Polygroup TGK0P5154C00 Assembly Instructions

TREE ASSEMBLY INSTRUCTIONS
Congratulations on purchasing your new tree from
Carefully follow the instructions below on how to quickly and easily set up your new tree.
TREE BASE ASSEMBLY
Follow below steps:
A: Connect part 1 to 2, then screw part 7(Bolt).
B: Connect part 2 to 3, then screw part 8(Bolt).
C: Insert tree section 7 to bottom cross frame,
and then insert tree section 6 to 7, then
section 5 to 6.
D: Connect part 3 to part 4, then screw part 7(Bolt).
E: Connect part 4 to part 6, then screw part 8(Bolt).
F: Insert the tree section 4 to section 5, insert tree
section 3 to section 4, section 2 to section 3,
finally section 1 to section 2.
11
4
8
3
MODEL #: TGK0P5154C00
Polygroup®!
No.
10
11
12
7
5
6
10
8
12
9
2
PART LIST
Name
1 Bottom Cross Frame
2 Horizontal Connection Frame
3 Vertical Connection T ube
4 Vertical Connection T ube
5 Vertical Connection T ube
6 Tube For Hooking Branches
7 Top Cross Flame
8 Bolt - Spec M8*16mm
9 Bolt - Spec M8*50mm
Nut - Spec M8
Bolt - Spec M6*10mm
Triangle Bolt - Spec M6*18mm
12
9
1
9
1
Qty .
1 PCS
4 PCS
4 PCS
4 PCS
4 PCS
7 PCS
4 PCS
8 PCS
8 PCS
8 PCS
4 PCS
6 PCS
