ImageTech M6 Quick Start Manual

iMageTech M6

Goods included with your delivery:

iMageTech M6
I/O Port & LED bu�ons and light indicators
1
1. Power switch/audio source switch key/power indicator
2. Audio source indicator
3. Pairing key/connec�on status indicator (white)
(S0, S1, S2, S3, S4, S5)

Start using your product

Step1: Connect the iMageTech M6 Wireless Speakerphone System to the USB power supply (No.6); press and hold the "Power on key (No.1)" for three seconds to ini�ate your product.
Step2: Press and hold the "pairing key (No.3)" for 3 seconds un�l the "Connec�on status indicator (white)" flashes quickly to start pairing with iMage A6 (A7); pair the S0, S1, S2, S3, S4, and S5
of iMage A6 (A7) in sequence; the la�er is paired successfully when the connec�on status indicator lighted on.
(Set your iMage A6 (A7) to Link mode in advance.)
Step3: Select the audio source (Bluetooth, USB, video) according to the audio device you desire to connect; select Bluetooth mode for mobile devices including smartphone or tablet; select
USB mode for desktop or notebook computer; select LINK (Line-in/Line-Out) mode along with a dedicated audio cable for video host or audio device.
USB cable USB adapter
2 3
Blue light: Bluetooth mode
Red light: USB mode
Indicator dimmed: LINK
(Line-in/Line-out) mode
Purple light: Expansion mode
Wireless Speakerphone System
Audio Cable Set
4 5
4. Audio input port (Line-In)
5. Audio output port (Line-Out)
6. USB Port
6
