ZSE2/ISE2 Specifications
Operating pressure range/
Regulating pressure range
Proof pressure
Fluid
Power supply voltage
Current consumption
Response time
Repeatability
Enclosure
Operating temperature range
Operating humidity range
Vibration resistance
Impact resistance
Temperature characteristics
(Based on 25°C)
Withstand voltage
Insulation resistance
Port size
Weight
Output Specifications
Model
Output type
Residual voltage
Hysteresis
Number of outputs
Indicator light
Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from
Compact Pressure Switch
ZSE2
For vacuum
0 to –101 kPa
500 kPa
Air/Non-corrosive, non-flammable gas
12 to 24 VDC ±10%, Ripple (P-P) 10% or less
Operating: 0 to 60°C, Stored: –10 to 60°C (With no condensation, nor freezing)
Operating/Stored: 35 to 85%RH (With no condensation)
10 to 500 Hz at whichever is smaller of 1.5 mm amplitude or 98 m/s
in X, Y, Z directions for 2 hrs. each (De-energized)
980 m/s
1000 VAC for 1 min. (Between lead wires and case)
50 MΩ or more (at 500 VDC by megameter)
01: R 1/8
0X: With suction filter (For mounting on ZX unit) 0R: Base mount type (For mounting on ZR unit)
35 g (Including 0.6 m—Long lead wire)
15
-
NPN open collector 30 V, 80 mA
1 V or less (
Series
ISE2L
For low pressure
0 to 100 kPa
17 mA or less at 24 VDC
5 ms or less
±1% F.S. or less
IP40
2
in X, Y, Z directions, 3 times each (De-energized)
±3% F.S. or less
M5 x 0.8 T1: NPTF 1/8, M5 x 0.8
,
PNP open collector 80 mA
With load current of 80 mA
3% F.S. or less (Fixed)
1
ON: when output is ON (Red)
ZSE2/ISE2
ISE2
For high pressure
0 to 1 MPa
1.5 MPa
2
acceleration,
55
-
)
16-6-9
