Contents Introduction Warning Caution Main Unit Description Remote Control OSD basic adjustment DTV Features USB/CARD Reader Operation Specifications Trouble Shooting...
Introduction Thank you very much for your purchase of our product of LCD TV. It serves as a normal color TV and PC monitor. To enjoy your set to the full from the very beginning, read this manual carefully and keep it handy for ready reference. INSTALLATION ①...
Warning CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO AVOID THE RISK OF ELECTRIC SHOCK. DO NOT REMOVE COVER (OR BACK). NO USER- SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This symbol is intended to alert the user to avoid the risk of electric shock, do not disassemble this equipment by anyone except a qualified service personnel.
Caution Caution High voltages are used in the operation of this product. Do not remove the back cabinet from your set. Refer servicing to qualified service personnel. Caution To prevent fire or electrical shock hazard, Do not expose the main unit to moisture. Caution Do not drop or push objects into the television cabinet slots or openings.
Page 6
Caution Caution Never stand on, lean on, push suddenly the product or its stand. You should pay special attention to children. Caution Do not place the main unit on an unstable cart stand, shelf or table. Serious injury to an individual, and damage to the television, may result if it should fall.
Main unit description Control Panel Button Function VOL+ : Volume up. VOL- : Volume down. CH+ : TV channel up. CH- : TV channel down. MENU : Press to select the main menu. TV/AV : Select the input signal. POWER : Switch on when at standby mode or enter the standby mode. TV Terminal Connections .USB input terminal.
Page 8
Optional Configuration as below: Connect the USB/CARD storage to the USB/CARD jack on the set. NOTE ● It is only 500 mA MAX of DC current output when you connect with USB jack or CARD socket. ● To ensure the Mobile HD works well, you should use other power supply for the Mobile HD. And do not use the USB jack and CARD socket in the same time.
Remote control POWER: Press this button to switch on the TV when at standby mode or enter standby mode. MUTE: Press this button to mute or restore sound. NICAM/A2: In the TV condition, press this key to select the sound effects. SLEEP: Set the sleep timer.
Page 10
EPG: Enter electronic program guide. (Used for models with DTV function only) :Stop playing the MEDIA or stop to record. (Used for models with USB/CR function only) SUBTITLE: Open or close subtitle. (Used for models with DTV function only) TEXT: Press to enter the Teletext mode. (Used for European region only) :Press to start playing the MEDIA or to pause playing.
OSD basic adjustment Picture You can select the type of picture, which best corresponds to your viewing. 1. Press the “MENU” button to enter the OSD menu. Then press “ / ” button to select the “PICTURE” menu. Enter the “PICTURE”...
Page 12
Press “ / ” button to select “BALANCE” and press the “ / ” button to enter balance adjustment menu to adjust balance. Press “ / ” button to select “AVL” and press the “ / ”button to select the avl function on or off.
Page 13
Press “ / ” button to select “AUTO SEARCH” and press the “ENTER” button to enter. Press “ / ” button to select “YES” or “NO”. 4. Press “ / ” button to select “MANUAL SEARCH” and press the “ENTER” button to enter.
Page 14
e. Press “ / ” button to select the channel in the list, press “ENTER” button to enter the rename channel’s window. Input channel name at “____”, press “ / / ” button to select “letter”, “number”, “_”, “〔”, “〕”, “EMPTY” or “BAK SPC”, and press “ENTER”...
Page 15
3. Press “ / ” button to select “AUTO SEARCH” and press the “ENTER” button to enter. Press “ / ” button to select “YES” or “NO”. 4. Press “ / ” button to select “MANUAL SEARCH” and press the “ENTER” button to enter.
Page 16
d. DEL TV CH. Press “ / ” button to select “DEL TV CH ” and press the “ENTER” button to enter . Press “ / ” button to select “YES” or “NO”, press “ENTER” button to delete all TV channels when select “YES”, press “ENTER”...
Page 17
rating . e. RECORD SET. (1) RECORD START Press “ / ” button to select “RECORD START” and press the “ENTER” button to start record . (2) FILE MANAGER Press “ / ” button to select “FILE MANAGER” and press the “ENTER” button to enter.
DTV Features Favourite List When the source is selected as DTV, users can enter “FAVOURITE LIST ”by pressing “FAV” button. The “Favourite LIST” window is illustrated as follow: Program Information When the source is selected as DTV, you can press “INFO” button to display the channel’s information.
Page 19
Weekly Mode: The “GREEN” button enables the WEEKLY MODE, the program guide is listed and sorted by weekly time Extend Mode: The “YELLOW” button enables the EXTEND MODE, the program guide window contains detailed information about the program. “EPG” is used for enter or closing the EPG window.
USB/CARD Reader Operation 1. Press the “SOURCE” button to spring the “SOURCE” menu, the default menu of input is “USB”. 2. Press the “ENTER” button to enter the “USB” source. 3. The default choice is “MOVIE”. And to press the “RED” button can enter the “MOVIE”...
Trouble Shooting Before consulting service personnel, check the following chart for a possible cause of the trouble you are experiencing and for a solution. PROBLEM SOLUTION ●Make sure the power cord is plugged in. TV will not turn on ●The batteries in the remote control may be exhausted replace the batteries.
