- Page 1 Digital Convection Heater Model Number: RHCVH2003 (B) 220-240V AC 50Hz/60Hz 1830W - 2180W This product is only suitable for well insulated spaces or occasional use PLEASE RETAIN FOR FUTURE REFERENCE...
- Page 2 CONTENTS Page(s) Safety Instructions and Electrical Safety 3 – 6 Battery Replacement Information Feature Diagram Base Assembly Control Panel and Remote Operations and Functions 11 - 14 Cleaning and Care Problem Solving Guarantee and Customer Services Spare Parts Connection to the Mains Supply Specification Notes 21 - 23...
- Page 3 SAFETY INSTRUCTIONS When using electrical appliances, basic safety precautions should always be observed, including the following: • Read all instructions. • Check that the mains voltage corresponds with the rating on the appliance. • This appliance must be positioned upright on the floor away from curtains, furniture or wall coverings and other flammable items.
- Page 4 SAFETY INSTRUCTIONS • Never remove parts from the appliance, such as the feet, screws and so on. • Never use the appliance near a bath, shower or a swimming pool. • Never place flammable objects or clothing on top of the appliance.
- Page 5 SAFETY INSTRUCTIONS • Do not operate this appliance for any thing other than its intended use. • This appliance is not intended for commercial use • This product is intended for household use only. Do not use outdoors. • This product is only intended for heating. •...
- Page 6 SAFETY INSTRUCTIONS Electrical Safety THIS APPLIANCE MUST BE PLUGGED INTO AN EARTHED SOCKET • Before switching on, make sure that the voltage of your electricity supply is the same as that indicated on the rating plate. This product is designed to operate on 220 - 240V AC 50Hz/60Hz. Connection to any other power source may damage the unit.
- Page 7 BATTERY REPLACEMENT INFORMATION This appliance comes with 1 CR2025 (3V) battery which is to be fitted into the remote. • CAUTION : Batteries are a chemical burn and choking hazard. Keep batteries away from children. • Ensure that the battery compartment is always completely secure. If the battery compartment does not close securely, stop using the remote, remove the batteries, and keep it away from children.
- Page 8 FEATURE DIAGRAM 1. Air outlet 4. Power switch 2. Control panel & LED display 5. Feet 3. Handles 6. Remote control...
- Page 9 BASE ASSEMBLY Before using the heater, the feet must be fitted to the unit. These are to be attached to the base of the heater using the 2 screws provided. Carefully lie the heater on its side, clip on the feet and secure by inserting the screws, taking care to ensure that they are located correctly in the bottom ends of the plastic mouldings.
- Page 10 CONTROL PANEL & REMOTE A. LED display B. Remote control receiver C. Power on/off button D. Mode selection button E. Temperature/timer increase button F. Temperature/timer decrease button G. Temperature button H. Timer button...
- Page 11 OPERATIONS AND FUNCTIONS Before connecting your appliance to the mains socket, position the appliance upright on the floor, at least 100cm away from the wall, curtains, furniture or wall coverings. Insert the mains plug into a suitable wall mains socket. Then use the “Power Switch”...
- Page 12 OPERATIONS AND FUNCTIONS Temperature Button • When the unit is on, press the “Temperature” button on the appliance/remote control. • The “Temperature”, “+” and “-” buttons will illuminate, and the current set temperature will be displayed and flash. • Use the “+” or “-” buttons on the appliance/remote control to adjust the temperature from 7℃...
- Page 13 OPERATIONS AND FUNCTIONS Timer Button • When the power is on, you can schedule to shut off the heater, or when in standby mode you can schedule to turn on the heater. • To set press the “Timer” button; the “Timer”, “+” and “-”...
- Page 14 OPERATIONS AND FUNCTIONS PLEASE NOTE: Once the appliance has been plugged into the mains, if there is no operation within 3 minutes. The unit will then enter standby mode, as shown by the “Power On/Off and “Timer” button lowly lit. Your heater is now ready for use. Other Functions Memory Function - If the heater is turned off then on again using the “Power On/Off”...
- Page 15 CLEANING AND CARE WARNING: Electrical Shock Hazard. Before you clean the appliance, disconnect the mains plug from the wall socket. • Allow the appliance to cool down completely before cleaning. • Do not immerse cord, plug or appliance in any liquid or allow moisture to come into contact with electrical parts.
- Page 16 PROBLEM SOLVING My appliance does not work when I turn it on: 1. Check that your appliance is plugged in and the power is turned on at the mains socket. 2. Try another mains socket. 3. Check the appliance is in an upright position. 4.
- Page 17 GUARANTEE AND CUSTOMER SERVICES This product is guaranteed for 12 months from the date of the original purchase. If any defect arises due to faulty materials or workmanship, the faulty product must be returned to the place of purchase. Refund or replacement is at the discretion of the retailer. The following conditions apply: •...
- Page 18 SPARE PARTS To check the availability of the following spare parts, simply contact our friendly Customer Services team using the details provided on the previous page. Feet and screws Remote control...
- Page 19 CONNECTION TO THE MAINS SUPPLY This appliance is designed to operate from a mains supply of 220-240V~50Hz/60Hz. Check that the voltage marked on the product corresponds with your supply voltage. How to change the fuse 1. Slot the end of a screwdriver into the recess in the fuse holder of the plug.
- Page 20 SPECIFICATION Model number RHCVH2003 (B) Rated voltage 220V - 240V ~ 50Hz/60Hz Power consumption 1830W - 2180W Product dimensions (CMS) (H)60 x (W) 18.5 x (D) 39.5 Model number RHCVH2003 (B) Item Symbol Value Unit Item Unit Heat output Type of heat input, for electric storage local space heaters only...
- Page 21 NOTES...
- Page 22 NOTES...
- Page 23 NOTES...
- Page 24 Swan Lane, Hindley Green, Wigan, WN2 4AY, United Kingdom / Product Care (Ireland) Ltd, Unit 3D North Point House, North Point Business Park, New Mallow Road, Cork, T23 AT2P, Ireland. Russell Hobbs is the registered trademark of Spectrum Brands (UK) Ltd.
