Summary of Contents for Sony BRAVIA KLV-32CX32D
- Page 1 4-270-478-13(1) LCD Colour TV Start-up Guide Operating the TV Operating Instructions Using Optional Equipment Using Menu Functions Additional Information KLV-32CX32D...
- Page 2 , DivX Certified and associated logos are Introduction trademarks of DivX, Inc. and are used under license. Thank you for choosing this Sony product. ® Before operating the TV, please read this manual ABOUT DIVX VIDEO: DivX is a digital video thoroughly and retain it for future reference.
- Page 3 IMPORTANT INFORMATION If a television is not positioned in a sufficiently stable location, it can be potentially hazardous due to falling. Many injuries, particularly to children, can be avoided by taking simple precautions such as: • Using cabinets or stands recommended by the manufacturer of the television.
- Page 5 Table of Contents Start-up Guide Using Menu Functions Checking the accessories ........6 Navigating through menus ....... 18 1: Attaching the stand.........6 Using the Favourites ........18 2: Connecting an antenna/cable/VCR ....7 Playing back photo/music/video via USB..19 3: Preventing the TV from toppling over .....7 Listening to the FM Radio ........
- Page 6 Start-up Guide Checking the accessories 1: Attaching the stand • Refer to the supplied stand leaflet for proper Stand (1) and screws (8) attachment for some TV models. Remote RM-GA020 (1) • For best picture quality, do not expose the screen to Size AA batteries (R6 type) (2) direct illumination or sunlight.
- Page 7 Tie the wood screw and the machine screw with a strong cord (not supplied). z • An optional Sony support belt kit is used to secure the TV. Contact your nearest Sony service centre to purchase a kit. Have your TV model name ready for reference.
- Page 8 4: Performing the initial Watching TV set-up Press 1 on the TV to turn on the TV. Press the number buttons or PROG +/– to select a TV channel. Press 2 +/– to adjust the volume. Adjusting the viewing angle of the TV This TV can be adjusted within the angles shown below.
- Page 9 TV AC power outlet. may result. – Use only Sony supplied AC power cords, not those of other brands. • When lifting or moving the TV set, hold it – Insert the plug fully into the AC power outlet.
- Page 10 To avoid material degradation or screen following problems occur. coating degradation, observe the following Ask your dealer or Sony service centre to precautions. have it checked by qualified service • To remove dust from the screen surface/ personnel.
- Page 11 • If the TV is brought directly from a cold to a warm location, or is placed in a very Safety information damp room, or is placed in a room in which heating has just been turned on, about built-in DVD moisture may condense on the surface or inside the TV.
- Page 12 Operating the TV Overview of the remote – Input select / Text hold • Displays the connected equipment list and selects the input source (page 16). • In Text mode: Holds the current page. 2 SYNC MENU Press to display the BRAVIA Sync Menu and then select connected HDMI equipment from “HDMI Device Selection”.
- Page 13 qa 2 +/– – Volume Adjusts volume. qs % – Mute Press to mute the sound. Press again to restore the sound. qd "/1 – TV standby Press to turn the TV on or to switch to standby mode. qf AUDIO – Dual Sound (page 29) In DVD mode: Switches between the original and dubbing languages* while playing.
- Page 14 Overview of the TV buttons and indicators 1 Z – Eject Ejects the disc. 2 N – Play Starts disc playback. 3 x – Stop Stops disc playback. 4 1 – Power Press to turn the TV on or to switch to standby mode. •...
- Page 15 Using Optional Equipment Connecting optional equipment You can connect a wide range of optional equipment to your TV. player Home with Blu-ray (HDMI- theatre Audio HDMI Disc output) system system Camcorder output player Digital still camera Camcorder USB storage media S VHS/ Hi8/DVC camcorder...
- Page 16 • You cannot use the component video jack and the video jack 1 at the same time. You can enjoy photo/music/video files stored in a Sony digital still camera, camcorder or USB storage device (page 19). Connect to the video jack 2 and the audio jacks 2.
