4 Button Remote Start Security System With
Plug-In Shock Sensor & Starter Disable
IMPORTANT ! In order to provide you with the highest level of security to your
vehicle, this system is equipped with selectable manual override circuitry. It is
possible that you will need to override you security system if the transmitter
becomes lost, or inoperative due to battery failure. Reading the sections on
"Manually Overriding Your System" is necessary to fully understand the procedure
required to enable your vehicle in such situations. In addition, the chart on the last
page of this manual has a section for the particular features and options installed
in your vehicle as well as the override method selected. Although the default
mode is "Valet Switch" operation, the system can be configured for "Custom
Code" operation for enhanced security. Confirm the override mode selected on
the last page of this manual, and familiarize yourself with the section on it's opera-
tion.
FEATURES :
1 Two Way 3 Button Remote Control And 1 One Way 4 Button Remote Control
Six Channel Code Learning Programmable Receiver
External Superheterodyne Receiver Antenna
Single Or Two User Programmable W/Separate Control Outputs
Single Button Lock/Unlock or Separate Button Lock/Unlock or Both
Remote Keyless Entry With Optional Access Guard (must have power door
locks)
Selectable Manual Override Mode
New Enhanced Panic Feature (Any button other than unlock stops siren, no
change to the units state)
Smart Disarm (If triggered, elect to shut off siren, or disarm entire unit )
Selectable Automatic Timed Start Mode
Adjustable Shock Sensor Via The Transmitter (Pre-Detect Off, Pre & Full Detect
Off, City Mode)
Safe Start Output Controlled From Channel 3 (Option Channel 3 For Trunk, Or
For R/S)
Remote Panic In All Modes (Press & Hold Lock /Unlock Button For 3 Seconds
To Engage)
Improved Custom Code Override, User Selectable and Programmable
Protected Push Button Valet/Override Switch
7-Function LED-Arm / Disarm / Zone 1 / Zone 2 / Zone 3 / Valet / Arming
Intrusion Alert With Memory
Instant Siren Activation
TW-2
Owner's Manual
Advertisement
Related Manuals for Code Alarm TW-2
Summary of Contents for Code Alarm TW-2
- Page 1 TW-2 Owner’s Manual 4 Button Remote Start Security System With Plug-In Shock Sensor & Starter Disable IMPORTANT ! In order to provide you with the highest level of security to your vehicle, this system is equipped with selectable manual override circuitry. It is possible that you will need to override you security system if the transmitter becomes lost, or inoperative due to battery failure.
- Page 2 w Starter Disable Output w Additional Engine Immobilizer Output, (Optional Relay Required) w True Last Door Arming (Hardwire Only) w Defective Zone By-Pass w Defective Zone Chirp Confirmation (Unit Chirps To Report Zone Cleared) w 6 Tone Mini Siren (New AS-9903) w Car Horn Output For Additional Alarm Response (Improved Timing To Mini- mize RF Interference.) w Additional Negative Trigger Input (Hood &...
- Page 3 If your transmitter button is pressed more than fifty times while it is out of range of the vehicle (children playing with your keys), the transmitter will not operate when you return to the vehicle, and will need to be re aligned to the receiver. To do this, simply press button 1 two times within a one second time period.
- Page 4 Note: If the optional Headlamp illumination feature has been added, and has been selected for operation when arming, as an added convenience, the system will turn on the headlights when the system is armed. ARMING THE SYSTEM - PASSIVE (AUTOMATIC) 1.
- Page 5 DISARMING THE SYSTEM Note: If the optional 2 step door unlock circuit is installed, when the unlock transmit- ter button is activated, the drivers door only will unlock, pressing the unlock button a second time will cause all doors to unlock. Note: If your transmitter has been configured with single button Lock/Unlock as shown, to activate the all door unlock feature operate the Lock/Unlock button a second time within 3 seconds of the first unlock command.
- Page 6 þ Siren will not sound. If the siren sounds 4 chirps, then the alarm was triggered in your absence. Before turning the key on, examine the LED and refer to the INTRUSION WARNING SIGNALS section of this manual to identify which zone was triggered.
- Page 7 MANUALLY OVERRIDING YOUR SYSTEM: USING THE VALET SWITCH MANUAL OVERRIDE Your Security System can be disarmed without the use of the keychain transmitter. This is necessary, since you will need the ability to operate your vehicle if the transmitter is lost or its battery fails. If your system has been selected for Valet Switch manual override as indicated on the last page of this manual, to bypass the alarm system;...
