- Page 1 TYTUŁ WYDARZENIA USER MANUAL ORVALDI LT-1100 – LT-2000 – LT-3000 Sinus Tower ORVALDI POWER PROTECTION SP. Z O.O. 02-017 Warszawa; Aleje Jerozolimskie 123 orvaldi@orvaldi.com | www.orvaldi.com...
- Page 2 ORVALDI LT-1100 – LT-2000 – LT-3000 Sinus Tower ORVALDI Power Protection Sp. z o.o. ul. Wrocławska 33d; 55-090 Długołęka www.orvaldi.com.pl Version: 1.1...
- Page 3 Table of Contents 1. Important Safety Warning ....................1 1-1. Transportation ......................1 1-2. Preparation ....................... 1 1-3. Installation ....................... 1 1-4. Operation ......................... 1 1-5. Maintenance, service and faults ................. 2 2. Installation And Setup ...................... 4 2-1. Rear panel view ......................4 2-2.
- Page 4 1. Important Safety Warning Please comply with all warnings and operating instructions in this manual strictly. Save this manual properly and read carefully the following instructions before installing the unit. Do not operate this unit before reading through all safety information and operating instructions carefully 1-1.
- Page 5 1-5. Maintenance, service and faults The UPS system operates with hazardous voltages. Repairs may be carried out only by qualified maintenance personnel. Caution - risk of electric shock. Even after the unit is disconnected from the mains (building wiring outlet), components inside the UPS system are still connected to the battery and electrically live and dangerous.
- Page 6 For UPS with internally mounted battery Instructions shall carry sufficient information to enable the replacement of the battery with a suitable manufacturer and catalogue number. Safety instructions to allow access by Service Personnel shall be stated in the installation/service handbook. If batteries are to be installed by Service Personnel, instructions for interconnections, including terminal torque, shall be provided.
- Page 7 2. Installation And Setup NOTE: Before installation, please inspect the unit. Be sure that nothing inside the package is damaged. Please keep the original package in a safe place for future use. 2-1. Rear panel view IEC Type 1.1K/1.5K 2K/3K NEMA Type 1.1K/1.5K 1.
- Page 8 2-2. Operating principle The operating principle of the UPS is shown as below. Output EMI/RFI Inverter Filters DC-to-DC Converter Battery Battery Charger The UPS is composed of mains input, EMI/RFI filters, inverter, battery charger, DC-to-DC converter, battery, AVR TX and UPS output 2-3.
- Page 9 Step 1: UPS input connection Plug the UPS into a two-pole, three-wire, grounded receptacle only. Avoid using extension cords. Step 2: UPS output connection There two kinds of outputs: programmable outlets and general outlets. Please connect non- critical devices to the programmable outlets and critical devices to the general outlets. During power failure, you may extend the backup time to critical devices by setting shorter backup time for non-critical devices.
- Page 10 3. Operations 3-1. Button operation Button Function Turn on the UPS: Press and hold ON/Mute button for at least 2 seconds to turn on the UPS. Mute the alarm: After the UPS is turned on in battery mode, press and hold this button for at least 3 seconds to disable or enable the alarm system.
- Page 11 Configuration and fault information Indicates the configuration items, and the configuration items are listed in details in section 3-5. Indicates the warning and fault codes, and the codes are listed in details in section 3-7 and 3-8. Mute operation Indicates that the UPS alarm is disabled. Input, Battery, Temperature, Output &...
- Page 12 3-4. LCD display wordings index Abbreviation Display content Meaning Enable Disable Escape Active Open Active Close Battery Low Over Load No Connect Over Charge Site wiring fault Temperature Charger Battery Fault Battery Replace EEPROM error 3-5. UPS Setting Parameter 2 There are two parameters to set up the UPS.
- Page 13 115: presents output voltage is 115Vac 120: presents output voltage is 120Vac (Default) 127: presents output voltage is 127Vac 02: Programmable outlets enable/disable Interface Setting Parameter 2: Enable or disable programmable outlets. ENA: Programmable outlets enable DIS: Programmable outlets disable (Default) 03: Programmable outlets setting ...
- Page 14 Steps for setting programmable outlet Step 1: Before entering setting mode, the UPS should be in Stand-by mode (off-charging) and make sure the battery is connected. The LCD display is shown as right. Step 2: Press and hold the “Selection” button for 3 seconds to enter Setting mode.
- Page 15 Standby mode UPS is powered off and no output supply power, but still can charge batteries. Fault mode When a fault occurs, the ERROR icon and the fault code will be displayed. 3-7. Faults Reference Code Fault event Fault code Icon Fault event Fault code Icon Bus start fail...
- Page 16 4. Troubleshooting If the UPS system does not operate correctly, please solve the problem by using the table below. Symptom Possible cause Remedy No indication and alarm even The AC input power is not Check if input power cord though the mains is normal. connected well.
- Page 17 Symptom Possible cause Remedy The UPS shut down Check output wiring and if Fault code is shown as 14 on automatically because short connected devices are in LCD display and alarm is circuit occurs on the UPS short circuit status. continuously sounding.
- Page 18 6. Specifications MODEL 1.1K 1.5K CAPACITY 1100 VA / 770 W 1500 VA / 1050 W 2000 VA / 1400 W 3000 VA / 2100 W INPUT 81-134 VAC/86-139 VAC/89-145AVC/102-152 VAC Acceptable Voltage Range or 162-268 VAC/162-268 VAC/170-280AVC/177-290 VAC Frequency Range 60/50 Hz ±...