- Page 17 Viewing Twin Picture Viewing PIP (Picture in Picture) You can view two pictures (in PC input mode) on the You can view two pictures (in Component and HDMI screen simultaneously. input mode) on the screen simultaneously. Connect a PC (page 15), and make sure that images Connect the optional equipment (page 15), and make from a PC appear on the screen (page 16).
- Page 18 Using Menu Functions Navigating through menus The HOME button allows you to access a variety of TV settings, USB media files, FM Radio mode, DVD mode and Karaoke mode. Press HOME on the TV or remote. Press to select an option, then press Follow the instructions on the screen.
- Page 19 Playing back photo/music/video via USB You can enjoy photo/music/video files stored in a Sony digital still camera or camcorder through a USB cable or USB storage device on your TV. Connect a supported USB device to the TV. Press HOME.
- Page 20 – Do not remove the USB device. The data on the USB device may be damaged. • Sony will not be held liable for any damage to, or loss of, data on the recording media due to a malfunction of any connected devices or the TV.
- Page 21 USB Video format Extension Container Video Codec Audio Codec DivX 3.11/4.x/5.1 PCM / MPEG1 Layer1, 2 / MP3 / XviD MPEG2 AAC (2ch) / MPEG1 MPEG4 AAC (2ch) / .avi MPEG4 HE-AAC (2ch) / MPEG2 MP Dolby Digital (2ch) / H.264 BP/MP/HP WMA v8 MPEG-4 SP/ASP...
- Page 22 Listening to the FM Radio You are able to listen to the FM radio stations using your TV by connecting an antenna (page 7). FM Radio tuning range is from 87.5-108.0 MHz. When you use the FM Radio function for the first time, press HOME and select “FM Radio”, then perform “Auto Tuning”...
- Page 23 Playing a DVD Getting ready Playing a DVD Press 1 on the TV, or "/1 on the remote to Playing a title turn on the TV. The Standby indicator on the After the DVD is read, playback starts front panel of the TV changes to green from automatically.
- Page 24 Step-by-step chapter selection Press AUDIO during playback. For example, the following information, which Press > to select the next chapter during indicates the current dubbing language, appears playback. on the screen briefly: Press . to select the previous chapter Audio 1/4: Dolby Digital 3/2.1 CH English during playback.
- Page 25 To activate PBC Press x twice, then press N to start playback. Enjoying Karaoke To deactivate PBC Press number buttons to select the title during Using Karaoke playback. z • While PBC is on, press OPTIONS and select “Top You can enjoy karaoke by setting this TV to karaoke Menu”...
- Page 26 Adjusts the volume (2 +/–) and mutes the sound (%) of a connected audio system. • You can operate the connected Sony equipment that has the BRAVIA Sync logo by the TV remote. Possible operations with BRAVIA Sync buttons, see page 12.
- Page 27 Settings adjustment • The options you can adjust vary depending on the situation. Unavailable options are greyed out or not displayed. Picture Picture Mode Sets a picture mode. The options that can be selected differ depending on the “Scene Select” settings. “Vivid”: Enhances picture contrast and sharpness.
- Page 28 Advanced Settings Allows you to set “Picture” settings in more detail. These settings are not available when “Picture Mode” is set to “Vivid”. “Reset”: Resets all the advanced settings to the factory settings. “Adv. Contrast Enhancer”: Automatically adjusts “Backlight” and “Picture” to the most suitable settings judging from the brightness of the screen.
- Page 29 Surround Allows you to select the suitable surround effects depending on the genre of TV programme (movie, sport, music, etc.) or video game. The options that can be selected differ depending on the “Scene Select” settings. “On”: Delivers surround effects that help you enjoy the virtual two-ch surround audio with just the two internal TV speakers.
- Page 30 Screen Wide Mode For details about wide mode, see page 13. Auto Wide Automatically changes the wide mode according to the input signal from an external equipment. To keep your setting, select “Off”. • “Auto Wide” is only available when watching programmes from video input, HDMI and component input in format 480i or 576i.
