ImageTech iMage A1 Manual

iMage A1 Bluetooth Conference Speakerphone
Packing
1. iMage A1 Bluetooth Conference Speakerphone
2. USB cable
3. User manual
Welcome!
Thank you for purchasing iMage A1 Bluetooth Conference
Speakerphone; this instruction manual will guide you on how to start
using this product.
I/O Port buttons and slots
LED Indicator
Bluetooth Mode
USB Mode
AUX Mode
Adapter Mode
Charing First!
Please connect the USB cable to iMage A1 Bluetooth Conference Spea-
kerphone to charge it; it is recommended to fully charge the power for
approximately 6 hours (charge until
using it for the first time.
Power Status
When the power is turned on, if one of the four mode indicators on the
right has a blue light on, it means that the unit is currently powered-on.
Charging: When the orange
charging and using USB power; if the light remains constantly
on, it means that charging is complete (when powered on).
When the orange
currently charging; when the orange light goes off, it means
that charging is complete (when powered off).
Power remaining: If the blue
sufficient power remaining; if the red
means that power is low and requires charging.
Start
Turn on the power and start iMage A1 Bluetooth Conference
Speakerphone; press the
mode you need.
Note: The battery life will significantly decrease if your device has not
been charged for a lone time.Therefore, we recommend you to charge
your device at least once every week
1. Increase volume
2. Lower volume
3. Mute
4: Mute microphone
5: Answer
6: Hang up
7: Mode selection
8: Mode status
indicator
9: Microphone
reception jack
10: Power status
indicator
11. Power
switch
12. USB Slot
13. Audio In
14. Audio Out
Power status
Charging
power indicator goes off) before
light flickers, it means that it is currently
light is constantly on, it means that it is
light flickers it means that there is
light flickers it
(mode selection) button to select the
.
Mode selection: Bluetooth Mode
You can connect other portable devices or computer using
Bluetooth connection to make iMage A1 Bluetooth Conference
Speakerphone your multimedia speakerphone.
Connection method:
1. Select "Search for Bluetooth device" on the device you want to
connect.
2. You will see "iMage A1_XX (number differs according to the
different devices)"; click on it to perform pairing.
3. Pairing complete.
Blue light remains constantly on: Bluetooth device has successfully
connected with iMage A1 Bluetooth Conference Speakerphone, and
supports HFP and A2DP.
* If the device could not be paired, you can clear the previous
pairing data to pair it over again; press and hold
button for 3 seconds and wait until you hear the prompt then
release it to search for iMage A1 Bluetooth Conference
Speakerphone again for pairing.
* Please confirm the Bluetooth chip built in the computer before
connecting to a PC or notebook using Bluetooth Mode, and
download the related driver programs etc. from the original
manufacturer of the chip; please refer to the user manual of your
computer for details.
Mode selection: USB Mode
You can connect to a PC or notebook through Mini-USB to make
iMage A1 Bluetooth Conference Speakerphone your expansion
speakerphone set.
Connection method:
1. First connect the USB cable to the Mini-USB jack of iMage A1
Bluetooth Conference Speakerphone.
2. Wait for the computer to automatically install the drivers (please
first confirm that your computer is connected to the Internet).
3. Set the "Playback device" and "Reception device" of the computer
as iMage A1.
* To use iMage A1 Bluetooth Conference Speakerphone with specific
application programs, you must first go to the program's settings to
select the "Playback device" and "Reception device"
Mode selection: AUX Mode
You can make iMage A1 Bluetooth Conference Speakerphone an
expansion speakerphone set by connecting it to a signal source using
a 3.5Ø audio cable.
Connection method: Connect the audio output of the device (PC, NB
etc.) to the Audio In socket of iMage A1 Bluetooth Conference
Speakerphone, and connect the audio input to the Audio Out socket.
Mode selection: Adapter Mode (optional purchase)
You can purchase the iMage A1 Bluetooth Adapter Tx/Rx additionally
to connect the audio input and output of the video device, making
iMage A1 Bluetooth Conference Speakerphone your external auxiliary
speakerphone for your video set.
Connection method:
1. Connect the iMage A1 Bluetooth Adapter Tx/Rx output/input to
the audio input/output of the video device.
2. Connect the iMage A1 Bluetooth Adapter Tx/Rx power and press
the connect (Bluetooth connection) button.
the hang up
.
