Homedics AF-75 Manual

Technical Specifications

Input voltage	120 V
Rated Frequency	60 HZ
Power	38 Watts
Weight	8.50 lbs
Noise Level	<60 dB
Unit Height	13.5"

Main Features of the HoMedics Hypoallergenic HEPA Cleaner

Main Features

warning NOTE: This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of shock, this plug is intended to fit only one way in a polarized outlet. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. DO NOT attempt to defeat this safety feature. To do so could result in an electric shock hazard.

Control Panel

warning NOTE: The Clean/Reset Filter Indicator MUST be pressed to reset the indicator after you have cleaned and replaced the filter.

Operating Instructions

Turning the Unit On

Take the air cleaner out of the box and remove the clear protective plastic bag.
Place the air cleaner on a firm level surface.
Before turning the air cleaner ON, you need to check that the filters are firmly in place and did not become loose during shipping.

To check filter, open the front grill by pulling on the tabs on either side of the top of the grill plate. Fig. 1

Fig. 1
Open the plate outward until the tabs at the bottom of the grill plate easily slide away from the unit. Fig. 2

Fig. 2
The HEPA filter will be resting inside the unit. Make sure that the filter is firmly seated inside of the unit. Fig. 3

Fig. 3
Place the tabs at the bottom of the grill plate into the base of the unit. Gently push the grill plate back into place until you hear a click sound indicating that the grill is firmly latched. Fig. 4

Fig. 4
Plug the power cord into a standard AC outlet.

warning NOTE: Unit will not operate unless filter and grill are properly installed.

On/Off and Fan Speed Settings
- To turn the air cleaner on, press the ON/OFF Control. When the air cleaner is on, the ON/OFF Control will illuminate and the air cleaner will start to operate on LOW speed.
- This air cleaner has 3 fan speed settings: LOW (1), MEDIUM (2), and HIGH (3). The higher the fan speed setting, the more air will be cleaned. To select or change fan speed, slide the FAN SPEED Control until desired speed is reached.
- To turn the air cleaner off, press the ON/OFF Control.

Clean Filter Indicator Button

This air cleaner is equipped with a CLEAN FILTER indicator button to let you know when the HEPA filter requires cleaning. Generally this is every 480 hours of use. When the HEPA filter requires cleaning, the CLEAN FILTER indicator button on the control panel will illuminate.
If the air cleaner is used daily, we recommend cleaning the HEPA filter more frequently.

Replacing HEPA Filter

With regular cleaning the life of the HEPA filter is approximately 12-18 months under typical household usage and conditions. We recommend replacing your filter every year. To purchase replacement HEPA filters, model # AF-75FL, go back to your retailer (where you purchased your air cleaner), or visit www.homedics.com.

After cleaning or replacing the HEPA filter, be sure to reset the filter indicator by pressing the CLEAN/RESET FILTER INDICATOR BUTTON for several seconds until an audible chime sounds and the light turns off.

Cleaning the HEPA Filter

Make sure that the air cleaner is turned OFF and unplugged from the outlet before cleaning.

Open the front grill by gently pulling on the tabs on either side of the top of the grill plate. Fig. 5

Fig. 5
Open the plate outward until the tabs at the bottom of the grill plate easily slide away from the unit. Fig. 6

Fig. 6

Remove the HEPA filter from the main unit. Fig. 7

Fig. 7
Use the brush attachment with your vacuum cleaner. Run the attachment along both sides of the HEPA filter, cleaning thoroughly between the accordion folds of the filter. Fig. 8

Fig. 8
Place the clean HEPA filter back in the main unit, making sure it is firmly seated inside the unit. Fig. 9

Fig. 9
Place the tabs at the bottom of the grill plate into the base of the unit. Gently push the grill plate back into place until you hear a click sound indicating that the grill is firmly latched. Fig. 10

Fig. 10

Cleaning and Maintenance

For best performance, we recommend:

Vacuum the HEPA filter using the brush attachment of your vacuum cleaner once a month
NEVER use water or any household cleaners or detergents to clean the HEPA filter
Clean off the outside of the unit with a dry cloth once a month
NEVER use water, wax, polish, or any chemical solution to clean the outside of the unit
Clean off the grill plate using a damp cloth or the brush attachment of your vacuum once a month
NEVER use wax, polish, or any chemical solution to clean the grill plate
Replace the HEPA filter every 12-18 months

