Dimensions: ISE2
Grommet type: ISE2-
L
2-ø3.5
Mounting hole
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
Compact Pressure Switch
01
„ -
T1
01
-15
T1
Pressure setting trimmer
SET
H
Indicator light (Red)
20
Piping port
13
M5 x 0.8 depth 5
Connector type: ISE2-
2-ø3.5
01: R 1/8
Mounting hole
T1: NPTF 1/8
ZSE2/ISE2
Series
01
-15C
T1
Pressure setting trimmer
SET
L H
Indicator light (Red)
20
Piping port
13
M5 x 0.8 depth 5
