Attention:
To ensure sufficient ventilation, keep the spacing shown as below:
-
(add line drawing)
Do not remove the plastic cover of FM Antenna (A) at the back of the unit.
-
(add line drawing)
Main Unit Front Panel Description
1. CD Player.
2. ON/STANDBY button to turn on or off the unit. Press over 5 seconds. It turns
to ECO mode and also back to STANDBY mode when pressed over 5
seconds again.
3. SOURCE button to select TUNER, CD, UDISK (for USB), SD/MMC, iPOD,
and AUX source.
4. BAND/FOLDER button to select MW or FM band in radio mode or folder
selection during MP3/WMA playback.
5. ST/MONO button to select stereo or mono output for FM band.
6. PROG/PRESET button to enter program mode to select program playback,
or to memorize stations for tuner ,auto scan and preset tuner stations when
pressed over 5 secs.
7.
button to select next track in CD/USB/SD-MMC/iPOD mode, when
pressed long it will change to fast forward play, or to adjust the clock during
clock/timer/alarm setting or to increase the frequency in Tuner mode.
8.
button to select previous track in CD/USB/SD-MMC/iPOD mode, hwne
pressed long it will change to fast backward play ,or to adjust the clock
during clock/timer/alarm setting or to decrease the frequency in Tuner
mode.
9. RANDOM button to select random playback in CD/USB/SD-MMC/IPOD
mode ,or to select the previous preset channel in Tuner mode
10. phones.
11. SD/MMC CARD slot for SD or MMC card memory.
12. USB slot for USB memory.
13. Remote sensor to receive the remote control signal.
14. LCD display.
15.
button to eject CD disc
16. MENU button to enable menu mode.
17. VOL + Button to increase the Volume
18. VOL– Button to decrease the Volume
19.
button to play or pause a track in CD/USB/SD-MMC/iPOD playback or to

Advertisement

loading
Need help?

Need help?

Do you have a question about the MCI-200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LENCO MCI-200

Summary of Contents for LENCO MCI-200

  • Page 1 Attention: To ensure sufficient ventilation, keep the spacing shown as below: (add line drawing) Do not remove the plastic cover of FM Antenna (A) at the back of the unit. (add line drawing) Main Unit Front Panel Description 1. CD Player. 2.
  • Page 2 confirm the selection in MENU mode. button to stop CD/USB/SD-MMC/iPOD playback or to return to the previous menu page. 21. RPT button to select repeat playback or to select the next preset channel in tuner mode Main Unit Top Panel Description 1.
  • Page 3 playback, or to memorize for tuner , auto scan and preset tuner channels when it is pressed over 5 seconds 15. RAND/ button to select random playback or to set the channel number / select a preset channel in TUNER mode, / ESC button to stop CD/USB/SD-MMC/iPOD playback or to return to the previous menu page.
  • Page 4 pressed for 10 seconds. Setting the Clock 1. Press the Menu button repeatedly until “CLCOK” is shown, then press the /ENTER button to confirm. 2. Press the button to select 24Hr or 12Hr display, then press the /ENTER button to confirm. 3.
  • Page 5 /ENTER button to confirm. 3. Press the / ESC button to escape or it will automatically return to the previous page if no button is pressed for 10 seconds. Setting the BASS 1. Press the Menu button repeatedly until “BASS” is shown, then press the /ENTER button to confirm.
  • Page 6 a. Press the button to skip to next track. b. Press the button once to skip to the beginning of the current track. Press it twice to skip to the previous track. Search within a track During playback, hold and press the button to search for a desired point, then release the button.
  • Page 7 Press the RANDOM button on the main unit or remote control to playback the files in random order. The symbol “???”will be shown in the display. 11. Eject CD Press the button on the main unit or remote control to eject the CD. IPOD Operation 1.
  • Page 8 Operation – Tuning a Radio Station. 2. Press the PROG/PRESET button to enter tuning save mode. The symbol “MEM” will be displayed. E.g. “FM 104.75 M: 01” with 01 flashing, where M: 01 is program number. 3. Within 10 seconds, press the RPT or RANDOM button to select the desired program number.
  • Page 9 At FM mode, extend and position the FM antenna to achieve optimum reception. At MW mode, orientate the main unit to achieve optimum reception.
