- Page 1 3 Hole Cleat TECHNICALMANUALS Instalation Manual Rev. A - 8.28.18 Tool List: - Screwdriver - Grease - Small Flat-head Screwdriver 3 Hole Cleat Kit Contents: Part No. 15289 6 Short Screws 6 Long Screws...
- Page 2 Step 1: Determine your shoe type Take a look at your shoes and use the guide below to determine which length screws to use. Some shoes will have a bit of a recess in the sole before the Some shoes will have no recess in the sole before the threads threads start.
- Page 3 Step 2: Disassembly For packaging purposes, the 3-hole cleats come assembled. Note: Pulling from one side only may cause damage to the tread. The first step is to remove the tread to install the cleats. Pry off each side sepperately, working from the side of the cleat is ideal.
- Page 4 Step 3: Fitting your cleats Determine your release angle and fore / aft positioning. Each set of cleats comes with 2 different versions. One features 2 dots printed on the cleat and the other does not have and dots printed on it. No Dots 2 Dots Putting the cleat with no dots on the...
- Page 5 Step 4: Finish the installation Secure the cleat to the shoe and install the tread. Lightly thread in the 3 cleat screws. Position the cleat as desired. Once you’ve positioned Completely press the tread We want to leave them slightly loose the cleat, tighten the screws back on to the cleat base in for the next step.