Troubleshooting

Problem	Possible Cause	Solution
Unit will not operate	Unit is not plugged in No power to unit	Plug unit in Press the ON/OFF button to turn the power on Check circuits, fuses, try a different outlet
Reduced airflow or poor filtering	The front grill may be blocked HEPA filter may be clogged	Check to make sure nothing is blocking the front grill and air outlet Check and clean filter Replace the filter
Excessive noise	The unit is not level	Place the unit on a flat, level surface
CLEAN FILTER indicator light will not go off	The filter needs to be cleaned The filter needs to be replaced CLEAN/RESET FILTER INDICATOR has not been reset	Remove filter from unit and clean using brush attachment on your vacuum Replace filter – Model # AF-75FL Press and hold the CLEAN/RESET FILTER INDICATOR BUTTON until an audible chime sounds and the light turns off

Service & Warranty

e-mail:
cservice@homedics.com
Monday-Friday 8:30 am – 7:00 pm (EST)

1-800-466-3342

LIMITED FIFE YEAR WARRANTY
To obtain warranty service on your HoMedics product, contact a Consumer Relations Representative by telephone at 1-800-466-3342 for assistance. Please make sure to have the model number of the product available.
No COD's will be accepted.

For more information regarding our product line in the USA, please visit: www.homedics.com

Register Your Product At: www.homedics.com/register
Your valuable input regarding this product will help us create the products you will want in the future.

IMPORTANT SAFETY INSTRUCTIONS

WHEN USING ELECTRICAL PRODUCTS, ESPECIALLY WHEN CHILDREN ARE PRESENT, BASIC SAFETY PRECAUTIONS SHOULD ALWAYS BE FOLLOWED, INCLUDING THE FOLLOWING:

READ ALL INSTRUCTIONS BEFORE USING

TO REDUCE THE RISK OF ELECTRIC SHOCK:

Always unplug the air cleaner from the electrical outlet immediately after using and before cleaning.
Keep cord away from heated surfaces.
Always place the air cleaner on a firm, level surface.
Always place the air cleaner at least six (6) inches away from walls and three (3) feet from heat sources such as stoves, radiators, or heaters.
DO NOT operate where aerosol (spray) products are being used or where oxygen is being administered.
DO NOT reach for an appliance that has fallen into water. Unplug it immediately.
DO NOT place or store appliance where it can fall or be pulled into a tub or sink.
DO NOT place in or drop into water or other liquid.
Keep dry - DO NOT operate in wet or moist conditions.
Check your air cleaner cord and plug connections. Faulty wall outlet connections or loose plugs can cause the outlet or plug to overheat. Be sure the plug fits tightly in the outlet.

TO REDUCE THE RISK OF BURNS, FIRE, ELECTRIC SHOCK OR INJURY TO PERSONS:

Extreme caution is necessary when any air cleaner is used by or near children or invalids and whenever the air cleaner is left operating and unattended.
Always unplug the air cleaner when not in use.
Do not operate the air cleaner with a damaged cord or plug, or after the air cleaner malfunctions, or has been dropped or damaged in any manner. Return to HoMedics Consumer Relations for examination, electrical or mechanical adjustment, or repair.
This air cleaner is not intended for use in bathroom, laundry areas and similar moist indoor locations. Never locate air cleaner where it may fall into a bathtub or other water container.
Do not run cord under carpeting. Do not cover cord with throw rugs, runners or similar coverings. Do not route cord under furniture or appliances. Arrange cord away from traffic areas where it can be tripped over.
To disconnect the air cleaner, first turn controls to the OFF position, then remove plug from outlet.
Do not tilt or move the air cleaner while it is in operation. Shut off and remove plug from outlet before moving.
Do not insert or allow foreign objects to enter any ventilation or exhaust opening as this may cause an electric shock or fire, or damage the air cleaner.
To prevent a possible fire, do not block air intakes or exhaust in any manner. Do not use on any soft surface, like a bed, where openings may become blocked.
Use this air cleaner only for its intended use as described in this manual. Any other use not recommended by the manufacturer may cause fire, electric shock, or injury to persons.
DO NOT use outdoors.

This product earned the ENERGY STAR by meeting strict energy efficiency guidelines set by the US EPA. US EPA does not endorse any manufacturer claims of healthier indoor air from the use of this product.

The energy efficiency of this ENERGY STAR qualified model is measured based on a ratio between the model's CADR for Dust and the electrical energy it consumes, or CADR/Watt.

SAVE THESE IMPORTANT INSTRUCTIONS FOR EASY REFERENCE