- Page 8 Custom Code Programming Example: To Change the code from the factory preassigned code of 11 to “52” you would do the following: 1. Disarm the system by use of the transmitter, or by use of the emergency override sequence. 2. Turn the ignition switch to the on position. 3.
- Page 9 ELIMINATING THE NORMAL ARM / DISARM CHIRPS As explained earlier in the manual, you can eliminate the chirps selectively any time you arm or disarm the system simply by holding the ARM or DISARM button for two seconds. If you find the normal arming and disarming chirps annoying, they can be turned off permanently, eliminating the need to hold the ARM / DIS- ARM button for 2 seconds.
- Page 10 3. Stage 2 (Omit pre & full detect) In this mode, both the pre-detect stage, and the full trigger stage of the sensor are defeated. The unit will not react to vibration of any magnitude. 4. Stage 3 (City Mode) In this mode, the pre-detect chirps will change from six pre-warning tones to a full 10 seconds of warning chirps.
- Page 11 To Remote Start The Vehicle: Press and release the programmed channel of your keychain transmitter two times within 2 seconds. The vehicle will start and remain running for the pre-programmed 5, 10, 15, or 20 minutes. As a visual indication, the parking lights will flash or turn on depending on the programming set up by your installation center.
- Page 12 CANCELING THE AUTOMATIC START UP TIMER To cancel the automatic start up timer do one of the following; 1. Start the vehicle manually with the use of the ignition key and depress the brake pedal. 2. Remote start the vehicle using your keychain RF transmitter. OPTIONAL DEVICE OUTPUT ( CHANNEL 3 ) Controlled By: o Trunk/Key Button o Option Button o Lock + Unlock Buttons o Lock + Trunk/Key Buttons o Lock + Option Buttons o Unlock + Trunk/Key Buttons...
- Page 13 ADDITIONAL REMOTE FUNCTION ( CHANNEL 5 ) Controlled By: o Trunk/Key Button o Option Button o Lock + Unlock Buttons o Lock + Trunk/Key Buttons o Lock + Option Buttons o Unlock + Trunk/Key Buttons o Unlock + Option Buttons o Trunk/Key + Option Buttons Other Transmitter button configurations are also available.
- Page 14 This security system has an additional feature that can be connected to a number of different optional accessories. Some of the more common uses for this channel are; o Remote Car Starter o Remote Window Closure o Remote Garage Door Interface To remotely operate the device indicated, momentarily press, or press and hold the appropriate transmitter button(s) as indicated above.
- Page 15 When the Remote Start Function has been Operated, The three exhaust bars turn "ON", on the LED screen. Once the vehicle is running, the three bars will flash all the while the vehicle is running. When Panic Mode has been activated and the system is armed the vehicle's lights and the word ARM will flash on the LED screen.
- Page 16 Triggered and entry attempt was made to the vehicles hood or trunk. Triggered and entry attempt was made to the vehicles glass, or the vehicle has been hit or bumped hard enough to cause a response from the vibration detector.
- Page 17 ADDITIONAL ICONS THAT MAY BE DISPLAYED ARE: If the arm/disarm chirp tones have been turned off at the vehicle, when you arm, or disarm, the display will indicate this as shown, and there will be no arm/ disarm chirps at the transmitter. This is true if the transmitter is set for vibrate mode.
- Page 18 ADDITIONAL REMOTE FEATURES: The two way remote control unit allows you to access information from the vehicle, light the display, and toggle the transmitter from the mute to vibrate. To Access these features, do the following: Pressing this button for 1 second and releasing will turn the backlighting of the display on for 3 seconds.
- Page 19 APS 995 SYSTEM FUNCTIONS AT A GLANCE DASH LED INDICATORS RAPID FLASHING PASSIVE ARMING/ACTIVE REARMING SLOW FLASHING ARMED DISARMED ON SOLID VALET MODE 3 FLASH...PAUSE INTRUSION ZONE 3 2 FLASH...PAUSE INTRUSION ZONE 2 1 FLASH...PAUSE INTRUSION ZONE 1 SIREN CHIRP INDICATORS 1 CHIRP * 2 CHIRPS * DISARM...
- Page 20 © 2001 Audiovox Electronics Corp., 150 Marcus Blvd., Hauppauge, NY 11788 8-6165...