- Page 31 PC input signal reference chart for PC and HDMI IN 1, 2 Horizontal Horizontal Vertical Signals Vertical (Line) Standard (Pixel) frequency (kHz) frequency (Hz) 31.5 SVGA 37.9 VESA Guidelines 1024 48.4 VESA Guidelines WXGA 1280 47.4 VESA WXGA 1280 47.8 VESA WXGA 1360...
- Page 32 Manual Programme Before selecting “Label”/“AFT”/“Audio Filter”/“Skip”/“Colour System”, press PROG +/– to select the programme number with the channel. You cannot select a programme Preset number that is set to “Skip” (page 32). “Programme”/“TV System”/“Frequency” Presets programme channels manually. Select “Programme”, then press Press to select the programme number you want to manually tune (if tuning a VCR, select channel 0), then press RETURN.
- Page 33 FM Radio Set-up Preset up to 30 FM radio stations that can be received in your area. “Auto Tuning” Allows you to automatically tune and store all the available channels. Select “Auto Tuning”, then press Select “OK” to automatically tune in all the available channels. “FM Radio Presets”...
- Page 34 Control for HDMI. When set to “On”, the following functions are available. If the specific Sony equipment that is compatible with Control for HDMI is connected, this setting is applied to the connected equipment automatically when the “Control for HDMI”...
- Page 35 DivX(R) VOD Select “DivX(R) VOD Registration Code” to register your TV for playback of DivX contents. Select “DivX(R) VOD Deregistration Code” to delete the registration. • A new registration code will be displayed in “DivX(R) VOD Registration Code” after deleting registration via “DivX(R) VOD Deregistration Code”. DVD Settings “Downmix”...
- Page 36 Sufficient expertise is required for installing these products, especially to determine the strength of the wall for withstanding the TV’s weight. Be sure to entrust the attachment of these products to the wall to Sony dealers or licensed contractors and pay adequate attention to safety during the installation. Sony is not liable for any damage or...
- Page 37 TV installation dimensions table SU-WL50B: Screen centre point Unit: mm Display dimensions Screen centre dimension Length for mounting Figures in the above table may differ slightly depending on the installation. WARNING The wall that the TV will be installed on should be capable of supporting a weight of at least four times that of the TV.
- Page 38 Screw and hook locations diagram/table Screw location - When installing the Mounting Hook on the TV. SU-WL50B Hook location - When installing the TV onto the Base Bracket. SU-WL50B Base Bracket Hook * Hook location “a” cannot be used for the models in the table below.
- Page 39 When installing the base bracket on the wall (for SU-WL50B): Install one side of each plate to the upper bracket and the other side to the lower bracket. Attach the base bracket to the wall. Remove the plates. • Be sure to store the plates in a safe place after use.
- Page 40 No colour or irregular colour when viewing a signal the AC power cord, and inform your dealer or from the Y, P jacks of Sony service centre of how the indicator • Check the connection of the Y, P jacks of flashes (number of flashes).
- Page 41 General The TV turns off automatically (the TV enters standby mode) • Check if the “Sleep Timer” is activated (page 33). • Check if the “Idle TV Standby” is activated (page 35). Some input sources cannot be selected • Select “Video Labels” and cancel “Skip” of the input source (page 34).
- Page 42 Specifications System Panel system LCD (Liquid Crystal Display) Panel B/G, I, D/K, M TV system Colour/video system PAL, PAL60 (only video input), SECAM, NTSC4.43 (only video input), NTSC3.58 Channel coverage B/G: VHF: E2 to E12/ UHF: E21 to E69/ CATV: S01 to S03, S1 to S41 UHF: B21 to B69/ CATV: S01 to S03, S1 to S41 D/K: VHF: C1 to C12, R1 to R12/ UHF: C13 to C57, R21 to R60/ CATV: S01 to S03, S1 to S41, Z1 to Z39 M: VHF: A2 to A13/ UHF: A14 to A79/ CATV: A8 to A2, A to W+4, W+6 to W+84...
- Page 44 Customer support Instructions on “Installing the Wall-Mount Bracket” are not supplied in the form of a separate leaflet with this TV. These installation instructions are included within this TV’s instructions manual. © 2011 Sony Corporation Printed in China...
