote control. • Incorrect battery usage may result in leakage of battery fluid and/or damage. • If the remote control is not going to be used for a long time, please remove the battery. Unsuitable location •...
Page 13 Remote control Replacing the battery • Open the battery compartment by pressing (A) and pulling out (B) at the same time. Take out the flat battery. • Insert a new battery into the battery compartment, making sure the polarity is correct (+ / -). •...
Page 14 Remote control On/off button Quiet button Automatic button Turbo Auto Timer buttons Fan speed buttons Locking button Function Select the required fan speed Switches the air purifier to automatic mode Switches the air purifier on/off Switches the air purifier to Quiet mode Select the required timer time Press the locking button to lock the buttons on the control panel (air purifier).
Page 15 Changing the filter Filter replacement (e.g. in accordance with the filter replacement indicator F) Note: Only original IDEAL filter cartridges (order from www.mbmcorp.com) may be used. No tools are required to replace the filter cartridge. CAUTION: Disconnect the mains plug! The front panel is hooked in at the bottom in two places, and kept shut with 4 magnets.
Page 16 App Control / WLAN App Control Your purifier can additionally be controlled by the "IDEALAIRPRO" App via your smartphone/tablet (iOS /Android). WLAN Air quality indicator Quiet button Enabling/disabling WLAN The air purifier is connected to the power supply and switched off. Press and hold down the Quiet button (D) until the air quality indicator (E) flashes The WLAN is enabled ...
Page 17 Cleaning and maintenance / Accessories Cleaning and maintenance CAUTION: Disconnect the mains plug prior to any cleaning or maintenance work! • Replace the filter cartridge as soon as the filter replacement indicator (F) lights up. The average life expectancy of the filter is approx. 1 year (depending on operation and purification activities). •...
Page 18 Troubleshooting The air purifier won't switch on. Is the power cable securely connected to the back of the device?  Make sure that the power cable is not damaged in any way.  Check both ends of the power cable. Make sure that these are plugged in and that the purifier is connected to the power supply.
Page 19 Troubleshooting The indicators on the control panel do not Is the air purifier switched on? light up at all.  Switch the air purifier on by pressing the on/off button. Has the Quiet function been activated?  Disable the Quiet function by pressing the Quiet button.
Page 20 Troubleshooting The air purifier is making loud noises. Is the filter cartridge really dirty?  Clean the pre-filter with a vacuum cleaner. Is the air purifier located on an even surface?  Place the device on an even surface. Is the air purifier running at a high fan speed?...
Page 21 Technical data IDEAL AP60 PRO: Power supply 200-240V 50/60Hz / 100-120V 50/60Hz   Power consumption 90W (200-240V) / 75W (100-120V) Suitable for rooms 50 to 70 m² * Air flow rate (max.) 600 m³/h Dimensions (L × W × H) 468 ×...
Page 22 The company Krug + Priester has the following certifications: • Quality management system according to DIN EN ISO 9001:2015 • Environmental management system according to DIN EN ISO 14001:2015 • Energy management system according to DIN EN ISO 50001:2018 Storage We recommend storing the air purifier in its original packaging in a cool, dry place.
Page 23 Subject to technical changes. EC-declaration of conformity - Herewith we declare that GS-IDENT. No. UL-IDENT. No. IDEAL AP60 PRO Made in Germany 11874101 10874101 IDEAL AP80 PRO Made in Germany 11874102 10874102 - complies with the following provisons applying to it...
Page 24 Supplier‘s Declara�on of Conformity 47 CFR § 2.1077 Compliance Informa�on This device complies with part 15 of the FCC Rules. Opera�on is subject to the following two condi�ons: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired opera�on.
Page 25 Notes : AP60 80 PRO DE-NL 08-2022 9700284 20230130zm...
Page 26 Krug & Priester GmbH & Co. KG Simon-Schweitzer-Str. 34 D-72336 Balingen (Germany) AP60 80 PRO DE-NL 08-2022 9700284 20230130zm...
