Step 1: The Gem Pump Clip mounts to your bicycle
frame using existing water bottle cage
bosses and hardware. Remove the water
bottle cage bolts from your frame to install
the pump clip.
Step 2: Place the clip onto the frame and secure using the existing
hardware. If using a water bottle cage, the clip mounts
underneath the cage. Longer hardware may be needed and
can be acquired from your local dealer if necessary
Step 3: Install the bottle cage bolts back into the
torque provided by your frames
manufacturer.
1/4
Advertisement
Table of Contents
Related Manuals for Crankbrothers Gem Pump
Summary of Contents for Crankbrothers Gem Pump
- Page 1 TECHNICALMANUALS Step 1: The Gem Pump Clip mounts to your bicycle Step 2: Place the clip onto the frame and secure using the existing Step 3: Install the bottle cage bolts back into the frame using existing water bottle cage hardware.
- Page 2 Step 1: Unthread the valve cap and set aside. Make Step 2: Swing the lever outward to push the rubber Step 3: Separate the gasket and plastic sure the lever is in the down position for this gasket and plastic adapter out far enough to adapter then rotate each piece step.
- Page 3 Step 1: If inflating a tube with a presta valve, remember Step 2: Push the pump head onto your valve. Step 3: Lift the lever arm from the pump head to lock to unscrew the valve locknut and tap to insure into place.
- Page 4 Step 7: Rotate the lever toward the pump to unlock the Step 8: Remove the pump from the valve. Step 9: head for removal.
